3-11
Switch board
(KD-G331,G332,G333,G337)
Block No. [0][2]
Symbol No.
Part No. Part Name Description Local
IC661 PT6523LQ-L LCD DRIVER
IC681 RPM7338-V4 RM.RECEIVER G337BEE,G337SEE
D630 SML-310LT/MN/-X LED
D631 LNJ308G81/1-3/X LED
G331E,G331EU,G331EX,
G331EY,G337SEE
D631 LSQ971/KL/-X LED
G332E,G332EU,G332EX,
G332EY,G333E,G333EU,
G333EX,G333EY,G337BEE
D632 LNJ308G81/1-3/X LED
G331E,G331EU,G331EX,
G331EY,G337SEE
D632 LSQ971/KL/-X LED
G332E,G332EU,G332EX,
G332EY,G333E,G333EU,
G333EX,G333EY,G337BEE
D633 LNJ308G81/1-3/X LED
G331E,G331EU,G331EX,
G331EY,G337SEE
D633 LSQ971/KL/-X LED
G332E,G332EU,G332EX,
G332EY,G333E,G333EU,
G333EX,G333EY,G337BEE
D634 LNJ308G81/1-3/X LED
G331E,G331EU,G331EX,
G331EY,G337SEE
D634 LSQ971/KL/-X LED
G332E,G332EU,G332EX,
G332EY,G333E,G333EU,
G333EX,G333EY,G337BEE
D635 LNJ308G81/1-3/X LED
G331E,G331EU,G331EX,
G331EY,G337SEE
D635 LSQ971/KL/-X LED
G332E,G332EU,G332EX,
G332EY,G333E,G333EU,
G333EX,G333EY,G337BEE
D636 LNJ308G81/1-3/X LED
G331E,G331EU,G331EX,
G331EY,G337SEE
D636 LSQ971/KL/-X LED
G332E,G332EU,G332EX,
G332EY,G333E,G333EU,
G333EX,G333EY,G337BEE
D637 LNJ308G81/1-3/X LED
G331E,G331EU,G331EX,
G331EY,G337SEE
D637 LSQ971/KL/-X LED
G332E,G332EU,G332EX,
G332EY,G333E,G333EU,
G333EX,G333EY,G337BEE
D638 LNJ308G81/1-3/X LED
G331E,G331EU,G331EX,
G331EY,G337SEE
D638 LSQ971/KL/-X LED
G332E,G332EU,G332EX,
G332EY,G333E,G333EU,
G333EX,G333EY,G337BEE
D639 LNJ308G81/1-3/X LED
G331E,G331EU,G331EX,
G331EY,G337SEE
D639 LSQ971/KL/-X LED
G332E,G332EU,G332EX,
G332EY,G333E,G333EU,
G333EX,G333EY,G337BEE
D640 LNJ308G81/1-3/X LED
G331E,G331EU,G331EX,
G331EY,G337SEE
D640 LSQ971/KL/-X LED
G332E,G332EU,G332EX,
G332EY,G333E,G333EU,
G333EX,G333EY,G337BEE
D641 LNJ308G81/1-3/X LED
G331E,G331EU,G331EX,
G331EY,G337SEE
D641 LSQ971/KL/-X LED
G332E,G332EU,G332EX,
G332EY,G333E,G333EU,
G333EX,G333EY,G337BEE
D642 LNJ308G81/1-3/X LED
G331E,G331EU,G331EX,
G331EY,G337SEE
D642 LSQ971/KL/-X LED
G332E,G332EU,G332EX,
G332EY,G333E,G333EU,
G333EX,G333EY,G337BEE
D643 LNJ308G81/1-3/X LED
G331E,G331EU,G331EX,
G331EY,G337SEE
D643 LSQ971/KL/-X LED
G332E,G332EU,G332EX,
G332EY,G333E,G333EU,
G333EX,G333EY,G337BEE
D644 LNJ308G81/1-3/X LED
G331E,G331EU,G331EX,
G331EY,G337SEE
D644 LSQ971/KL/-X LED
G332E,G332EU,G332EX,
G332EY,G333E,G333EU,
G333EX,G333EY,G337BEE
D645 LNJ308G81/1-3/X LED
G331E,G331EU,G331EX,
G331EY,G337SEE
D645 LSQ971/KL/-X LED
G332E,G332EU,G332EX,
G332EY,G333E,G333EU,
G333EX,G333EY,G337BEE
D646 LNJ308G81/1-3/X LED
G331E,G331EU,G331EX,
G331EY,G337SEE
D646 LSQ971/KL/-X LED
G332E,G332EU,G332EX,
G332EY,G333E,G333EU,
G333EX,G333EY,G337BEE
D647 LNJ308G81/1-3/X LED
G331E,G331EU,G331EX,
G331EY,G337SEE
D647 LSQ971/KL/-X LED
G332E,G332EU,G332EX,
G332EY,G333E,G333EU,
G333EX,G333EY,G337BEE
D648 LNJ308G81/1-3/X LED
G331E,G331EU,G331EX,
G331EY,G337SEE
D648 LSQ971/KL/-X LED
G332E,G332EU,G332EX,
G332EY,G333E,G333EU,
G333EX,G333EY,G337BEE
D649
NSPW310BS/
BRST/
LED
D650
NSPW310BS/
BRST/
LED
D661 1SS355W-X DIODE
D661 or MA111-X SI DIODE
D662 UDZW5.1B-X SB DIODE
D662 or MA8051/M/-X Z DIODE
C661 NCB21AK-105X C CAPACITOR 1uF 10V K
C662 NDC31HJ-681X C CAPACITOR 680pF 50V J
C663 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C682 NCB31HK-103X C CAPACITOR 0.01uF 50V K G337BEE,G337SEE
R601 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R602 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R604 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R605 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R606 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R607 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R608 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R609 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R610 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R611 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R612 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R613 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R614 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R615 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R630 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R631 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R633 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R635 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R637 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R639 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R641 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R643 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R645 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R647 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R649 NRS181J-181X MG RESISTOR 180
Ω
1/8W J
R661 NRSA02J-102X MG RESISTOR 1k
Ω
1/10W J
R663 NRSA63J-225X MG RESISTOR 2.2M
Ω
1/16W J
R664 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R665 NRSA63J-513X MG RESISTOR 51k
Ω
1/16W J
R666 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R667 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R668 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R681 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J G337BEE,G337SEE
R682 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J G337BEE,G337SEE
R683 NRSA63J-683X MG RESISTOR 68k
Ω
1/16W J G337BEE,G337SEE
CJ601 QGZ1601K1-12S CONNECTOR (1-12)
JS686 QSW1219-001
ROTARY
ENCODER
S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW
S604 NSW0124-001X TACT SW
S605 NSW0124-001X TACT SW
S606 NSW0124-001X TACT SW
S607 NSW0124-001X TACT SW
S608 NSW0124-001X TACT SW
Symbol No.
Part No. Part Name Description Local
