INSTALLING YOUR NEW VCR
RF OUT
RF cable (supplied)
Matching transformer
(not supplied)
AC Power
Cord
Audio/video cable
(not supplied)
TV
ANT. IN
(Antenna or cable input)
Back of VCR
To 75 ohm terminal
AC Outlet
Antenna or cable
Flat feeder
Coaxial cable
Basic Connections
AUDIO OUT
VIDEO OUT
To Audio/video input
connectors
