JVC KD-DB912BT User Manual

10
ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
CD/USB/iPod
Insert a disc
Eject disc
Label side
The source changes to CD automatically and playback starts.
Connect a USB device
USB device
USB input terminal
USB 2.0 cable*
(commercially available)
The source changes to USB automatically and playback starts.
* Do not leave the cable inside the car when not in use.
Connect an iPod/iPhone
USB input terminal
Accessory of the iPod/iPhone*
iPod/
iPhone
The source changes to iPod USB automatically and playback starts.
• You can also connect iPod/iPhone via Bluetooth. (Page 16)
* Do not leave the cable inside the car when not in use.
Basic operations
Selectable source:
CD/USB/iPod USB or iPod BT
JS_JVC_KD_DB912BT_E_EN_1.indd 10JS_JVC_KD_DB912BT_E_EN_1.indd 10 7/23/2019 4:59:30 PM7/23/2019 4:59:30 PM

JVC KD-DB912BT Specifications

General

DIN size	1 DIN
CD player	Yes
Impedance	4 Ω
Output power	200 W
Product color	Black
Volume control	Rotary
Disc types supported	CD
Audio output channels	4.0 channels
Equalizer bands quantity	13
Maximum power per channel	50 W
Audio formats supported	AAC, SBC
Display type	LCD
USB version	2.0
Bluetooth version	4.2
USB port position	Front
Bluetooth profiles	A2DP, AVRCP
USB connector type	USB Type-A
USB ports quantity	1
Bluetooth functions	Handsfree calling
Package weight	1600 g
AM band range	531 - 1611 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	FM, LW, MW

Weight and Dimensions

Weight	1200 g
