JVC KS-F350R

Item
Parts number
Parts name
Area
A
Parts list
Q'ty
Description
Block No.
M2MM
1 X-0036-1001S MAIN CHASSIS AS 1
2 X-0036-6082S HEAD PLATE ASSY 1
3 X-0036-1009S REEL BASE ASS'Y 1
4 X-0036-1010S FR CHANGE ARM A 1
6 X-0036-1019S EJ.CAM LOCK ASY 1
7 X-0036-6077S LEVER BKT ASS'Y 1
10 X-0036-1025S FR ARM(A)ASS'Y 1
11 X-0138-2006S CM BKT ASS'Y(X) 1
12 1-0036-6010-0S FLYWHEEL ASY(BF 1
13 1-0138-6002S PINCH ARM(R)ASS 1
14 1-0138-6003S PINCH ARM(F)ASS 1
15 X-0036-6080S REEL SPINDLE AS 2
16 1-0036-6010-1S FLYWHEEL ASY(BR 1
19 1-0138-1010S CASSETTE HOLDER 1
20 1-0036-1006S EJECT CAM 1
21 1-0036-1007S EJECT LEVER 1
22 1-0138-1002S CASSETTE HANGER 1
23 1-0036-1015S SPG SUPPORT PLT 1
24 1-0036-1016S CONVERSION LEVE 1
25 1-0138-1006S ADJUSTER SHIN(X 1
26 1-0036-1018S CENTER PLATE 1
27 1-0036-1013S LOCK ARM 1
28 1-0036-1023S CHANGE LEVER(B) 1
29 1-0036-1026S FR ARM(B) 1
30 1-0036-1065S FF LEVER(JVC) 1
31 1-0036-1066S REW LEVER(JVC) 1
35 1-0036-2001S IDLE GEAR 1
37 1-0036-2004-0S REDUCT.GEAR(A) 1
38 1-0036-2003S REDUCT.GEAR(B) 1
39 1-0036-2005-0S PULLEY GEAR 1
40 1-0038-2018S TAPE GUIDE 1
41 1-0036-2007S RATCHET 1
42 1-0036-2008S FF ARM 1
43 1-0036-2009S SENSOR ARM 1
44 1-0036-2010S SELECTOR GEAR 1
45 1-0138-2005-3S ADJUSTER ARM(B) 1
46 1-0138-2004S ADJUSTER LINC(X 1
47 1-0038-2014S GEAR LOCK ARM 1
48 1-0036-2014S DETECTOR GEAR 1
49 X-0036-2015S TU GEAR ARM ASY 1
50 X-0136-2001S DETEC. CAM ASSY 2
51 1-0038-2034S MUTE ARM(N) 1
52 1-0058-2004S TAPE HOOKER 1
53 1-0058-2021-5S IDLE PULLEY(A) 1
57 1-0036-3024S HP ROLLER(B) 1
58 1-0036-3004S FF ROLLER 1
59 1-0036-3018S COLLER 1 SELECTOR GEAR
60 1-0036-3002S HP ROLLER(A) 1
(Cassette mechanism)
