KD-SX991R/KD-XS911R
3-8
Item
Parts number Parts name Area
Electrical parts list (Main board)
Remarks
Block No. 01
A
Item
Parts number Parts name Area
Remarks
A
BZ841 QAN0009-001Z BUZZER
C 1 QEKJ1CM-226Z E CAPACITOR 22MF 20% 16V
C 2 NCB31EK-473X C CAPACITOR
C 3 NCB31EK-103X C CAPACITOR
C 4 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 5 QEKJ1HM-104Z E CAPACITOR 0.1MF 20% 50V
C 6 NCB31HK-103X C CAPACITOR
C 31 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V
C 32 NCS31HJ-470X C CAPACITOR
C 33 QEKJ0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 34 NCB31EK-473X C CAPACITOR
C 35 NDC31HJ-100X C CAPACITOR
C 36 NDC31HJ-7R0X C CAPACITOR
C 37 NDC31HJ-100X C CAPACITOR
C 38 NCB31HK-102X C CAPACITOR
C 39 NCB31HK-102X C CAPACITOR
C 40 QEKJ1CM-106Z E CAPACITOR 10MF 20% 16V
C 41 NCB31EK-473X C CAPACITOR
C 42 NCB31HK-103X C CAPACITOR
C 43 QFV61HJ-473Z MF CAPACITOR 0.047MF 5% 50V
C 44 NCB31HK-103X C CAPACITOR
C 45 NCB31HK-272X C CAPACITOR
C 46 NCB31HK-103X C CAPACITOR
C 47 NCB31HK-103X C CAPACITOR
C 48 NCB31EK-473X C CAPACITOR
C 49 NCB31HK-103X C CAPACITOR
C 50 NCS31HJ-101X C CAPACITOR
C 51 NCS31HJ-331X C CAPACITOR
C 52 NCB31HK-103X C CAPACITOR
C 53 NCB31EK-472X C CAPACITOR
C 54 NCB31EK-104X C CAPACITOR
C 55 QEKJ1HM-474Z E CAPACITOR 0.47MF 20% 50V
C 71 NCS31HJ-561X C CAPACITOR
C 72 NCB31EK-223X C CAPACITOR
C 73 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 74 NDC31HJ-820X C CAPACITOR
C 75 NDC31HJ-470X C CAPACITOR
C 76 NCB31HK-103X C CAPACITOR
C 77 QERF0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 81 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 82 NCB31HK-821X C CAPACITOR
C 83 NCB31EK-104X C CAPACITOR
C 84 NCB31HK-153X C CAPACITOR
C 91 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 92 NCB31HK-821X C CAPACITOR
C 94 NCB31HK-153X C CAPACITOR
C 161 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 162 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 163 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 164 NCB31HK-103X C CAPACITOR
C 165 QEKJ1CM-106Z E CAPACITOR 10MF 20% 16V
C 166 NCB31EK-104X C CAPACITOR
C 167 NCS31HJ-471X C CAPACITOR
C 168 NCB31CK-104X C CAPACITOR
C 169 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 170 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 171 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 172 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 173 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 174 NCB31HK-103X C CAPACITOR
C 175 QEKJ1CM-106Z E CAPACITOR 10MF 20% 16V
C 176 NCB31EK-104X C CAPACITOR
C 177 NCS31HJ-471X C CAPACITOR
C 178 NCB31CK-104X C CAPACITOR
C 179 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 180 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 185 NCB31HK-472X C CAPACITOR
C 186 NCS31HJ-471X C CAPACITOR
C 187 QEKJ1CM-106Z E CAPACITOR 10MF 20% 16V
C 188 NCB31EK-472X C CAPACITOR
C 189 NCB31AK-224X C CAPACITOR
C 190 NCB31AK-224X C CAPACITOR
C 191 QEKJ1CM-476Z E CAPACITOR 47MF 20% 16V
C 193 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V
C 194 NCB31HK-103X C CAPACITOR
C 195 NCB31HK-472X C CAPACITOR
C 196 NCS31HJ-471X C CAPACITOR
C 197 QEKJ1CM-106Z E CAPACITOR 10MF 20% 16V
C 198 NCB31EK-472X C CAPACITOR
C 199 NCB31AK-224X C CAPACITOR
C 200 NCB31AK-224X C CAPACITOR
C 201 NCB31EK-104X C CAPACITOR
C 202 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 241 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 242 QEKJ1CM-226Z E CAPACITOR 22MF 20% 16V
C 243 NCB31EK-473X C CAPACITOR
C 244 NCB21HK-153X C CAPACITOR
C 301 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 302 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 303 NCS31HJ-391X C CAPACITOR
C 304 NCS31HJ-391X C CAPACITOR
C 311 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 312 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 313 NCS31HJ-391X C CAPACITOR
C 314 NCS31HJ-391X C CAPACITOR
C 315 QERF1CM-475Z E CAPACITOR 4.7MF 20% 16V
C 316 QERF1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 317 QERF1CM-476Z E CAPACITOR 47MF 20% 16V
C 318 QEKJ1CM-226Z E CAPACITOR 22MF 20% 16V
C 319 NCB31EK-223X C CAPACITOR
C 320 NCB31EK-223X C CAPACITOR
C 321 NCB31EK-473X C CAPACITOR
C 322 NCB31EK-104X C CAPACITOR
C 323 NCB31EK-104X C CAPACITOR
C 324 NCB31EK-104X C CAPACITOR
C 325 NCB31EK-104X C CAPACITOR
C 341 NCB31EK-473X C CAPACITOR
C 501 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 502 NCB31HK-103X C CAPACITOR
C 503 QERF1CM-226Z E CAPACITOR 22MF 20% 16V
C 521 NCB31HK-103X C CAPACITOR
C 522 NCB31HK-103X C CAPACITOR
C 523 NCB31HK-103X C CAPACITOR
C 524 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 525 NCB31HK-103X C CAPACITOR
C 526 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 527 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 528 NCS31HJ-101X C CAPACITOR
C 529 NCB31HK-103X C CAPACITOR
C 530 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 531 NCB31EK-104X C CAPACITOR
C 532 NCB31EK-104X C CAPACITOR
C 533 NDC31HJ-560X C CAPACITOR
C 541 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 542 NCB31HK-103X C CAPACITOR
C 543 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V
