KD-SX991R/KD-XS911R
3-10
Item
Parts number Parts name Area
Electrical parts list (Main board)
Remarks
Block No. 01
A
Item
Parts number Parts name Area
Remarks
A
IC 31 TB2118F-X IC
IC 71 SAA6579T-X IC
IC161 BD3860K IC
IC301 LA4743K IC
IC501 LA6567H-X IC
IC521 TA2109F-X IC
IC541 TC9462F IC
IC581 NJM4565M-WE IC
IC701 UPD784215AGC127 IC
IC702 IC-PST600M/G/-W IC
IC771 M24C16-WMN6-X IC
IC801 HD74HC126FP-X IC
IC901 HA13164 IC
J 1 QNB0100-001 CAR ANT JACK
J 321 QNN0176-001 PIN JACK KD-SX991R
J 321 QNN0175-001 PIN JACK KD-SX911R
J 801 QNZ0095-001 CONNECTOR
L 1 QQL244J-4R7Z INDUCTOR
L 541 QQL244J-4R7Z INDUCTOR
L 542 QQL244J-4R7Z INDUCTOR
L 701 QQL244K-4R7Z INDUCTOR
L 901 QQR0703-001 CHOKE COIL
Q
1 2SD601A/R/-X TRANSISTOR
Q
2 2SD601A/R/-X TRANSISTOR
Q
3 UN2111-X TRANSISTOR
Q
4 UN2111-X TRANSISTOR
Q
5 2SB709A/R/-X TRANSISTOR
Q
6 2SB815/7/-X TRANSISTOR
Q
7 UN2211-X TRANSISTOR
Q
9 UN2111-X TRANSISTOR
Q
31 UN2211-X TRANSISTOR
Q
51 2SC2412K/R/-X TRANSISTOR
Q
52 2SC2412K/R/-X TRANSISTOR
Q
53 UN2211-X TRANSISTOR
Q
81 2SD601A/R/-X TRANSISTOR
Q
91 2SD601A/R/-X TRANSISTOR
Q
241 2SD601A/R/-X TRANSISTOR
Q
321 2SD1781K/QR/-X TRANSISTOR
Q
331 2SD1781K/QR/-X TRANSISTOR
Q
341 2SD1781K/QR/-X TRANSISTOR
Q
351 2SD1781K/QR/-X TRANSISTOR
Q
501 2SB1322/RS/-T TRANSISTOR
Q
521 2SB1322/RS/-T TRANSISTOR
Q
781 UN2111-X TRANSISTOR
Q
782 UN2211-X TRANSISTOR
Q
784 UN2111-X TRANSISTOR
Q
841 UN2211-X TRANSISTOR
Q
881 UN2211-X TRANSISTOR
Q
891 UN2211-X TRANSISTOR
Q
976 UN2211-X TRANSISTOR
Q
977 2SA1037AK/RS/-X TRANSISTOR
R 1 NRS181J-8R2X MG RESISTOR
R 2 NRSA63J-473X MG RESISTOR
R 3 NRSA63J-472X MG RESISTOR
R 4 NRSA63J-332X MG RESISTOR
R 5 NRSA63J-473X MG RESISTOR
R 6 NRSA63J-473X MG RESISTOR
R 7 NRSA63J-472X MG RESISTOR
R 9 NRSA63J-0R0X MG RESISTOR
R 31 NRS181J-100X MG RESISTOR
R 32 NRSA63J-622X MG RESISTOR
R 33 NRSA63J-473X MG RESISTOR
R 34 NRSA63J-222X MG RESISTOR
R 35 NRSA63J-222X MG RESISTOR
R 36 NRSA63J-222X MG RESISTOR
R 37 NRSA63J-222X MG RESISTOR
R 38 NRSA63J-101X MG RESISTOR
R 39 NRSA63J-0R0X MG RESISTOR
R 40 NRSA63J-393X MG RESISTOR
R 41 NRSA63J-103X MG RESISTOR
R 42 NRS181J-100X MG RESISTOR
R 43 NRSA63J-471X MG RESISTOR
R 44 NRSA63J-221X MG RESISTOR
R 51 NRSA63J-223X MG RESISTOR
R 52 NRSA63J-473X MG RESISTOR
R 53 NRSA63J-473X MG RESISTOR
R 54 NRSA63J-103X MG RESISTOR
R 55 NRSA63J-222X MG RESISTOR
R 56 NRSA63J-103X MG RESISTOR
R 57 NRSA63J-153X MG RESISTOR
R 58 NRSA63J-471X MG RESISTOR
R 59 NRSA63J-473X MG RESISTOR
R 71 NRSA63J-222X MG RESISTOR
R 72 NRSA63J-222X MG RESISTOR
R 73 NRSA63J-222X MG RESISTOR
R 74 NRSA02J-101X MG RESISTOR
R 81 NRSA63J-822X MG RESISTOR
R 82 NRSA63J-183X MG RESISTOR
R 83 NRSA63J-472X MG RESISTOR
R 91 NRSA63J-822X MG RESISTOR
R 92 NRSA63J-183X MG RESISTOR
R 93 NRSA63J-472X MG RESISTOR
R 161 NRSA63J-224X MG RESISTOR
R 164 NRSA63J-473X MG RESISTOR
R 165 NRSA63J-473X MG RESISTOR
R 166 NRSA63J-682X MG RESISTOR
R 167 NRSA63J-224X MG RESISTOR
R 171 NRSA63J-224X MG RESISTOR
R 174 NRSA63J-473X MG RESISTOR
R 175 NRSA63J-473X MG RESISTOR
R 176 NRSA63J-682X MG RESISTOR
R 177 NRSA63J-224X MG RESISTOR
R 181 NRSA63J-222X MG RESISTOR
R 182 NRSA63J-222X MG RESISTOR
R 190 NRSA63J-332X MG RESISTOR
R 199 NRSA63J-332X MG RESISTOR
R 202 NRSA63J-105X MG RESISTOR
R 241 NRSA63J-473X MG RESISTOR
R 242 NRSA63J-223X MG RESISTOR
R 243 NRSA63J-184X MG RESISTOR
R 244 NRSA63J-123X MG RESISTOR
R 245 NRSA63J-101X MG RESISTOR
R 246 NRSA63J-102X MG RESISTOR
R 247 NRSA63J-184X MG RESISTOR
R 301 NRSA63J-273X MG RESISTOR
R 302 NRSA63J-273X MG RESISTOR
R 311 NRSA63J-273X MG RESISTOR
R 312 NRSA63J-273X MG RESISTOR
R 321 NRSA63J-222X MG RESISTOR
R 322 NRSA63J-821X MG RESISTOR
R 323 NRSA63J-101X MG RESISTOR
R 331 NRSA63J-222X MG RESISTOR
R 332 NRSA63J-821X MG RESISTOR
R 333 NRSA63J-101X MG RESISTOR
R 341 NRSA63J-222X MG RESISTOR
R 342 NRSA63J-821X MG RESISTOR
