KD-SX991R/KD-SX911R
3-9
Item
Parts number Parts name Area
Electrical parts list (Main board)
Remarks
Block No. 01
A
Item
Parts number Parts name Area
Remarks
A
C 544 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 545 NCB31HK-103X C CAPACITOR
C 546 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 547 NCS31HJ-470X C CAPACITOR
C 548 NCB31HK-153X C CAPACITOR
C 549 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 550 NCB31HK-103X C CAPACITOR
C 551 NCB31HK-272X C CAPACITOR
C 552 NCB31HK-103X C CAPACITOR
C 553 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 554 NCB31HK-103X C CAPACITOR
C 555 NCB31EK-333X C CAPACITOR
C 556 NCB31HK-332X C CAPACITOR
C 557 NCS31HJ-561X C CAPACITOR
C 558 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 559 NCB31EK-473X C CAPACITOR
C 560 NCB31EK-473X C CAPACITOR
C 561 NCB31EK-473X C CAPACITOR
C 562 NCB31EK-473X C CAPACITOR
C 563 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 564 NCB31HK-103X C CAPACITOR
C 565 NCB31HK-103X C CAPACITOR
C 566 NDC31HJ-100X C CAPACITOR
C 567 NDC31HJ-100X C CAPACITOR
C 568 NCB31HK-103X C CAPACITOR
C 569 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 570 NCS31HJ-101X C CAPACITOR
C 571 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 572 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 573 NCB31HK-103X C CAPACITOR
C 581 NCS31HJ-821X C CAPACITOR
C 582 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 583 QEKJ0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 584 NCS31HJ-121X C CAPACITOR
C 591 NCS31HJ-821X C CAPACITOR
C 592 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 593 QEKJ0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 594 NCS31HJ-121X C CAPACITOR
C 595 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V
C 596 NCB31HK-103X C CAPACITOR
C 701 NDC31HJ-220X C CAPACITOR
C 702 NDC31HJ-270X C CAPACITOR
C 703 NDC31HJ-270X C CAPACITOR
C 704 NDC31HJ-8R0X C CAPACITOR
C 705 NCB31EK-473X C CAPACITOR
C 706 NCB31EK-473X C CAPACITOR
C 707 NCB31EK-473X C CAPACITOR
C 708 NCB31EK-473X C CAPACITOR
C 709 NCB31HK-103X C CAPACITOR
C 710 QEKJ0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 711 QERF1AM-107Z E CAPACITOR 100MF 20% 10V
C 712 NCB31HK-103X C CAPACITOR
C 713 NCB31HK-103X C CAPACITOR
C 716 NCB31EK-104X C CAPACITOR
C 717 NCB31EK-104X C CAPACITOR
C 771 NCB31EK-473X C CAPACITOR
C 781 QERF0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 782 NCB31EK-823X E CAPACITOR
C 784 QERF1CM-107Z E CAPACITOR 100MF 20% 16V
C 801 NCB31EK-473X C CAPACITOR
C 802 NCB31HK-103X C CAPACITOR
C 841 QERF1HM-104Z E CAPACITOR 0.1MF 20% 50V
C 881 QERF1CM-226Z E CAPACITOR 22MF 20% 16V
C 891 NCB31EK-104X C CAPACITOR
C 901 QEZ0338-228 E CAPACITOR 2200MF
C 902 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 903 QERF1CM-476Z E CAPACITOR 47MF 20% 16V
C 904 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 905 QERF1CM-226Z E CAPACITOR 22MF 20% 16V
C 906 NCB31HK-103X C CAPACITOR
C 907 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 908 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 909 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 910 QERF1CM-476Z E CAPACITOR 47MF 20% 16V
C 911 NCB31CK-104X C CAPACITOR
C 912 NCB31HK-103X C CAPACITOR
C 914 QERF1CM-107Z E CAPACITOR 100MF 20% 16V
C 915 NCB31CK-104X C CAPACITOR
C 961 NCS31HJ-101X C CAPACITOR
C 962 NCS31HJ-101X C CAPACITOR
C 963 NCS31HJ-101X C CAPACITOR
C 964 NCS31HJ-101X C CAPACITOR
C 965 NCS31HJ-101X C CAPACITOR
C 966 NCS31HJ-101X C CAPACITOR
C 967 NCS31HJ-101X C CAPACITOR
C 968 NCS31HJ-101X C CAPACITOR
C 971 NCB31EK-104X C CAPACITOR
CN501 QGB2027M1-26S CONNECTOR
CN701 QNZ0007-002 CAR CONNECTOR
CN901 QNZ0112-001 CAR CONNECTOR
D 1 1SS133-T1 SI DIODE
D 2 1SS133-T1 SI DIODE
D 3 1SS133-T1 SI DIODE
D 4 1SS355-X DIODE
D 5 1SS355-X DIODE
D 240 1SS355-X DIODE
D 241 1SS355-X DIODE
D 242 1SS133-T1 SI DIODE
D 243 1SS133-T1 SI DIODE
D 321 1SS355-X DIODE
D 331 1SS355-X DIODE
D 341 1SS355-X DIODE
D 351 1SS355-X DIODE
D 501 DSK10C-T1 DIODE
D 701 UDZS5.6B-X ZENER DIODE
D 702 UDZS5.6B-X ZENER DIODE
D 703 UDZS5.6B-X ZENER DIODE
D 704 UDZS5.6B-X ZENER DIODE
D 705 UDZS5.6B-X ZENER DIODE
D 706 UDZS5.6B-X ZENER DIODE
D 707 UDZS5.6B-X ZENER DIODE
D 708 UDZS5.6B-X ZENER DIODE
D 709 UDZS5.6B-X ZENER DIODE
D 710 1SS355-X DIODE
D 712 UDZS5.6B-X ZENER DIODE
D 713 UDZS5.6B-X ZENER DIODE
D 714 QLL0033-001 LAMP
D 781 1SS133-T1 SI DIODE
D 782 1SS133-T1 SI DIODE
D 784 UDZ11B-X ZENER DIODE
D 891 1SS355-X DIODE
D 892 1SS355-X DIODE
D 901 1N5401-TU-15 DIODE
D 902 1SS355-X DIODE
D 971 CRS03-W SB DIODE
D 972 CRS03-W SB DIODE
