# REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABCDEFGH I JKLMN
#
REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABCDEFGHI JKLMN
5-4
---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------ ---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------
******************************
PACKING AND ACCESSORY ASSEMBLY <M1>
801 LG-3835RP0075B INSTRUCTION ASSEMBLY (EN,GE,FR,IT,DU) A C
801 LG-3835RP0075C INSTRUCTION ASSEMBLY (PT,GR,SP) A C
801 LG-3835RP0075D INSTRUCTION ASSEMBLY (SW,DA,FI,NO,GE) A C
801 LG-3835RP0075E INSTRUCTION ASSEMBLY (EN,GE,FR,IT,DU) B DE J
801 LG-3835RP0075F INSTRUCTION ASSEMBLY (PT,GR,SP) B DE J
801 LG-3835RP0075G INSTRUCTION ASSEMBLY (SW,DA,FI,NO,GE) B DE J
801 LG-3835RP0075H INSTRUCTION ASSEMBLY (FR) FG
801 LG-3835RP0075K INSTRUCTION ASSEMBLY (EN) I
801 LG-3835RP0075L INSTRUCTION ASSEMBLY (PO,CZ,HU) K M
801 LG-3835RP0075M INSTRUCTION ASSEMBLY (EN) H
801 LG-3835RP0075N INSTRUCTION ASSEMBLY (PO,CZ,HU) L N
802 LG-3890R-H768D BOX EDJ200P NA3GJJX SW3-A 0.858 4 ABCDEFGHI JKLMN
803 LG-3920R-0067A PACKING AF999NS 0.02 65 EPS 12 1190 23 ABCDEFGHI JKLMN
804 LG-292-053A BAG SOFT(VCP) ABCD FG K
804 LG-3880R-H001A BAG HDPE 500 500 0.03 VCR MIDI E H I J LMN
806 LG-6850R-CAA26 CABLE,COAXIAL 1200M/M PAL-PAL DOUBLE SHIELD ABCDEFGH I JKLMN
808 — BATTERY,MANGANESE AAAM(R03) SEOTONG 1-5 V - 1PA ABCDEFGHI JKLMN
810 LG-6851RP0003A CABLE ASSY,RF CABLE ASSY,RF/SCART/RCA USING ABCDEFGH I JKLMN
821 LG-6850R-SMA21 CABLE,COAXIAL 14PIN 1200M/M SCART-SCART DOUB FG
900 LG-6711R1P037A REMOTE CONTROLLER ASSEMBLY N5 NOR EDJ209P NA3GJJX JVC W/S B D FGHI L N
900 LG-6711R1P037B REMOTE CONTROLLER ASSEMBLY N5 EDJ200P NAEGJJX JVC W/O SHO A C K M
900 LG-6711R1P037C REMOTE CONTROLLER ASSEMBLY N5 EDJ209P NA6NJJY JVC W/SHOWV E J
MODEL MARK MODEL MARK MODEL MARK
HR-J285EU A HR-J595MS F HR-J282EU K
HR-J290EU B HR-J295MS G HR-J283EU L
HR-J585EU C HR-J595EK H HR-J582EU M
HR-J590EU D HR-J295EK I HR-J583EU N
HR-J593EU E HR-J293EU J
5.2 REPLACEMENT PARTS LIST
******************************
FINAL ASSEMBLY <M2>
A00 LG-6721RF0700D DECK ASSEMBLY,VIDEO D35(N) DI(2HD, SP ONLY, AHC(X) AB G JKL
A00 LG-6721RF0710D DECK ASSEMBLY,VIDEO D35(N) DI (2HD, NP, AHC(X), B/ I
A00 LG-6721RF0750D DECK ASSEMBLY,VIDEO D35(N) DI (4HF, PAL, AHC(X), B CDEF H MN
A43 LG-3721R-F253A PANEL ASSEMBLY,FRONT EDJ200P (J285EU) A
A43 LG-3721R-F253B PANEL ASSEMBLY,FRONT EDJ209P (J290EU) B
A43 LG-3721R-F253C PANEL ASSEMBLY,FRONT EDJ904NS (J595MS) F
A43 LG-3721R-F253D PANEL ASSEMBLY,FRONT EDJ900NP (J585EU) C
A43 LG-3721R-F253E PANEL ASSEMBLY,FRONT EDJ209P (J293EU) J
A43 LG-3721R-F253F PANEL ASSEMBLY,FRONT EDJ909NP (J590EU) D
A43 LG-3721R-F253G PANEL ASSEMBLY,FRONT EDJ909NP (J593EU) E
A43 LG-3721R-F253H PANEL ASSEMBLY,FRONT EDJ204S (J295MS) G
A43 LG-3721R-F253J PANEL ASSEMBLY,FRONT EDJ904NI(J595EK) H
A43 LG-3721R-F253K PANEL ASSEMBLY,FRONT EDJ200Y (J282EU) K
A43 LG-3721R-F253L PANEL ASSEMBLY,FRONT EDJ203Y (J283EU) L
A43 LG-3721R-F253M PANEL ASSEMBLY,FRONT EDJ203NI (J295EK) I
A43 LG-3721R-F253N PANEL ASSEMBLY,FRONT EDJ903NY (J583EU) N
A43 LG-3721R-F253Q PANEL ASSEMBLY,FRONT EDJ900NY (J582EU) M
A46 LG-3501R-5739A BOARD ASSEMBLY JVC DI EC(D) SERIES B J
A46 LG-3501R-5739B BOARD ASSEMBLY JVC DI EC(D) SERIES A
A46 LG-3501R-5739C BOARD ASSEMBLY JVC DI EC(D) SERIES F
A46 LG-3501R-5739D BOARD ASSEMBLY JVC DI EC(D) SERIES C
A46 LG-3501R-5739E BOARD ASSEMBLY JVC DI EC(D) SERIES DE
A46 LG-3501R-5739F BOARD ASSEMBLY JVC DI EC(D) SERIES G
A46 LG-3501R-5739G BOARD ASSEMBLY JVC DI EC(D) SERIES MN
A46 LG-3501R-5739H BOARD ASSEMBLY JVC DI EC(D) SERIES H
A46 LG-3501R-5739J BOARD ASSEMBLY JVC DI EC(D) SERIES KL
A46 LG-3501R-5739K BOARD ASSEMBLY JVC DI EC(D) SERIES I
250 LG-3110R-0128C CASE TOP(Q280G:B/K),SIDE E J
250 LG-3110R-0223G CASE TOP( 0128 A288G SIDE SCREW 4EA ABCD FGH I KLMN
260 LG-3210R-0023B FRAME MAIN (VII-PJT, 60HR) ABCDEFGHI JKLMN
280 LG-3720R-F193A PANEL,VIDEO FRONT(B589G-SLVER) ABCD FGHI KLMN
280 LG-3720R-F193B PANEL,VIDEO FRONT (Q280G) E J
283 LG-3580R-V031A DOOR,CASE CST (VCR) (MONO-B589G-SILVER) AB G I KL
283 LG-3580R-V031B DOOR,CASE CST (VCR) (MONO-Q280G-B.K) J
283 LG-3580R-V031C DOOR,CASE CST (VCR) (HIFI-B589G-SILVER) CD F H MN
283 LG-3580R-V031D DOOR,CASE CST (VCR) (HIFI-Q280G-BK) E
284 LG-442-681A SPRING DOOR ABCDEFGH I JKLMN
! 300 LG-6410RBHV01A POWER CORD H03VVH2-F2 X 0.75MM FILTER VOL H I
! 300 LG-6410RCHP03B POWER CORD HIT-102/H03VVH2-F (NM) HARNESS ABCDEFG JKLMN
320 LG-3720R-D020A PANEL DISTRIBUTOR (PAL-1SCART) A I KL
320 LG-3720R-D020B PANEL DISTRIBUTOR (PAL-SCART MONO) B G J
320 LG-3720R-D020C PANEL DISTRIBUTOR (PAL-2SCART HI-FI) DEF H
320 LG-3720R-D020D PANEL DISTRIBUTOR (PAL-1SCART HI-FI) C MN
323 LG-3111R-0089C CASE ASSEMBLY PRE-AMP (02-PAL) ABCDEFGH I JKLMN
330 LG-3550R-0210A COVER BOTTOM(LARGE) ABCDEFGH I JKLMN
452 LG-353-051A SCREW SPECIAL ABCDEFGH I JKLMN
457 LG-353-051E SCREW SPECIAL (3X12) ABCDEFGH I JKLMN
462 LG-353-136A SCREW SPECIAL(FBK) (353S353A) ABCDEFGHI JKLMN
******************************
MECHANISM ASSEMBLY <M4>
A01LG-6723R-0401A DRUM(CIRC) ASSEMBLY D35-2CH SP ONLY (8P2) AB G JKL
A01 LG-6723R-0401B DRUM(CIRC) ASSEMBLY D35-2CH SP/EP (8M2) I
A01 LG-6723R-0403C DRUM(CIRC) ASSEMBLY D35-6CH PAL (8P6C) CDEF H MN
A04 LG-4421R-0008A BRAKE ASSEMBLY RS AB G JKL
A04 LG-4811RF0038A BRACKET ASSEMBLY L/D(S) ABCDEFGHI JKLMN
A11 LG-4471R-0005A GEAR ASSY P3 ABCDEFGHI JKLMN
A12 LG-4471R-0004A GEAR ASSY P2 ABCDEFGHI JKLMN
A21 LG-4931R-0047A HOLDER ASSY CST ABCDEFGHI JKLMN
A22 LG-4471R-0006A GEAR ASSY RACK F/L ABCDEFGH I JKLMN
A23 LG-4261R-0023A ARM ASSY F/L ABCDEFGHI JKLMN
A24 LG-4510R-0046A LEVER ASSY SWITCH ABCDEFGHI JKLMN
001 LG-6723R-0304A DRUM(CIRC) ASSEMBLY SUB D35-2CH (8P2) AB G JKL
001 LG-6723R-0304B DRUM(CIRC) ASSEMBLY SUB D35-2CH (8M2) I
001 LG-6723R-0306C DRUM(CIRC) ASSEMBLY SUB D35-6CH (8P6C) CDEF H MN
002 LG-4680R-B005A MOTOR(MECH) DRUM I2OAL05 SEJIN-SANKYO ICLE ABCDEFGH I JKLMN
002A LG-5202R00002C BRUSH,CARBON ASSY D33 (TIP+2 SPRING) 1.4, ABCDEFGHI JKLMN
003 LG-4930R-0284A HOLDER,SHELF FPC(6CH) ABCDEFGH I JKLMN
004 LG-5006R-0034A CAP FPC ABCDEFGHI JKLMN
008 LG-6850R-HG18Z CABLE,FLAT P=1.25 FFC UL2896(0.05X0.8) 7 ABCDEFGHI JKLMN
009 LG-4260R-0038A ARM T/UP(D35) ABCDEFGH I JKLMN
010 LG-4810R-0125A BRACKET CHASSIS ABCDEFGH I JKLMN
011 LG-4261R-0022A ARM ASSY TENSION(D35) ABCDEFGH I JKLMN
012 LG-3041R-0037A BASE ASSY P2 ABCDEFGHI JKLMN
013 LG-3041R-0038A BASE ASSY P3 ABCDEFGHI JKLMN
014 LG-3041R-0039A BASE ASSY P4 ABCDEFGHI JKLMN
015 LG-5870R-0005A OPENER LID(D35) ABCDEFGH I JKLMN
016 LG-3041R-0036A BASE ASSEMBLY A/C HEAD (ALPS) ABCDEFGHI JKLMN
017 LG-4408R-0003A REEL S ABCDEFGHI JKLMN
018 LG-4970R-0140A SPRING COIL RS D35 ABCDEFGH I JKLMN
019 LG-4421R-0008A BRAKE ASSEMBLY RS CDEF H I MN
020 LG-4970R-0128A SPRING COIL D35 (TB) ABCDEFGHI JKLMN
021 LG-4421R-0006A BRAKE ASSY T ABCDEFGHI JKLMN
022 LG-6520D00002A HEAD(CIRC) D35 FE ST FE HEAD ABCDEFGHI JKLMN
023 LG-3040R-0057A BASE LOADING ABCDEFGH I JKLMN
024 LG-4261R-0029A ARM ASSEMBLY IDLER (N) ABCDEFGH I JKLMN
025 LG-4810R-0118A BRACKET L/D(S) ABCDEFGHI JKLMN
026 LG-4680R-D002A MOTOR(MECH) LOADING MDB2B66 SANKYO D35 ASP ABCDEFGHI JKLMN
027 LG-4470R-0093A GEAR WHEEL ABCDEFGH I JKLMN
028 LG-4408R-0004A REEL T ABCDEFGHI JKLMN
029 LG-4261R-0019A ARM ASSY PINCH ABCDEFGH I JKLMN
030 LG-4510R-0043A LEVER T/UP ABCDEFGH I JKLMN
031 LG-4970R-0123A SPRING COIL TENSION(D35) ABCDEFGHI JKLMN
032 LG-3141R-0040A CHASSIS ASSY D35 ABCDEFGHI JKLMN
051 LG-4400R-0005A BELT CAPSTAN ABCDEFGH I JKLMN
052 LG-4680R-A007A MOTOR(MECH) CAPSTAN F2QVB06 SANKYO D35 ASR ABCDEFGH I JKLMN
052A LG-4980R-0023A SUPPORTER CAPSTAN(D35) ABCDEFGHI JKLMN
054 LG-4470R-0100A GEAR RACK F/L ABCDEFGH I JKLMN
054A LG-4970R-0124B SPRING COIL D35 (RACK F/L) ABCDEFGHI JKLMN
055 LG-4470R-0097A GEAR DRIVE(D35) ABCDEFGHI JKLMN
056 LG-4470R-0096A GEAR CAM(D35) ABCDEFGH I JKLMN
058 LG-4421R-0007A BRAKE ASSY CAPSTAN ABCDEFGH JKLMN
060 LG-4510R-0040A LEVER F/R(D35) ABCDEFGHI JKLMN
061 LG-4265R-0006A CLUTCH ASSEMBLY D35 (N) ABCDEFGHI JKLMN
064 LG-4470R-0098A GEAR SECTOR(D35) ABCDEFGHI JKLMN
065 LG-4261R-0021A ARM ASSY P3 ABCDEFGH I JKLMN
066 LG-4970R-0122A SPRING COIL D35 ABCDEFGH I JKLMN
067 LG-4470R-0095A GEAR P3 ABCDEFGHI JKLMN
068 LG-4470R-0094A GEAR P2 ABCDEFGHI JKLMN
069 LG-4970R-0122A SPRING COIL D35 ABCDEFGH I JKLMN
070 LG-4261R-0020A ARM ASSY P2 ABCDEFGH I JKLMN
076 LG-4510R-0047A LEVER SPRING ABCDEFGH I JKLMN
077 LG-3300R-M116A PLATE SLIDER ABCDEFGH I JKLMN
078 LG-4510R-0041A LEVER TENSION ABCDEFGH I JKLMN
079 LG-3040R-0056A BASE TENSION(D35) ABCDEFGHI JKLMN
100 LG-3301R-M022A PLATE ASSEMBLY TOP ABCDEFGHI JKLMN
102 LG-4970R-0130A SPRING COIL D35 (STOPPER) ABCDEFGHI JKLMN
103 LG-4930R-0276A HOLDER,SHELF SIDE(L) ABCDEFGHI JKLMN
105 LG-4930R-0274A HOLDER,SHELF CST ABCDEFGH I JKLMN
106 LG-4930R-0275A HOLDER,SHELF SIDE(R) ABCDEFGH I JKLMN
107 LG-4510R-0044A LEVER STOPPER ABCDEFGH I JKLMN
109 LG-5870R-0004A OPENER DOOR ABCDEFGHI JKLMN
110 LG-4260R-0035A ARM F/L(L) ABCDEFGHI JKLMN
112 LG-3070R-0002A BODY F/L ABCDEFGH I JKLMN
113 LG-4970R-0127A SPRING COIL D35 (F/L(R)) ABCDEFGH I JKLMN
114 LG-4260R-0036A ARM F/L(R) ABCDEFGHI JKLMN
115 LG-4510R-0042A LEVER SWITCH ABCDEFGHI JKLMN
116 LG-4970R-0138A SPRING COIL D35 SWITCH ABCDEFGHI JKLMN
117 LG-3300R-M137A PLATE SPRING CST ABCDEFGHI JKLMN
401 LG-1MEC0261518 SCREW MACHINE,PAN HEAD SPR W D2.6 L4.5 MSWR3/FZY ABCDEFGHI JKLMN
402 LG-1MPC0261418 SCREW MACHINE,PAN HEAD D2.6 L4.0 MSWR3/FZY ABCDEFGH I JKLMN
405 LG-1SZZR-0031B SCREW,DRAWING D2.6 L5.8 SWRCH16A/FZY TAP ABCDEFGHI JKLMN
406 LG-1MEC0302018 PAN HEAD MACHINE SCREW S/W + D3.0 L6.0 MSWR3/FZY ABCDEFGHI JKLMN
409 LG-1SZZR-0032B SCREW,DRAWING D2.6 L5.0 SWRCH18A/FZY TAP ABCDEFGHI JKLMN
410 LG-1APF0262218 SCREW TAP TITE(B),PAN HEAD D2.6 L6.8 MSWR3/FZY ABCDEFGHI JKLMN
517 LG-1WZZR-0004D WASHER STOPPER ABCDEFGH I JKLMN
518 LG-1WZZR-0004A WASHER STOPPER ABCDEFGHI JKLMN
