24
ESPAÑOL
Prohibición de la expulsión
del disco
Es posible inhibir la expulsión del disco y
bloquearlo dentro de la ranura de carga.
Mientras pulsa CD/CD-CH (para
KD-G801) o CD (para KD-G701), pulse y
mantenga pulsado durante más
de 2 segundos.
NO EJECT parpadea en la pantalla durante
aproximadamente 5 segundos, y el disco queda
bloqueado para que no pueda expulsarse.
Para cancelar la prohibición y
desbloquear el disco
Mientras pulsa CD/CD-CH (para KD-G801) o
CD (para KD-G701), pulse y mantenga pulsado
otra vez durante más de 2 segundos.
EJECT OK parpadea en la pantalla durante
aproximadamente 5 segundos, y el disco queda
desbloqueado.
Reproducción del CD Text
En el CD Text, se ha grabado cierta información
relacionada con el disco (el título del disco, su
ejecutante y título de la pista).
Esta información de CD Text será mostrada
automáticamente cuando se reproduce un CD
Text.
Para cambiar manualmente la
información de CD Text, seleccione el
modo de visualización de texto mientras
se reproduce un CD Text.
Pulse DISP (pantalla)
repetidamente.
Cada vez que pulsa el botón, la
pantalla cambia de la manera
siguiente:
Notas:
En la pantalla se visualizan simultáneamente hasta
12 caracteres, efectuándose el desplazamiento
secuencial si hay más de 12.
Consulte también “Para seleccionar el modo de
desplazamiento—SCROLL MODE” en la página
37.
Algunos caracteres o símbolos no serán mostrados
(aparecerán en blanco o sustituidos por otros) en la
pantalla.
Si no se ha asignado un nombre al CD, aparecerá
“NO NAME”. Para asignar un nombre a un CD de
audio, consulte la página 39.
Si no se ha grabado el título del disco/ejecutante o
el título de la pista para el CD Text, aparecerá
“NO NAME”.
Cuando aparece el título de la pista, el indicador
TRACK y el número de la pista actual también
aparecen en la pare inferior de la pantalla.
(Para KD-G801)
(Para KD-G701)
o
Título del disco / ejecutante
Título de la pista
( se enciende en la pantalla)
Tiempo de reproducción
transcurrido y número
de pista actual
SP21-24_G801_G701[E_EX]f.p65 6/1/04, 6:33 PM24

Table of Contents

Other manuals for JVC KD-G801

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the JVC KD-G801 and is the answer not in the manual?

JVC KD-G801 Specifications

KD-G801

Audio Amplifier Section IconAudio Amplifier Section
maximum power output (front)50 W per channel
maximum power output (rear)50 W per channel
continuous power output (RMS, front)19 W per channel into 4 Ω
continuous power output (RMS, rear)19 W per channel into 4 Ω
load impedance4 Ω (4 Ω to 8 Ω allowance)
equalizer control range (low)±12 dB (60 Hz, 80 Hz, 100 Hz, 120 Hz)
equalizer control range (mid)±12 dB
equalizer control range (high)±12 dB (8 kHz, 10 kHz, 12 kHz, 15 kHz)
frequency response40 Hz to 20 000 Hz
signal-to-noise ratio70 dB
line-out level/impedance5.0 V/20 kΩ load (full scale)
subwoofer-out level/impedance2.0 V/20 kΩ load (full scale)
output impedance1 kΩ
CD Player Section IconCD Player Section
operating voltageDC 14.4 V (11 V to 16 V allowance)
allowable operating temperature0°C to +40°C
dimensions (installation size)182 mm × 52 mm × 159 mm
dimensions (panel size)188 mm × 58 mm × 12 mm
mass1.5 kg
frequency response5 Hz to 20 000 Hz
dynamic range96 dB
signal-to-noise ratio98 dB
Tuner Section IconTuner Section
frequency range (FM)87.5 MHz to 108.0 MHz
frequency range (AM MW)522 kHz to 1 620 kHz
frequency range (AM LW)144 kHz to 279 kHz
usable sensitivity (FM)11.3 dBf (1.0 µV/75 Ω)
50 dB quieting sensitivity (FM)16.3 dBf (1.8 µV/75 Ω)
alternate channel selectivity (FM, 400 kHz)65 dB
frequency response (FM)40 Hz to 15 000 Hz
stereo separation (FM)30 dB
capture ratio (FM)1.5 dB
sensitivity (MW)20 µV
selectivity (MW)35 dB
sensitivity (LW)50 µV

KD-G701

Audio Amplifier Section IconAudio Amplifier Section
maximum power output (front)50 W per channel
maximum power output (rear)50 W per channel
continuous power output (RMS, front)19 W per channel into 4 Ω
continuous power output (RMS, rear)19 W per channel into 4 Ω
load impedance4 Ω (4 Ω to 8 Ω allowance)
equalizer control range (low)±12 dB (60 Hz, 80 Hz, 100 Hz, 120 Hz)
equalizer control range (mid)±12 dB
equalizer control range (high)±12 dB (8 kHz, 10 kHz, 12 kHz, 15 kHz)
frequency response40 Hz to 20 000 Hz
signal-to-noise ratio70 dB
line-out level/impedance2.0 V/20 kΩ load (full scale)
output impedance1 kΩ
CD Player Section IconCD Player Section
operating voltageDC 14.4 V (11 V to 16 V allowance)
allowable operating temperature0°C to +40°C
dimensions (installation size)182 mm × 52 mm × 159 mm
dimensions (panel size)188 mm × 58 mm × 12 mm
mass1.5 kg
frequency response5 Hz to 20 000 Hz
dynamic range96 dB
signal-to-noise ratio98 dB
Tuner Section IconTuner Section
frequency range (FM)87.5 MHz to 108.0 MHz
frequency range (AM MW)522 kHz to 1 620 kHz
frequency range (AM LW)144 kHz to 279 kHz
usable sensitivity (FM)11.3 dBf (1.0 µV/75 Ω)
50 dB quieting sensitivity (FM)16.3 dBf (1.8 µV/75 Ω)
alternate channel selectivity (FM, 400 kHz)65 dB
frequency response (FM)40 Hz to 15 000 Hz
stereo separation (FM)30 dB
capture ratio (FM)1.5 dB
sensitivity (MW)20 µV
selectivity (MW)35 dB
sensitivity (LW)50 µV
