17ENGLISH
Category Menu item Selectable setting, [Initial: Underlined]
AUDIO
SUB.W FREQ *
8
Subwoofer cutoff
frequency
• LOW
• MID
• HIGH
: Frequencies lower than 72 Hz are sent to the
subwoofer.
: Frequencies lower than 111 Hz are sent to
the subwoofer.
: Frequencies lower than 157 Hz are sent to
the subwoofer.
SUB.W LEVEL *
8
Subwoofer level
SUB.W 00 —
SUB.W 08
[SUB.W 04]
: Adjust the subwoofer output level.
BEEP
Keytouch tone
• BEEP ON
• BEEP OFF
: Activates the keypress tone.
: Deactivates the keypress tone.
TEL MUTING
Telephone
muting
• MUTING 1/
MUTING 2
• MUTING OFF
: Select either one which mutes the sounds
while using a mobile phone.
: Cancels.
AMP GAIN *
9
Amplifier gain
control
• LOW POWER
• HIGH POWER
: VOLUME 00 – VOLUME 30 (Select if the
maximum power of each speaker is less than
50 W to prevent damaging the speakers.)
: VOLUME 00 – VOLUME 50
SRC SELECT
AM *
10
AM station
• AM ON
• AM OFF
: Enable “AM” in source selection.
: Disable “AM” in source selection.
AUX IN *
11
Auxiliary input
• AUX ON
• AUX OFF
: Enable “AUX IN” in source selection.
: Disable “AUX IN” in source selection.
*
8
Displayed only when <L/O MODE> is set to <SUB.W>.
*
9
The volume level automatically changes to “VOLUME 30” if you change to <LOW POWER> with the
volume level set higher than “VOLUME 30.”
*
10
Displayed only when any source other than “AM” is selected.
*
11
Displayed only when any source other than “AUX IN“ is selected.
EN12-19_KD-R511_003A_f.indd 17EN12-19_KD-R511_003A_f.indd 17 12/10/09 5:01:02 PM12/10/09 5:01:02 PM

JVC KD-R511 Specifications

General

MP3 playback	Yes
Tuner type	HS-IV
FM band range	87.5 - 108 MHz
LW band range	144 - 279 kHz
Output power	200 W
Product color	Black
Ready for iPod	No
Frequency range	5 - 20000 Hz
Equalizer bands quantity	3
Signal-to-Noise Ratio (SNR)	98 dB
File type	MP3/WMA
Key illumination color	Green

Weight and Dimensions

Dimensions (WxDxH)	181.6 x 159.6 x 51.6 mm
