6-1
SECTION 6
REPLACEMENT P
ARTS LIST
SAFETY PRECAUTION
Parts identified by the
!
symbol are critical for safety. Replace only with specified part numbers.
BEWARE OF BOGUS PARTS
Parts that do not meet specifications may cause trouble in regard to safety and performance. We recom-
mend that genuine JVC parts be used.
6.1.1
P
ACKING AND
ACCESSOR
Y
ASSEMBL
Y <M1>
The instruction manual to be provided with this product will differ according to the destination.
6.1
EXPLODED VIEW
BA
TTERY
808
BAG
804
P
ACKING
OPTIONAL
P
ARTS
803
806
INSTRUCTION ASSEMBL
Y
CABLE, COAXIAL
810
CABLE ASS'Y
,
RF
801
REMOCON
900
BOX CART
ONX
802
P
ACKING
803
81
1
812
PLUG ASS'Y(YELLOW)
PLUG ASS'Y(RED/WHITE)
821
SCART
CABLE
813
PLUG ASS'Y(BLACK)
102
104
