JVC KS-F350R Service Manual

Item
Parts number
Parts name
Area
A
Parts list
Q'ty
Description
Block No.
M1MM
1 ZCKSFX450J-NPA NOSE PIECE 1 KS-FX450R
ZCKSFX453R-NPA NOSE PIECE 1 KS-FX453R
FSJC3013-00C FRONT PANEL 1 KS-F350R
FSJC3013-00D FRONT PANEL 1 KS-F353R
1-1 FSJC1053-003 FRONT PANEL 1 KS-FX453R/FX450
FSJD3022-00B FINDER LENS 1 KS-FX453R
2 ZCKSFX12J-FB F.PANEL ASS'Y 1 KS-FX453R/FX450
ZCKSF150J-FB F.PANEL ASS'Y 1 KS-F353R/F350R
2-2
FSJC1055-001 FRONT CHASSIS 1
FSJC4003-027 CASSETTE LID 1 KS-FX453R/FX450
FSJC4003-029 CASSETTE LID 1 KS-F353R/F350R
VKW4947-002 DOOR SPRING 1
3 QYSPSPT2625Z MINI SCREW 1
4 FSKM2005-002 MECHA BRACKET 1
5 QYSDST2605Z SCREW 2 PCB+MECHA
6 QYSDSP2604Z SCREW 4 MECHA+M.BKT
7 FSJC1029-015 TOP CHASSIS 1
8 FSMH3001-001 SIDE PANEL 1
9 FSKM3011-002 BOTTOM COVER 1
10 FSMA3004-003 INSULATOR 1
11 QYSDST2605Z SCREW 4 CHASSIS+MECHA B
12 FSKZ4005-001 SCREW 3
13 QYSDST2606Z SCREW 2 CHASSIS+REAR BK
14 QYSDST2606Z SCREW 2 CHASSIS+MAIN PW
17 FSKS3010-001 LOCK LEVER 1
18 FSKW4005-003 TORSION SPRING 1
19 FSXP3026-002 RLS KNOB 1
20 FSKW3002-004 COMP.SPRING 1
21 ------------ CASSETTE MECHA 1 MECHA W/0 METAL
22 VKL7821-001 EJECT LEVER 1
24 FSJK3014-001 LIGHT LENS 1
25 FSYH4036-031 SHEET 1 PRESET BTN
26 FSXP2035-052 PRESET BUTTON 1 KS-FX453R/FX450
FSXP2035-050 PRESET BUTTON 1 KS-F353R/F350R
27 FSXP4005-016 BBE BUTTON 1
28 FSXP2044-001 COMBO BUTTON 1
29 FSXP3053-002 POWER BUTTON 1
30 FSXP2034-037 OPERAT.BUTTON 1 KS-FX453R/FX450
FSXP2034-039 OPERAT.BUTTON 1 KS-F353R/F350R
31 FSXP3068-002 PUSH BUTTON 1 KS-FX453R/FX450
FSXP3068-004 PUSH BUTTON 1 KS-F353R/F350R
33 FSXP3066-001 FF BUTTON 1
34 FSXP3067-001 REW BUTTON 1
35 FSXP3065-001 EJECT BUTTON 1
36 FSKW3002-003 COMP. SPRING 3
37 FSXP3055-001 DETACH BUTTON 1
38 FSKW3002-012 COMP. SPRING 1 FOR DETACH BUTT
39 FSJC1054-001 REAR COVER 1
FSJD3022-00A
FINDER LENS 1
KS-FX450R
2-1
2-3
1-2
R
R
R
R
R
R
(General assembly)
