Audio Amplifier Section| maximum power output (front) | 50 W per channel |
|---|---|
| maximum power output (rear) | 50 W per channel |
| continuous power output (RMS, front) | 19 W per channel into 4 Ω |
| continuous power output (RMS, rear) | 19 W per channel into 4 Ω |
| load impedance | 4 Ω (4 Ω to 8 Ω allowance) |
| equalizer control range (low) | ±12 dB (60 Hz, 80 Hz, 100 Hz, 120 Hz) |
| equalizer control range (mid) | ±12 dB |
| equalizer control range (high) | ±12 dB (8 kHz, 10 kHz, 12 kHz, 15 kHz) |
| frequency response | 40 Hz to 20 000 Hz |
| signal-to-noise ratio | 70 dB |
| line-out level/impedance | 5.0 V/20 kΩ load (full scale) |
| subwoofer-out level/impedance | 2.0 V/20 kΩ load (full scale) |
| output impedance | 1 kΩ |
CD Player Section| operating voltage | DC 14.4 V (11 V to 16 V allowance) |
|---|---|
| allowable operating temperature | 0°C to +40°C |
| dimensions (installation size) | 182 mm × 52 mm × 159 mm |
| dimensions (panel size) | 188 mm × 58 mm × 12 mm |
| mass | 1.5 kg |
| frequency response | 5 Hz to 20 000 Hz |
| dynamic range | 96 dB |
| signal-to-noise ratio | 98 dB |
Tuner Section| frequency range (FM) | 87.5 MHz to 108.0 MHz |
|---|---|
| frequency range (AM MW) | 522 kHz to 1 620 kHz |
| frequency range (AM LW) | 144 kHz to 279 kHz |
| usable sensitivity (FM) | 11.3 dBf (1.0 µV/75 Ω) |
| 50 dB quieting sensitivity (FM) | 16.3 dBf (1.8 µV/75 Ω) |
| alternate channel selectivity (FM, 400 kHz) | 65 dB |
| frequency response (FM) | 40 Hz to 15 000 Hz |
| stereo separation (FM) | 30 dB |
| capture ratio (FM) | 1.5 dB |
| sensitivity (MW) | 20 µV |
| selectivity (MW) | 35 dB |
| sensitivity (LW) | 50 µV |
Audio Amplifier Section| maximum power output (front) | 50 W per channel |
|---|---|
| maximum power output (rear) | 50 W per channel |
| continuous power output (RMS, front) | 19 W per channel into 4 Ω |
| continuous power output (RMS, rear) | 19 W per channel into 4 Ω |
| load impedance | 4 Ω (4 Ω to 8 Ω allowance) |
| equalizer control range (low) | ±12 dB (60 Hz, 80 Hz, 100 Hz, 120 Hz) |
| equalizer control range (mid) | ±12 dB |
| equalizer control range (high) | ±12 dB (8 kHz, 10 kHz, 12 kHz, 15 kHz) |
| frequency response | 40 Hz to 20 000 Hz |
| signal-to-noise ratio | 70 dB |
| line-out level/impedance | 2.0 V/20 kΩ load (full scale) |
| output impedance | 1 kΩ |
CD Player Section| operating voltage | DC 14.4 V (11 V to 16 V allowance) |
|---|---|
| allowable operating temperature | 0°C to +40°C |
| dimensions (installation size) | 182 mm × 52 mm × 159 mm |
| dimensions (panel size) | 188 mm × 58 mm × 12 mm |
| mass | 1.5 kg |
| frequency response | 5 Hz to 20 000 Hz |
| dynamic range | 96 dB |
| signal-to-noise ratio | 98 dB |
Tuner Section| frequency range (FM) | 87.5 MHz to 108.0 MHz |
|---|---|
| frequency range (AM MW) | 522 kHz to 1 620 kHz |
| frequency range (AM LW) | 144 kHz to 279 kHz |
| usable sensitivity (FM) | 11.3 dBf (1.0 µV/75 Ω) |
| 50 dB quieting sensitivity (FM) | 16.3 dBf (1.8 µV/75 Ω) |
| alternate channel selectivity (FM, 400 kHz) | 65 dB |
| frequency response (FM) | 40 Hz to 15 000 Hz |
| stereo separation (FM) | 30 dB |
| capture ratio (FM) | 1.5 dB |
| sensitivity (MW) | 20 µV |
| selectivity (MW) | 35 dB |
| sensitivity (LW) | 50 µV |
