KD-10A/B/C/E/JS/U
A\ parts are safety assurance parts.
When replacing those parts, make sure to use the specified one.
—~19 —
Ref. No. | Parts No. Parts Name Remarks O'ty
[ 54 VJD3124-002 Escutcheon 1
55
VJD4168-001
Escutcheon
Plate
1
56 TFB313563-01 Plate Nut 3
57
VKY4111-002
Button
Spring
for
Amp
Chassis
1
58
VKL2103-001
Bottom
Cover
1
59 VJF3001-001 Foot 4
60 VJC1018-003 Top Cover 1
61 VYSH110-015 Spacer 1
62 VKL4246-001 Bracket 1
63 | VXL3001-001 Volume Knob (1) KD-10A/C/J {(-002 = KD-10B/E/U)| 2
64
TLT356404-01
Dolby
Label!
1
65 VX04002-001 Lever Knob 3
66 *VYN2031-002HA Name Plate KD-10A 1
" -001HA ie KD-10B 1
aunt -O03HA ue KD-10C 1
aay -O04HA if KD-10E 1
aa -OO5HA is KD-10J 1
* -OO6HA KD-10U 1
67 | VKZ4001-007 Wire Holder for Muting 2
68 VYH1105-002 Chassis 1 |
[ 69 VKL4165-001 Switch Bracket - 1
70 ; OSP2111-011 Power Switch KD-10A/E A 1
i -011BS u KD-10B aN 1
| OSP1110-222 et KD-10C/J A| 1
as -221 ui KD-10U AN 1
71 VKY4125-002 Earth Spring for Top Cover Earth } 1
72 VK2Z4001-011 Wire Holder for Power Cord KD-10A/B/E 1
73 QFA72BM-223 M.P. Capacitor KD-10C, C1 0.022uF A 1
QFH72BM-223 M.M. Capacitor KD-10J, C1 0.022uF AN 1
QFH53AM-223 ui 7 - KD-10U, C1 0.022uF AN 1
74 T47047-001 Capacitor Boot KD-10J/U A 1 |
75 VKL4254-002 Bracket 2
76 VKL4167-001 Trans. Bracket 1
77 VTP54C5-011 Power Transformer KD-10A/E AN 1
| -011BS 7 KD-10B At 1
VTP54A5-011K a. KD-10C/J AN 1
; VTP54U5-011 * KD-10U A 1
78 QMP2500-200 Power Cord KD-10A A 1
QMP9017-007BS ie KD-10B A 1
QMP1200-244 KD-10C/J A 1
QMP3900-244 KD-10E A 1
QMP7600-183 ' KD-10U A 1
79 QHS3876-252 Strain Relief KD-10A/E A 1
-252BS " KD-10B A 1
QHS3056-252 u KD-10C/J/U A 1
80 TAW000504-01 Wire Connector KD-10A/B/E/C AN 2
81 QSS2325-006BS Slide Switch for Voltage Selector KD-10B A 1
° -006 ? ut KD-10A/E A 1
QSRO084-001 Voltage Select Switch KD-10U “AN 1
82 VKL4275-001 Bracket for Voltage Selector KD-10U 1
83 NTB3000S Nut " KD-10B 2
84 *VKL4257-003 Shield Plate 1
85 51739-002 Lug for Shield Plate 1
86 50242-5 Lug for Mecha. Earth 1
87 VKL3109-003 Volume Bracket 1
