Camcorder
! Touch Sensor ( pg. 6)
# OK (DISP) Button [OK/DISP] ( pg. 13)
$ Menu Button [MENU]
% Power Switch [ ]
(You can turn off the camcorder by
pressing and holding this button.)
& Speaker
( Playback/Recording Mode Switching
Button [SELECT PLAY/REC] ( pg. 16)
) Access/Charge Lamp [ACCESS/CHRG.]
(Blinks when you access files or charge
the battery. Do not turn off the power or
remove the battery pack/AC adapter while
accessing files.)
* Direct DVD Button [DIRECT DVD]
( pg. 22)/Information Button [INFO]
( pg. 15)
+ Upload/Upload Pre-Record Mode Button
[UPLOAD] ( pg. 27)
, Auto/Manual Mode Button [AUTO/
MANUAL]
- Video Recording Start/Stop Button [START/
STOP] ( pg. 16)
. Still Image Shooting Button [SNAPSHOT]
( pg. 17)
/ Zoom Lever [W 7 , T
,
]
Speaker Volume Control [–VOL+]
( pg. 18)
0 Mode Switch [!, #]
1 DC Jack [DC] ( pg. 14)
2 Audio/Video Jack [AV]
3 USB (Universal Serial Bus) Jack [
2
]
( pg. 22, 25 and 29)
4 LED Light
5 Camera Sensor
6 Lens Cover
7 Lens
8 Lens Cover Switch [
=
,
>
]
9 Stereo Microphone
: SD Card Slot
; Stud Hole
< Tripod Mounting Socket
= Battery Release Button [BATT.] ( pg. 14)
> Battery Pack Mount ( pg. 14)
? Grip Strap
