JVC KD-G331E - Page 38

3-12
Main board (KD-G334,G335,G338)
Block No. [0][3]
S609 NSW0124-001X TACT SW
S610 NSW0124-001X TACT SW
S611 NSW0124-001X TACT SW
S612 NSW0124-001X TACT SW
S613 NSW0124-001X TACT SW
S614 NSW0124-001X TACT SW
S615 NSW0124-001X TACT SW
S616 NSW0124-001X TACT SW
 Symbol No. Part No. Part Name Description Local
 IC1 TEF6601T/V1-X IC
IC161 BD3445FS-X IC
 IC301 TB2904HQ IC = TDA
 IC501 LA6565-X IC
IC581 NJM4565E-X IC
 IC701 JCV8016-2001A IC
 IC702 TMP86CH09NG6N68 IC
IC703 S-80827CNMC-W IC
IC705 74LVC3G04DP-X IC
 IC901 AN34001A REGULATOR IC
Q301 2SD601A/QR/-X TRANSISTOR
Q301 or 2SC3928A/QR/-X TRANSISTOR
Q352 RT2N62M-X TRANSISTOR
Q501 2SA1705/ST/-T TRANSISTOR
Q531 2SA1365/F/-X TRANSISTOR
Q531 or 2SB624/4/-X TRANSISTOR
Q701 RT1N141C-X DIGI TRANSISTOR
Q701 or UN2211-X TRANSISTOR
Q702 RT1P141C-X DIGI TRANSISTOR
Q702 or UN2111-X TRANSISTOR
Q781 RT1P141C-X DIGI TRANSISTOR
Q781 or UN2111-X TRANSISTOR
Q782 RT1P141C-X DIGI TRANSISTOR
Q782 or UN2111-X TRANSISTOR
Q783 RT1P141C-X DIGI TRANSISTOR
Q783 or UN2111-X TRANSISTOR
Q881 RT1N141C-X DIGI TRANSISTOR
Q881 or UN2211-X TRANSISTOR
Q882 RT1P141C-X DIGI TRANSISTOR
Q882 or UN2111-X TRANSISTOR
Q976 2SB709A/QR/-X TRANSISTOR
Q976 or 2SA1530A/QR/-X TRANSISTOR
Q977 RT1N141C-X DIGI TRANSISTOR
Q977 or UN2211-X TRANSISTOR
D301 MA8033-X Z DIODE
D301 or UDZW3.3B-X Z DIODE
D302 CRS03-W SB DIODE
D302 or RB160M-30-X SB DIODE
D302 or MA22D23-X SB DIODE
D303 CRS03-W SB DIODE
D303 or RB160M-30-X SB DIODE
D303 or MA22D23-X SB DIODE
G334UI,G335U,
G335UH,G335UN,
G335UT
D341 MC2836-X DIODE
D341 or MA152WA-X DIODE
D501 1A3G-T1 SI DIODE
D701 1SS355W-X DIODE
D701 or MA111-X SI DIODE
D782 MA8100/M/-X Z DIODE
D782 or UDZW10B-X Z DIODE
D783 MC2836-X DIODE
D783 or MA152WA-X DIODE
D851 RB160M-30-X SB DIODE
D851 or CRS03-W SB DIODE
D851 or MA22D23-X SB DIODE
D852 RB160M-30-X SB DIODE
D852 or CRS03-W SB DIODE
 Symbol No. Part No. Part Name Description Local
D852 or MA22D23-X SB DIODE
G334UI,G335U,
G335UH,G335UN,
G335UT
 D901 1N5401-TU-15 SI DIODE
 D901 or 1N5401-F64 SI DIODE
D903 CRS03-W SB DIODE
D903 or RB160M-30-X SB DIODE
D903 or MA22D23-X SB DIODE
D904 CRS03-W SB DIODE
D904 or RB160M-30-X SB DIODE
D904 or MA22D23-X SB DIODE
C1 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2 NDC31HJ-101X C CAPACITOR 100pF 50V J
C3 NCB31HK-102X C CAPACITOR 1000pF 50V K
C4 NCB31AK-224X C CAPACITOR 0.22uF 10V K
C5 NDC31HJ-150X C CAPACITOR 15pF 50V J
C6 NDC31HJ-220X C CAPACITOR 22pF 50V J
C7 NDC31HJ-220X C CAPACITOR 22pF 50V J
C10 NCB21AK-105X C CAPACITOR 1uF 10V K
C11 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C12 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C13 NCB21AK-105X C CAPACITOR 1uF 10V K
C14 NCB31AK-224X C CAPACITOR 0.22uF 10V K
C15 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C16 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C17 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C18 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C19 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C21 NDC31HJ-120X C CAPACITOR 12pF 50V J
C22 NDC31HJ-120X C CAPACITOR 12pF 50V J
C23 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C24 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C25 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C26 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C27 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C161 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C166 NCB31AK-224X C CAPACITOR 0.22uF 10V K
C167 NCB31AK-224X C CAPACITOR 0.22uF 10V K
C168 QTE1A57-107Z E CAPACITOR 100uF 10V
C169 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C171 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C173 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C174 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C181 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C186 NCB31AK-224X C CAPACITOR 0.22uF 10V K
C187 NCB31AK-224X C CAPACITOR 0.22uF 10V K
C188 QTE1C57-106Z E CAPACITOR 10uF 16V
C191 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C193 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C194 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C301 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C302 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C303 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C304 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C312 NDC31HJ-101X C CAPACITOR 100pF 50V J
C313 NDC31HJ-101X C CAPACITOR 100pF 50V J
C314 NDC31HJ-101X C CAPACITOR 100pF 50V J
C315 NDC31HJ-101X C CAPACITOR 100pF 50V J
C316 NCB21AK-105X C CAPACITOR 1uF 10V K
C318 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C506 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C507 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C508 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C509 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C510 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C531 NDC31HJ-470X C CAPACITOR 47pF 50V J
C532 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C533 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C534 NCB31HK-222X C CAPACITOR 2200pF 50V K
C535 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C536 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C537 NCB31HK-472X C CAPACITOR 4700pF 50V K
C538 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C539 NCB31AK-154X C CAPACITOR 0.15uF 10V K
C540 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C541 NDC31HJ-680X C CAPACITOR 68pF 50V J
C542 NCB31HK-103X C CAPACITOR 0.01uF 50V K
 Symbol No. Part No. Part Name Description Local
