20
ESPAÑOL
Códigos PTY
NEWS: Noticias
AFFAIRS: Programas temáticos que van de
noticias a asuntos de actualidad
INFO: Programas que ofrecen consejos
sobre una amplia variedad de
temas
SPORT: Eventos deportivos
EDUCATE: Programas educacionales
DRAMA: Radioteatro
CULTURE: Programas sobre cultura
nacional o regional
SCIENCE: Programas sobre ciencias
naturales y tecnología
VARIED: Otros programas tales como
comedias o ceremonias
POP M: Música Pop
ROCK M: Música Rock
EASY M: Música fácil de escuchar
LIGHT M: Música ligera
CLASSICS: Música clásica
OTHER M: Otras músicas
WEATHER: Información de pronóstico del
tiempo
FINANCE: Informes sobre comercio,
mercadeo, mercado de
acciones, etc.
CHILDREN: Programas de entretenimiento
infantil
SOCIAL: Programas sobre actividades
sociales
RELIGION: Programas que tratan de
cualquier aspecto de las
creencias o fe, o naturaleza de
la existencia o ética
PHONE IN: Programas en los cuales las
personas pueden expresar sus
opiniones por teléfono o en un
foro público
TRAVEL: Programas acerca de destinos
de viaje, excursiones e ideas y
oportunidades para viajes
LEISURE: Programas concernientes con
actividades recreativas tales
como jardinería, cocina, pesca,
etc.
JAZZ: Música de jazz
COUNTRY: Música country
NATION M: Música popular actual de otras
naciones o regiones en el
idioma de ese país
OLDIES: Música pop clásica
FOLK M: Música folklórica
DOCUMENT: Programas que presentan
hechos reales, presentados en
estilo investigación
El mismo programa puede ser recibido en frecuencias diferentes.
Programa 1
transmitiendo
en frecuencia A
Programa 1
transmitiendo
en frecuencia E
Programa 1
transmitiendo
en frecuencia B
Programa 1
transmitiendo
en frecuencia D
Programa 1
transmitiendo
en frecuencia C
SP14-20_G801_G701[E_EX]f.p65 29/12/03, 3:45 PM20

Table of Contents

Other manuals for JVC KD-G801

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the JVC KD-G801 and is the answer not in the manual?

JVC KD-G801 Specifications

KD-G801

Audio Amplifier Section IconAudio Amplifier Section
maximum power output (front)50 W per channel
maximum power output (rear)50 W per channel
continuous power output (RMS, front)19 W per channel into 4 Ω
continuous power output (RMS, rear)19 W per channel into 4 Ω
load impedance4 Ω (4 Ω to 8 Ω allowance)
equalizer control range (low)±12 dB (60 Hz, 80 Hz, 100 Hz, 120 Hz)
equalizer control range (mid)±12 dB
equalizer control range (high)±12 dB (8 kHz, 10 kHz, 12 kHz, 15 kHz)
frequency response40 Hz to 20 000 Hz
signal-to-noise ratio70 dB
line-out level/impedance5.0 V/20 kΩ load (full scale)
subwoofer-out level/impedance2.0 V/20 kΩ load (full scale)
output impedance1 kΩ
CD Player Section IconCD Player Section
operating voltageDC 14.4 V (11 V to 16 V allowance)
allowable operating temperature0°C to +40°C
dimensions (installation size)182 mm × 52 mm × 159 mm
dimensions (panel size)188 mm × 58 mm × 12 mm
mass1.5 kg
frequency response5 Hz to 20 000 Hz
dynamic range96 dB
signal-to-noise ratio98 dB
Tuner Section IconTuner Section
frequency range (FM)87.5 MHz to 108.0 MHz
frequency range (AM MW)522 kHz to 1 620 kHz
frequency range (AM LW)144 kHz to 279 kHz
usable sensitivity (FM)11.3 dBf (1.0 µV/75 Ω)
50 dB quieting sensitivity (FM)16.3 dBf (1.8 µV/75 Ω)
alternate channel selectivity (FM, 400 kHz)65 dB
frequency response (FM)40 Hz to 15 000 Hz
stereo separation (FM)30 dB
capture ratio (FM)1.5 dB
sensitivity (MW)20 µV
selectivity (MW)35 dB
sensitivity (LW)50 µV

KD-G701

Audio Amplifier Section IconAudio Amplifier Section
maximum power output (front)50 W per channel
maximum power output (rear)50 W per channel
continuous power output (RMS, front)19 W per channel into 4 Ω
continuous power output (RMS, rear)19 W per channel into 4 Ω
load impedance4 Ω (4 Ω to 8 Ω allowance)
equalizer control range (low)±12 dB (60 Hz, 80 Hz, 100 Hz, 120 Hz)
equalizer control range (mid)±12 dB
equalizer control range (high)±12 dB (8 kHz, 10 kHz, 12 kHz, 15 kHz)
frequency response40 Hz to 20 000 Hz
signal-to-noise ratio70 dB
line-out level/impedance2.0 V/20 kΩ load (full scale)
output impedance1 kΩ
CD Player Section IconCD Player Section
operating voltageDC 14.4 V (11 V to 16 V allowance)
allowable operating temperature0°C to +40°C
dimensions (installation size)182 mm × 52 mm × 159 mm
dimensions (panel size)188 mm × 58 mm × 12 mm
mass1.5 kg
frequency response5 Hz to 20 000 Hz
dynamic range96 dB
signal-to-noise ratio98 dB
Tuner Section IconTuner Section
frequency range (FM)87.5 MHz to 108.0 MHz
frequency range (AM MW)522 kHz to 1 620 kHz
frequency range (AM LW)144 kHz to 279 kHz
usable sensitivity (FM)11.3 dBf (1.0 µV/75 Ω)
50 dB quieting sensitivity (FM)16.3 dBf (1.8 µV/75 Ω)
alternate channel selectivity (FM, 400 kHz)65 dB
frequency response (FM)40 Hz to 15 000 Hz
stereo separation (FM)30 dB
capture ratio (FM)1.5 dB
sensitivity (MW)20 µV
selectivity (MW)35 dB
sensitivity (LW)50 µV
