JVC KD-SX8250 Service Manual

3-15
KD-SX8250/KD-SX780
Item
Parts number Parts name Area
A
Parts list (Packing)
Q'ty
Description
Block No. M3MM
P 1 FSPG4002-001
POLY BAG
1
FOR INST BOOK
P 2 QPA00801205
POLY BAG
1
FOR SCREW KIT
P 3 FSYH4036-068
SHEET
1
MIRAMA SHEET
P 4 QPA01003003
POLY BAG
1
FOR HARD CASE
P 5 QPC03004315P
POLY BAG
1
FOR SET
P 6 GE30407-024A
PACKING CASE
1
KD-SX8250
GE30407-026A
PACKING CASE
1
KD-SX780
P 7 GE10047-001A
ESP CUSHION
2
Item
Parts number Parts name Area
A
Parts list (Accessories)
Q'ty
Description
Block No. M5MM
A 1 GET0071-001B
INST BOOK
1
ENG SPA FRE
A 2 GET0071-002A
INSTALL MANUAL
1
ENG SPA FRE
A 3 GET0094-001A
CAUTION SHEET
1
RESET CAUSTION
A 4 BT-51018-2
WARRANTY CARD
1
KD-SX780
BT-51029-1
WARRANTY CARD
1
KD-SX8250
A 5 LVT0717-001B
TROUBLE SHEET(C
1
A 6 BT-52004-2
WARRANTY CARD
1
KD-SX780
BT-52005-1
WARRANTY CARD
1
KD-SX8250
A 7 BT-51028-1
REGISTER CARD
1
KD-SX8250
BT-51020-2
REGISTER CARD
1
KD-SX780
A 8 BT-20071B
JVC CENTER LIST
1
A 9 VKZ4027-202
PLUG NUT
1
A 10 VKH4871-001SS
MOUNT BOLT
1
A 11 VKZ4328-001
LOCK NUT
1
A 12 WNS5000Z
WASHER
1
A 13 GE40130-001A
HOOK
2
A 14 RM-RK50
REMOCON
1
A 15 -----------
LI BATTERY
1
A 16 FSJB3002-00C
HARD CASE
1
A 17 GE20126-001A
MOUNTING SLEEVE
1
A 18 GE20127-007A
TRIM PLATE
1
KD-SX8250
GE20127-005A
TRIM PLATE
1
KD-SX780
A 19 QAM0013-006
16P CORD ASS'Y
1
KD-SX780
QAM0012-003
16P CORD ASS'Y
1
KD-SX8250
KIT KSFX480K-SCREW1
SCREW PARTS KIT
1
A9-A13
