KD-SX991R/KD-XS911R
3-12
Item
Parts number Parts name Area
Electrical parts list (Main board)
Remarks
Block No. 01
A
R 809 NRSA63J-223X MG RESISTOR
R 810 NRSA63J-101X MG RESISTOR
R 841 NRSA63J-102X MG RESISTOR
R 872 NRSA63J-473X MG RESISTOR
R 881 NRSA63J-473X MG RESISTOR
R 882 NRSA63J-472X MG RESISTOR
R 891 NRSA63J-102X MG RESISTOR
R 892 NRSA63J-473X MG RESISTOR
R 901 QRE142J-102X C RESISTOR 1.0K 5% 1/4W
R 902 NRSA02J-912X MG RESISTOR
R 903 NRSA02J-472X MG RESISTOR
R 971 NRS181J-222X MG RESISTOR
R 972 NRS181J-222X MG RESISTOR
R 976 NRSA02J-273X MG RESISTOR
R 977 NRSA02J-123X MG RESISTOR
S 701 QSW0451-001 DETECT SWITCH DETACH
S 702 QSW0451-001 DETECT SWITCH OPEN
S 703 QSW0534-001 RESET SWITCH RESET
TU 1 QAU0222-001 TUNER
X 31 QAX0616-001Z CRYSTAL
X 71 QAX0263-001Z CRYSTAL
X 541 QAX0413-001Z CRYSTAL
X 701 QAX0617-001Z CRYSTAL
X 702 QAX0401-001 CRYSTAL
