KD-LH3101
3-9
Front board
Block No. [0][2][0][0]
R989 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R992 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R993 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R994 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R995 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R996 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R997 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R998 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R999 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
L1 NQL114K-100X COIL 10uH K
L701 NQL114K-470X INDUCITOR 47uH K
L702 NQL114K-470X INDUCITOR 47uH K
L753 NQL114K-470X INDUCITOR 47uH K
L901 QQR1378-001 CHOKE COIL
L921 NQLZ007-151X COIL 150uH
L922 NQL114M-4R7X COIL 4.7uH M
BZ795 QAN0023-001Z BUZZER
CN131 QGA2006C1-04 CONNECTOR W-B (1-4)
CN132 QGA2006F1-02 CONNECTOR W-B (1-2)
CN601 QGB2027M4-22S CONNECTOR B-B (1-22)
CN701 QNZ0605-001 CAR CONNECTOR
CN901 QNZ0112-001 CAR CONNECTOR
CN902 QNZ0095-001 CONNECTOR
J1 QNB0100-002 CAR ANT JACK
J121 QNN0490-001 PIN JACK
PP1 QZW0010-001 STYLE PIN
PP2 QZW0010-001 STYLE PIN
S701 QSW0451-001 DETECT SW
S702 QSW0451-001 DETECT SW
S703 QSQ1A11-V06Z TACT SW I/M
TU1 QAU0203-002 TUNER
X51 QAX0761-001Z CRYSTAL
X701 QAX0617-001Z CRYSTAL 12.500MHz
X702 QAX0401-001 CRYSTAL 32.768KHz
Symbol No.
Part No. Part Name Description Local
IC801 MN102H60KCG IC
IC802 LH28F160BJHET92 IC (FLASH ROM)
IC803 IC-PST3424U-X IC
IC804 NJU7241F33-X IC
IC805 RPM6938-SV4 IC
Q401 UN2211-X TRANSISTOR
Q402 UN2211-X TRANSISTOR
Q403 UN2211-X TRANSISTOR
Q404 UN2211-X TRANSISTOR
Q405 UN2211-X TRANSISTOR
Q406 UN2211-X TRANSISTOR
Q407 UN2211-X TRANSISTOR
Q408 2SD601A/R/-X TRANSISTOR
Q409 2SD601A/R/-X TRANSISTOR
Q410 2SD601A/R/-X TRANSISTOR
Q411 2SD601A/R/-X TRANSISTOR
Q412 2SD601A/R/-X TRANSISTOR
Q413 2SD601A/R/-X TRANSISTOR
Q414 2SD601A/R/-X TRANSISTOR
Q415 2SD601A/R/-X TRANSISTOR
Q416 2SD601A/R/-X TRANSISTOR
Q417 2SD601A/R/-X TRANSISTOR
Q418 2SD601A/R/-X TRANSISTOR
Q419 2SD601A/R/-X TRANSISTOR
Q420 2SD601A/R/-X TRANSISTOR
Q421 2SD601A/R/-X TRANSISTOR
Q422 2SD601A/R/-X TRANSISTOR
Q423 2SD601A/R/-X TRANSISTOR
Q424 2SD601A/R/-X TRANSISTOR
Q425 2SD601A/R/-X TRANSISTOR
Q428 2SD601A/R/-X TRANSISTOR
Symbol No.
Part No. Part Name Description Local
Q801 2SB709A/QR/-X TRANSISTOR
Q802 2SB709A/QR/-X TRANSISTOR
Q803 2SD601A/R/-X TRANSISTOR
Q804 UN2111-X TRANSISTOR
D401 MA152WK-X SI DIODE
D402 SML-310LT/MN/-X LED
D403 SML-310LT/MN/-X LED
D405 SML-310LT/MN/-X LED
D406 SML-310LT/MN/-X LED
D407 SML-310LT/MN/-X LED
D408 SML-310LT/MN/-X LED
D409 SML-310LT/MN/-X LED
D410 SML-310LT/MN/-X LED
D411 SML-310LT/MN/-X LED
D412 SML-310LT/MN/-X LED
D413 SML310BAT/JKL-X LED
D414 SML310BAT/JKL-X LED
D415 SML-310LT/MN/-X LED
D416 SML-310LT/MN/-X LED
D417 SML-310LT/MN/-X LED
D418 SML-310LT/MN/-X LED
D419 SML-310LT/MN/-X LED
D420 SML-310LT/MN/-X LED
D421 SML-310LT/MN/-X LED
D422 SML-310LT/MN/-X LED
D423 UDZS6.2B-X Z DIODE
D424 UDZS6.2B-X Z DIODE
D425 UDZS6.2B-X Z DIODE
D426 UDZS6.2B-X Z DIODE
D427 UDZS6.2B-X Z DIODE
D428 UDZS6.2B-X Z DIODE
D429 UDZS6.2B-X Z DIODE
D430 UDZS6.2B-X Z DIODE
D431 UDZS6.2B-X Z DIODE
D435 NSPB310A/WRST/ LED
D436 NSPB310A/WRST/ LED
D451 NSCM315C-W LED
D452 NSCM315C-W LED
D453 NSCM315C-W LED
D801 MA152WK-X SI DIODE
D803 1SS355-X SI DIODE
D804 UDZS6.2B-X Z DIODE
D805 UDZS6.2B-X Z DIODE
D806 UDZS6.2B-X Z DIODE
D807 UDZS6.2B-X Z DIODE
D808 UDZS6.2B-X Z DIODE
D809 UDZS6.2B-X Z DIODE
D810 UDZS6.2B-X Z DIODE
D811 UDZS6.2B-X Z DIODE
D812 UDZS6.2B-X Z DIODE
C451 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C452 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C453 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C454 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C455 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C456 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C457 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C458 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C459 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C801 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C802 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C804 NCS31HJ-471X C CAPACITOR 470pF 50V J
C805 NCS31HJ-471X C CAPACITOR 470pF 50V J
C806 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C807 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C808 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C809 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C810 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C811 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C812 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C813 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C814 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C815 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C816 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C817 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C818 NCB31EK-473X C CAPACITOR 0.047uF 25V K
