# REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABCDEFGH I JKLMN
#
REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABCDEFGHI JKLMN
5-5
---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------ ---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------
******************************
MAIN BOARD ASSEMBLY <03>
PBM00 LG-6871R-5739A PWB(PCB) ASSEMBLY,TOTAL EDJ209P (PCB ASSY) B J
PBM00 LG-6871R-5739B PWB(PCB) ASSEMBLY,TOTAL EDJ200P (PCB ASSY) A
PBM00 LG-6871R-5739C PWB(PCB) ASSEMBLY,TOTAL EDJ904NS (PCB ASSY) F
PBM00 LG-6871R-5739D PWB(PCB) ASSEMBLY,TOTAL EDJ900NP (PCB ASSY) C
PBM00 LG-6871R-5739E PWB(PCB) ASSEMBLY,TOTAL EDJ909NP (PCB ASSY) DE
PBM00 LG-6871R-5739F PWB(PCB) ASSEMBLY,TOTAL EC(D) SERIES (PCB ASSY) G
PBM00 LG-6871R-5739G PWB(PCB) ASSEMBLY,TOTAL EDJ SERIES (HIFI) MN
PBM00 LG-6871R-5739H PWB(PCB) ASSEMBLY,TOTAL EDJ904NI (HIFI) H
PBM00 LG-6871R-5739J PWB(PCB) ASSEMBLY,TOTAL EDJ SERIES (MONO) KL
PBM00 LG-6871R-5739K PWB(PCB) ASSEMBLY,TOTAL EDJ203I (MONO) I
IC101 STR-A6351 IC,POWER MANAGEMENT STR-A6351 SANKEN 8 DIP ST SMPS ABCDEFGH I JKLMN
! IC102 LTV-817B SENSOR LTV-817B,PHOTO COUPLER(LITEON) ABCDEFGH I JKLMN
IC103 LG-0IKE431000A IC,KEC KIA431 3 PIN TP ABCDEFGH I JKLMN
IC201 LG-0ILNRSA007A IC,LINEAR LA70100M SANYO 30 SOP ST SECAM FG
IC301 LG-0ILNRSA005A IC,LINEAR LA71750AM SANYO 100 QFP TRAY A ABCDEFGH I JKLMN
IC501 LG-0IMCRHI014B IC,MICRO CONTROLLER HD6432197SA06F HITACHI 112 QFP ABCDEFGH I JKLMN
IC501 LG-0IMCRHI019A IC,MICRO CONTROLLER HD6432197SA09F HITACHI 112P QF KLMN
IC503 LG-0IAL241600B IC,ATMEL AT24C16 - - - - ABCDEFGH I JKLMN
IC504 LG-0IKE703100A IC,KEC KIA7031P 3P 3.1V RESET(TAPING) ABCDEFGHI JKLMN
IC505 LG-0IKE704200B IC,KEC KIA7042P 3P 4.2V RESET(TAPING) ABCDEFGHI JKLMN
IC751 LG-0IIT341700B IC,ITT MSP3417D-QG QFP44 BK NICAM+A2 CDEF H MN
IC7V1 LG-0ILNRMN001A IC,LINEAR SDA5650 MICRONAS 14 DIP ST VPS B DE J
IC801 LG-0IPH960500A IC,PHILIPS TDA9605H QFP44 BK HIFI AMP+HIF CDEF H MN
IC901 MM1443XJ IC,MITSUMI MM1443XJ SSOP-34 TP CANAL S/W B G J
Q151 LG-0TR127309AA TRANSISTOR KTA1273-TP-Y (KTA966A)KEC ABCDEFGHI JKLMN
Q152 LG-0TR127309AA TRANSISTOR KTA1273-TP-Y (KTA966A)KEC ABCDEFGHI JKLMN
Q154 LG-0TR126809BA TRANSISTOR,BIPOLARS KTA1268-BL TP KEC ABCDEFGHI JKLMN
Q155 LG-0TR320509AB TRANSISTOR KTC3205-TP-Y (KTC2236A)KEC ABCDEFGHI JKLMN
Q157 LG-0TR120309AE TRANSISTOR SRC1203 TP AUK TO92 22K,22K ABCDEFGH I JKLMN
Q162 LG-0TR534309BA TRANSISTOR 2SC5343-L TP AUK TO92 ABCDEFGH I JKLMN
Q163 LG-0TR120109AC TRANSISTOR SRC1201 TP AUK TO92 4.7K,4.7K ABCDEFGHI JKLMN
Q164 LG-0TR120309AE TRANSISTOR SRC1203 TP AUK TO92 22K,22K ABCDEFGH I JKLMN
Q165 LG-0TR220309AF TRANSISTOR SRA2203 TP AUK TO92 22K,22K ABCDEFGHI JKLMN
Q166 LG-0TR127309AA TRANSISTOR KTA1273-TP-Y (KTA966A)KEC ABCDEFGHI JKLMN
Q301 LG-0TR534309BA TRANSISTOR 2SC5343-L TP AUK TO92 ABCDEFGH I JKLMN
Q302 LG-0TR198009CA TRANSISTOR 2SA1980G TP AUK TO92 ABCDEFGH I JKLMN
Q303 LG-0TR534309BA TRANSISTOR 2SC5343-L TP AUK TO92 ABCDEFGH I JKLMN
Q304 LG-0TR534309BA TRANSISTOR 2SC5343-L TP AUK TO92 ABCDEFGH I JKLMN
Q305 LG-0TR198009CA TRANSISTOR 2SA1980G TP AUK TO92 ABCDEFGH I JKLMN
Q306 LG-0TR534409AA TRANSISTOR 2SC5344Y TP ABCDEFGH I JKLMN
Q307 LG-0TR198009CA TRANSISTOR 2SA1980G TP AUK TO92 B DEFGH J
Q308 LG-0TR198009CA TRANSISTOR 2SA1980G TP AUK TO92 ABCDEFGH I JKLMN
Q309 LG-0TR198009CA TRANSISTOR 2SA1980G TP AUK TO92 ABCDEFGH I JKLMN
Q501 LG-0TR534309BA TRANSISTOR 2SC5343-L TP AUK TO92 ABCDEFGH I JKLMN
Q502 LG-0TR534309BA TRANSISTOR 2SC5343-L TP AUK TO92 ABCDEFGH I JKLMN
Q503 LG-0TR127309AA TRANSISTOR KTA1273-TP-Y (KTA966A)KEC ABCDEFGHI JKLMN
Q504 LG-0TR534309BA TRANSISTOR 2SC5343-L TP AUK TO92 ABCDEFGH I JKLMN
Q514 LG-0TR120309AE TRANSISTOR SRC1203 TP AUK TO92 22K,22K ABCDEFGH I JKLMN
Q515 LG-0TR120309AE TRANSISTOR SRC1203 TP AUK TO92 22K,22K ABCDEFGH I JKLMN
Q5P2 LG-0TR120309AE TRANSISTOR SRC1203 TP AUK TO92 22K,22K ABCDEFGHI JKLMN
Q5P3 LG-0TR120309AE TRANSISTOR SRC1203 TP AUK TO92 22K,22K ABCDEFGHI JKLMN
Q5P4 LG-0TR120309AE TRANSISTOR SRC1203 TP AUK TO92 22K,22K ABCDEFGHI JKLMN
Q5P5 LG-0TR120309AE TRANSISTOR SRC1203 TP AUK TO92 22K,22K ABCDEFGHI JKLMN
Q5S1 LG-0TR534309BA TRANSISTOR 2SC5343-L TP AUK TO92 ABCDEFGH I JKLMN
Q7S1 LG-0TR534309BA TRANSISTOR 2SC5343-L TP AUK TO92 FG
Q901 LG-0TR120309AE TRANSISTOR SRC1203 TP AUK TO92 22K,22K ABCDEFGH I JKLMN
Q902 LG-0TR220309AF TRANSISTOR SRA2203 TP AUK TO92 22K,22K ABCDEFGHI JKLMN
Q903 LG-0TR120309AE TRANSISTOR SRC1203 TP AUK TO92 22K,22K ABCDEFGH I JKLMN
Q906 LG-0TR534309BA TRANSISTOR 2SC5343-L TP AUK TO92 ABCDEFGH I JKLMN
! BD101 S1WBA60 DIODE S1WBA60(1A 600V) SHIDENKEN ABCDEFGH I JKLMN
D102 EG01CW DIODE,RECTIFIER EG01CW(R-FORM 5MM) TP SANKEN ABCDEFGHI JKLMN
D103 LG-0DR180209AA DIODE,RECTIFIER ERA18-02KFRB TP FUJI DO204AL 2 ABCDEFGH I JKLMN
D104 1SS133DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDEFGHI JKLMN
D105 LG-0DR104009BA DIODE,RECTIFIER RL104F TP RECTRON NON 400V 1A ABCDEFGHI JKLMN
D106 1N5822DIODE,RECTIFIER 1N5822 BK RECTRON DO201AD 40V ABCDEFGH I JKLMN
D109 LG-0DR202000AB DIODE,RECTIFIER HER202 BK RECTRON NON 100V 2A ABCDEFGHI JKLMN
D155 LG-0DR104009AB DIODE,RECTIFIER RL104 R. TP GULF SEMICONDUCTOR ABCDEFGHI JKLMN
D156 1SS133 DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDEFGH I JKLMN
D159 1SS133 DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDEFGH I JKLMN
D160 1SS133 DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDEFGH I JKLMN
D301 1SS133 DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDEFGH I JKLMN
D502 1SS133 DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDEFGH I JKLMN
D509 1SS133 DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDEFGH I JKLMN
D901 1SS133 DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDEFGH I JKLMN
D902 1SS133 DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDEFGH I JKLMN
D903 1SS133 DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDEFGH I JKLMN
D904 1SS133 DIODE,SWITCHING 1SS133 DETECT,SW TP H
ZD151 MTZ13CT-77 DIODE,ZENERS MTZ13C TP ROHM-K ABCDEFGH I JKLMN
ZD503 LG-0DZ622609CA DIODE,ZENER GDZJ6.2C 26MM TP GRANDE DO34 0 ABCDEFGH I JKLMN
ZD801 UZ5.6BSB-T2 DIODE,ZENER UZ-5.6BSB 26MM TP PYUNG CHANG CDEF H MN
ZD802 UZ5.6BSB-T2 DIODE,ZENER UZ-5.6BSB 26MM TP PYUNG CHANG CDEF H MN
ZD803 MTZ13AT-77 DIODE,ZENER MTZ13A TP ROHM-K CDEF H MN
ZD804 MTZ13AT-77 DIODE,ZENER MTZ13A TP ROHM-K CDEF H MN
! C101 LG-624-088F CAPACITOR,DRAWING PCX2 275V 0.1UF,M (PILKO) ABCDEFGH I J
! C101 LG-624-088L CAPACITOR,DRAWING 435D SUNIL ELECTRONICS 0.1UF/2 KLMN
! C102 LG-624-088F CAPACITOR,DRAWING PCX2 275V 0.1UF,M (PILKO) ABCDEFGH I J
! C102 LG-624-088L CAPACITOR,DRAWING 435D SUNIL ELECTRONICS 0.1UF/2 KLMN
C103 LG-0CE476CU611 CAPACITOR,AL.ELECTROLYTIC 47UF SHL,SD 400V M FL BK7.5 ABCDEFGHI JKLMN
C105 LG-0CQ1031Y519 CAPACITOR,POLYESTER 0.01UF D 630V K PE NI TP ABCDEFGH I JKLMN
C106 LG-624-087B CAPACITOR HIGH-VOL 100P/1KV SMPS SAMHWA ABCDEFGH I JKLMN
C109 QET41HM-106 CAPACITOR,FIXED ELECTROLYTIC 10M SRA 50V M FM5 TP(5) ABCDEFGHI JKLMN
! C112 LG-0CG3320U630 CAPACITOR,SEMI CERAMIC 3300 PF 400V M E R(NK,AD,SD) ABCDEFGH I JKLMN
! C113 LG-0CG1010U510 CAPACITOR,SEMI CERAMIC 100 PF 400V K B R (NK,AD,SD) ABCDEFGH I JKLMN
C114 LG-0CQ4732K409 CAPACITOR,FIXED FILM 0.047UF S 50V J PE TP ABCDEFGHI JKLMN
C115 LG-624-085D CAPACITOR CE 47UF/50V KME (SMPS) ABCDEFGH I JKLMN
C116 LG-0CE108BF630 CAPACITOR,FIXED ELECTROLYTIC 1000UF KME 16V M FM5 BULK ABCDEFGH I JKLMN
C117 LG-624-082H CAPACITOR CE 1000UF/10V SHL(10*12.5)T/P ABCDEFGHI JKLMN
C120 LG-0CE477BH630 CAPACITOR,AL.ELECTROLYTIC 470UF KME TYPE 25V M FM5 BULK ABCDEFGH I JKLMN
C121 LG-0CE227CH618 CAPACITOR,FIXED ELECTROLYTIC 220UF SHL,SD 25V 20% FL TP 5 ABCDEFGH I JKLMN
C127 LG-0CN223AK948 CAPACITOR,TUBULAR(HIGH DIELEC) 0.022UF 50V Z F TA26 S ABCDEFGH I JKLMN
C135 LG-0CN4710K518 CAPACITOR TUBULA(HIGH DIELE) 470P 50V K B TA26 ABCDEFGH I JKLMN
C153 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABCDEFGH I JKLMN
C190 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABCDEFGH I JKLMN
C201 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 FG
C202 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 FG
C203 QET41HM-105 CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) FG
C204 QET41HM-105 CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) FG
C205 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA FG
C206 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 FG
C207 QET41HM-474 CAPACITOR,ELECTROLYTIC 0.47M SRA 50V M FM5 TP(5) FG
C208 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 FG
C209 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 FG
C210 QET41HM-474 CAPACITOR,ELECTROLYTIC 0.47M SRA 50V M FM5 TP(5) FG
C211 LG-0CN2220F668 CAPACITOR,TUBULAR(HIGH DIELEC) 2200P 16V M X TA26 FG
C212 LG-0CN2220F668 CAPACITOR,TUBULAR(HIGH DIELEC) 2200P 16V M X TA26 FG
C213 QET41HM-225 CAPACITOR,FIXED ELECTROLYTIC 2.2UF SRA,SS 50V 20% FM5 TP 5 FG
C214 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 FG
C215 QET41CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) FG
C216 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 FG
C301 QET41HM-475 CAPACITOR,FIXED ELECTROLYTIC 4.7UF SRA,SS 50V 20% FM5 TP 5 ABCDEFGHI JKLMN
C302 QET41CM-226 CAPACITOR,ELECTROLYTIC 22M SRA 16V M FM5 TP(5) ABCDEFGH I JKLMN
C303 LG-0CN1220F668 CAPACITOR TUBULA(HIGH DIELE) 1200P 16V M X TA26 ABCDEFGHI JKLMN
C304 QET41CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) ABCDEFGHI JKLMN
C305 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDEFGH I JKLMN
C306 LG-0CN1220F668 CAPACITOR TUBULA(HIGH DIELE) 1200P 16V M X TA26 ABCDEFGHI JKLMN
C307 QET41HM-105 CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABCDEFGHI JKLMN
C308 LG-0CQ1532K409 CAPACITOR,FIXED FILM 0.015UF S 50V J PE TP ABCDEFGH I JKLMN
C309 LG-0CN1210K518 CAPACITOR TUBULA(HIGH DIELE) 120P 50V K B TA26 ABCDEFGH I JKLMN
C310 LG-0CQ1032K409 CAPACITOR,POLYESTER(MYLAR) 0.01UF S 50V J PE TP ABCDEFGH I JKLMN
C311 LG-0CE4765K618 CAPACITOR,AL.ELECTROLYTIC 47UF SR,SV 50V M FL TP 5 ABCDEFGH I JKLMN
C312 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDEFGH I JKLMN
C313 LG-0CQ2232L559 CAPACITOR,POLYESTER 0.022UF S 63V K PP NI TP5 ABCDEFGH I JKLMN
C314 QET41CM-226 CAPACITOR,ELECTROLYTIC 22M SRA 16V M FM5 TP(5) ABCDEFGH I JKLMN
C315 LG-0CE2253K636 CAPACITOR,FIXED ELECTROLYTIC 2.2UF SRE,SE 50V 20% FM5 BP(D) ABCDEFGH I JKLMN
C316 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABCDEFGH I JKLMN
C317 LG-0CN8220F668 CAPACITOR,TUBULAR(HIGH DIELEC) 8200P 16V M X TA26 ABCDEFGHI JKLMN
C318 QET41HM-105 CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABCDEFGHI JKLMN
C319 LG-0CQ1032K409 CAPACITOR,POLYESTER(MYLAR) 0.01UF S 50V J PE TP ABCDEFGH I JKLMN
C320 QET41HM-105 CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABCDEFGHI JKLMN
C321 LG-0CX6800K408 CAPACITOR TUBULA(T.C) 68P 50V J SL TA26 ABCDEFGH I JKLMN
C322 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABCDEFGH I JKLMN
C323 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABCDEFGH I JKLMN
C324 QET41HM-475 CAPACITOR,FIXED ELECTROLYTIC 4.7UF SRA,SS 50V 20% FM5 TP 5 ABCDEFGHI JKLMN
C325 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABCDEFGH I JKLMN
C326 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDEFGH I JKLMN
C327 QET41HM-105 CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABCDEFGHI JKLMN
C328 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDEFGH I JKLMN
C329 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDEFGH I JKLMN
C330 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDEFGHI JKLMN
C331 QET41CM-106 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABCDEFGH I JKLMN
C333 QET41CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) ABCDEFGHI JKLMN
C334 LG-0CN4730K948 CAPACITOR,FIXED TUBULAR(High d 0.047UF D 50V 80%,-20% F(Y5V) ABCDEFGHI JKLMN
C335 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDEFGH I JKLMN
C336 QET41CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) ABCDEFGHI JKLMN
C337 QET41HM-105 CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABCDEFGHI JKLMN
C338 LG-0CN4730K948 CAPACITOR,FIXED TUBULAR(High d 0.047UF D 50V 80%,-20% F(Y5V) ABCDEFGHI JKLMN
C339 QET41HM-105 CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABCDEFGHI JKLMN
C340 LG-0CN4730K948 CAPACITOR,FIXED TUBULAR(High d 0.047UF D 50V 80%,-20% F(Y5V) ABCDEFGHI JKLMN
C341 LG-0CN223AK948 CAPACITOR,TUBULAR(HIGH DIELEC) 0.022UF 50V Z F TA26 S ABCDEFGH I JKLMN
C342 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDEFGHI JKLMN
C343 LG-0CN4730K948 CAPACITOR,FIXED TUBULAR(High d 0.047UF D 50V 80%,-20% F(Y5V) ABCDEFGHI JKLMN
MODEL MARK MODEL MARK MODEL MARK
HR-J285EU A HR-J595MS F HR-J282EU K
HR-J290EU B HR-J295MS G HR-J283EU L
HR-J585EU C HR-J595EK H HR-J582EU M
HR-J590EU D HR-J295EK I HR-J583EU N
HR-J593EU E HR-J293EU J
