34
ITALIANO
Valori
Cfr.
Spie Valori/voci selezionabili predisposti
pagina
in fabbrica
DEMO MODE Demo del display
CLOCK HOUR Regolazione dell’ora
CLOCK MINUTE Regolazione dei
minuti
CLOCK24H/12H
Visualizzazione
dell’ora sulla gamma
delle 24 o delle 12 ore
AUTO ADJUST Predisposizione
automatica
dell’orologio
CLOCK DISP Visualizzazione
dell’orologio
AF-REG
Frequenza alternativa/
Ricezione regionale
ALTRE FUNZIONI PRINCIPALI
Modifica delle impostazioni
generali (PSM)
Per modificare gli elementi elencati nella tabella
di seguito e a pagina 35, utilizzare il comando
PSM (modalità impostazione preferita).
Procedura di base
1
Tenere premuto SEL (seleziona) per
almeno 2 secondi, in modo che uno
dei componenti PSM appaia sul
display. (Cfr. di seguito e a pagina
35).
2
Selezionare la voce PSM che
s’intende regolare.
3
Regolare la voce PSM selezionata
qui sopra.
4
Ripetere i punti
2
e
3
per regolare
gli altri componenti PSM, se
necessario.
5
Fine dell’impostazione.
0 — 23 (1 — 12)
00 — 59
9
Le voci modalità di impostazioni preferite (PSM)
Per informazioni dettagliate sul funzionamento di ciascuna voce PSM, fare riferimento alle pagine
elencate nella tabella.
DEMO OFF DEMO ON DEMO ON 8
0 (0:00)
00 (0:00)
CLOCK 12HOUR CLOCK 24HOUR
CLOCK
24HOUR
CLK DISP OFF CLK DISP ON CLK DISP ON 36
14, 15
ADJUST OFF ADJUST ON ADJUST ON 19
AF ON
AF ON
AF REG
AF OFF*
1
*
1
Solo per KD-G801: Visualizzato soltanto quando “DAB AF” è impostato su “OFF”.
IT34-41_G801_G701[E_EX]f.p65 6/1/04, 11:00 AM34

Table of Contents

Other manuals for JVC KD-G801

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the JVC KD-G801 and is the answer not in the manual?

JVC KD-G801 Specifications

KD-G801

Audio Amplifier Section IconAudio Amplifier Section
maximum power output (front)50 W per channel
maximum power output (rear)50 W per channel
continuous power output (RMS, front)19 W per channel into 4 Ω
continuous power output (RMS, rear)19 W per channel into 4 Ω
load impedance4 Ω (4 Ω to 8 Ω allowance)
equalizer control range (low)±12 dB (60 Hz, 80 Hz, 100 Hz, 120 Hz)
equalizer control range (mid)±12 dB
equalizer control range (high)±12 dB (8 kHz, 10 kHz, 12 kHz, 15 kHz)
frequency response40 Hz to 20 000 Hz
signal-to-noise ratio70 dB
line-out level/impedance5.0 V/20 kΩ load (full scale)
subwoofer-out level/impedance2.0 V/20 kΩ load (full scale)
output impedance1 kΩ
CD Player Section IconCD Player Section
operating voltageDC 14.4 V (11 V to 16 V allowance)
allowable operating temperature0°C to +40°C
dimensions (installation size)182 mm × 52 mm × 159 mm
dimensions (panel size)188 mm × 58 mm × 12 mm
mass1.5 kg
frequency response5 Hz to 20 000 Hz
dynamic range96 dB
signal-to-noise ratio98 dB
Tuner Section IconTuner Section
frequency range (FM)87.5 MHz to 108.0 MHz
frequency range (AM MW)522 kHz to 1 620 kHz
frequency range (AM LW)144 kHz to 279 kHz
usable sensitivity (FM)11.3 dBf (1.0 µV/75 Ω)
50 dB quieting sensitivity (FM)16.3 dBf (1.8 µV/75 Ω)
alternate channel selectivity (FM, 400 kHz)65 dB
frequency response (FM)40 Hz to 15 000 Hz
stereo separation (FM)30 dB
capture ratio (FM)1.5 dB
sensitivity (MW)20 µV
selectivity (MW)35 dB
sensitivity (LW)50 µV

KD-G701

Audio Amplifier Section IconAudio Amplifier Section
maximum power output (front)50 W per channel
maximum power output (rear)50 W per channel
continuous power output (RMS, front)19 W per channel into 4 Ω
continuous power output (RMS, rear)19 W per channel into 4 Ω
load impedance4 Ω (4 Ω to 8 Ω allowance)
equalizer control range (low)±12 dB (60 Hz, 80 Hz, 100 Hz, 120 Hz)
equalizer control range (mid)±12 dB
equalizer control range (high)±12 dB (8 kHz, 10 kHz, 12 kHz, 15 kHz)
frequency response40 Hz to 20 000 Hz
signal-to-noise ratio70 dB
line-out level/impedance2.0 V/20 kΩ load (full scale)
output impedance1 kΩ
CD Player Section IconCD Player Section
operating voltageDC 14.4 V (11 V to 16 V allowance)
allowable operating temperature0°C to +40°C
dimensions (installation size)182 mm × 52 mm × 159 mm
dimensions (panel size)188 mm × 58 mm × 12 mm
mass1.5 kg
frequency response5 Hz to 20 000 Hz
dynamic range96 dB
signal-to-noise ratio98 dB
Tuner Section IconTuner Section
frequency range (FM)87.5 MHz to 108.0 MHz
frequency range (AM MW)522 kHz to 1 620 kHz
frequency range (AM LW)144 kHz to 279 kHz
usable sensitivity (FM)11.3 dBf (1.0 µV/75 Ω)
50 dB quieting sensitivity (FM)16.3 dBf (1.8 µV/75 Ω)
alternate channel selectivity (FM, 400 kHz)65 dB
frequency response (FM)40 Hz to 15 000 Hz
stereo separation (FM)30 dB
capture ratio (FM)1.5 dB
sensitivity (MW)20 µV
selectivity (MW)35 dB
sensitivity (LW)50 µV
