3-3
KS-F363R/KS-F360R
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
1 ---------------
CASSETTE MECHA
1
CDS-363SJ1
2 VKL7821-001
EJECT LEVER
1
3 QYSPSPT2625Z
MINI SCREW
1
4 FSKM2005-002
MECHA BRACKET
1
5 QYSDST2605Z
SCREW
2
PCB+MECHA
6 QYSDSP2604Z
SCREW
4
MECHA+M.BKT
7 FSJC1029-305
TOP CHASSIS
1
8 FSMH3001-201
SIDE PANEL
1
9 FSKM3011-002
BOTTOM COVER
1
10 FSMA3004-203
INSULATOR
1
11 QYSDST2605Z
SCREW
4
CHASSIS+MECHA BKT
12 FSKZ4005-001
SCREW
2
CHASSIS+SIDE PANEL
13 QYSDST2604Z
SCREW
2
CHASSIS+REAR BKT
14 QYSDST2606Z
SCREW
2
CHASSIS+MAIN PW
15 FSKZ4005-001
SCREW
1
SIDE PANEL+IC BKT
16 ZCKSF150J-FB
FRONT CHASSIS A
1
17,18,19
17 FSJC1055-001
FRONT CHASSIS
1
18 FSJC4003-029
CASSETTE LID
1
19 VKW4947-002
DOOR SPRING
1
20 FSKS3010-001
LOCK LEVER
1
21 FSKW4005-003
TORSION SPRING
1
22 FSXP3026-002
RLS KNOB
1
23 FSKW3002-004
COMP.SPRING
1
24 FSJC1053-006
FRONT PANEL
1
25 FSJD3022-00P
FINDER ASSY
1
KS-F363R
FSJD3022-00N
FINDER ASSY
1
KS-F360R
26 FSJK3014-001
LIGHT LENS
1
27 FSXP2035-110
PRESET BUTTON
1
1-6,RDS,PTY
28 FSYH4036-031
SHEET
1
PRESET BUTTON
29 FSXP2034-039
D.FUNC BUTTON
1
FM/AM/TP
30 FSXP3053-002
POWER BUTTON
1
31 FSXP4005-026
BBE BUTTON
1
32 FSXP2044-001
COMBO BUTTON
1
33 FSXP3068-004
PUSH BUTTON
1
DISP,MO
34 FSXP3066-001
FF BUTTON
1
35 FSXP3065-001
EJECT BUTTON
1
36 FSXP3067-001
REW BUTTON
1
37 FSKW3002-003
COMP. SPRING
1
FOR REW BUTTON
38 FSKW3002-003
COMP. SPRING
1
FOR FF BUTTON
39 FSKW3002-003
COMP. SPRING
1
FOR EJECT BUTTON
40 FSXP3055-001
DETACH BUTTON
1
41 FSKW3002-012
COMP. SPRING
1
FOR DETACH BUTTON
42 FSJC1054-001
REAR COVER
1
43 VKZ4777-001
MINI SCREW
4
F.PANEL+REAR COVER
44 QLD0145-001
LCD MODULE
1
45 QNZ0439-001
RUBBER CONNE
1
46 FSJK3034-001
LCD LENS
1
47 FSYH4076-001
LIGHTING SHEET
1
