JVC KD-DB912BT User Manual

20
ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Bluetooth®
Default: [XX]
[BT MODE]
[PHONE SELECT] Selects the phone or audio device to connect or disconnect.
“
” appears in front of the device name when connected.
“
” appears in front of the current playback audio device.
• You can connect a maximum of two Bluetooth phones and one Bluetooth
audio device at a time.
[AUDIO SELECT]
[DEVICE DELETE]
1 Turn the volume knob to select a device to delete, then press the knob.
2 Turn the volume knob to select [YES] or [NO], then press the knob.
[PIN CODE EDIT]
(0000)
Changes the PIN code (up to 6 digits).
1 Turn the volume knob to select a number.
2 Press S / T to move the entry position.
Repeat step 1 and step 2 until you finish entering the PIN code.
3 Press the volume knob to confirm.
[RECONNECT]
[ON]: The unit is automatically reconnect when the last connected
Bluetooth device is within the connectable range. ; [OFF]: Cancels.
[AUTO PAIRING]
[ON]: The unit is automatically paired with the supported Bluetooth
device (iPhone/iPod touch) when it is connected through USB input
terminal. Depending on the operating system of the connected device, this
function may not work. ; [OFF]: Cancels.
[INITIALIZE]
[YES]: Initializes all the Bluetooth settings (including stored pairing,
phonebook, and etc.). ; [NO]: Cancels.
[INFORMATION] [MYBTNAME]: Displays the name of your receiver (“KD-DB912BT”). ;
[MYADDRESS]: Shows address of this unit.
Bluetooth compatibility check mode
You can check the connectivity of the supported profile between the
Bluetooth device and the unit.
• Make sure there is no Bluetooth device paired.
1 Press and hold .
“BLUETOOTH” “CHECK MODE” appears. “SEARCH NOW USING
PHONE” “PIN IS 0000” scrolls on the display.
2 Search and select the name of your receiver (“KD-DB912BT”) on the
Bluetooth device within 3minutes.
3 Perform (A), (B) or (C) depending on what appears on the display.
(A) “PAIRING” “XXXXXX” (6-digit passkey): Ensure that the same
passkey appears on the unit and Bluetooth device, then operate the
Bluetooth device to confirm the passkey.
(B) “PAIRING” “PIN IS 0000”: Enter “0000” on the Bluetooth device.
(C) “PAIRING”: Operate the Bluetooth device to confirm pairing.
After pairing is done successfully, “PAIRING OK”
“Device Name” appears
and Bluetooth compatibility check starts.
If “CONNECT NOW USING PHONE” appears, operate the Bluetooth device to
allow phonebook access to continue.
“TESTING” flashes on the display.
JS_JVC_KD_DB912BT_E_EN_1.indd 20JS_JVC_KD_DB912BT_E_EN_1.indd 20 7/23/2019 4:59:32 PM7/23/2019 4:59:32 PM

JVC KD-DB912BT Specifications

General

DIN size	1 DIN
CD player	Yes
Impedance	4 Ω
Output power	200 W
Product color	Black
Volume control	Rotary
Disc types supported	CD
Audio output channels	4.0 channels
Equalizer bands quantity	13
Maximum power per channel	50 W
Audio formats supported	AAC, SBC
Display type	LCD
USB version	2.0
Bluetooth version	4.2
USB port position	Front
Bluetooth profiles	A2DP, AVRCP
USB connector type	USB Type-A
USB ports quantity	1
Bluetooth functions	Handsfree calling
Package weight	1600 g
AM band range	531 - 1611 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	FM, LW, MW

Weight and Dimensions

Weight	1200 g
