JVC KS-F363R User Manual

KS-F363R/KS-F360R
3-10
Item
Parts number Parts name Ar
e
a
Remarks
A
C 1 QEKJ1HM-104Z E CAPACITOR .10MF 20% 50V
C 6 NCB21EK-563X C CAPACITOR
C 7 NCB21EK-123X C CAPACITOR
C 9 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 17 NCS21HJ-151X C CAPACITOR
C 18 QERF1HM-224Z E CAPACITOR .22MF 20% 50V
C 20 NCS21HJ-102X C CAPACITOR
C 21 QEQF1HM-225Z NP E CAPACITOR 2.2MF 20% 50V
C 24 NCB21EK-473X C CAPACITOR
C 25 NCB21EK-104X C CAPACITOR
C 30 NDC21HJ-470X C CAPACITOR
C 101 NCS21HJ-821X C CAPACITOR
C 102 QEKJ1HM-474Z E CAPACITOR .47MF 20% 50V
C 103 NCS21HJ-101X C CAPACITOR
C 104 QEKJ0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 105 QFV61HJ-103Z MF CAPACITOR .010MF 5% 50V
C 111 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 112 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 113 QFLA1HJ-822Z M CAPACITOR 8200PF 5% 50V
C 114 QFV61HJ-154Z MF CAPACITOR .15MF 5% 50V
C 115 QERF1HM-224Z E CAPACITOR .22MF 20% 50V
C 116 QFV61HJ-333Z MF CAPACITOR .033MF 5% 50V
C 117 QFLA1HJ-562Z M CAPACITOR 5600PF 5% 50V
C 118 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 119 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 143 NCS21HJ-471X C CAPACITOR
C 144 NCS21HJ-471X C CAPACITOR
C 151 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 152 NCB21HK-122X C CAPACITOR
C 153 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 154 NCB21HK-153X C CAPACITOR
C 201 NCS21HJ-821X C CAPACITOR
C 202 QERF1HM-474Z E CAPACITOR .47MF 20% 50V
C 203 NCS21HJ-101X C CAPACITOR
C 204 QEKJ0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 205 QFV61HJ-103Z MF CAPACITOR .010MF 5% 50V
C 211 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 212 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 213 QFLA1HJ-822Z M CAPACITOR 8200PF 5% 50V
C 214 QFV61HJ-154Z MF CAPACITOR .15MF 5% 50V
C 215 QERF1HM-224Z E CAPACITOR .22MF 20% 50V
C 216 QFV61HJ-333Z MF CAPACITOR .033MF 5% 50V
C 217 QFLA1HJ-562Z M CAPACITOR 5600PF 5% 50V
C 218 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 219 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 243 NCS21HJ-471X C CAPACITOR
C 244 NCS21HJ-471X C CAPACITOR
C 251 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 252 NCB21HK-122X C CAPACITOR
C 253 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 254 NCB21HK-153X C CAPACITOR
C 301 NCB21HK-331X C CAPACITOR
C 302 NCB21HK-103X C CAPACITOR
C 303 NCB21EK-472X C CAPACITOR
C 304 NCB21EK-104X C CAPACITOR
C 305 QEKJ1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 701 NDC21HJ-270X C CAPACITOR
C 702 NDC21HJ-270X C CAPACITOR
C 703 NCB21EK-104X C CAPACITOR
C 704 NCB21EK-104X C CAPACITOR
C 705 NCB21HK-102X C CAPACITOR
C 707 NCB21EK-104X C CAPACITOR
C 708 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 709 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 710 NCS21HJ-121X C CAPACITOR
C 711 NCB21CK-224X C CAPACITOR
C 712 NCB21HK-104X C CAPACITOR
C 761 NCB21EK-223X C CAPACITOR
C 762 NCS21HJ-561X C CAPACITOR
C 763 QEKJ1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 764 NDC21HJ-820X C CAPACITOR
C 765 NDC21HJ-470X C CAPACITOR
C 766 QERF1CM-476Z E CAPACITOR 47MF 20% 16V
C 767 NCB21HK-103X C CAPACITOR
C 901 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V
C 911 QERF1CM-476Z E CAPACITOR 47MF 20% 16V
C 912 QERF1CM-107Z E CAPACITOR 100MF 20% 16V
C 913 QERF1CM-107Z E CAPACITOR 100MF 20% 16V
C 932 NCB21EK-104X C CAPACITOR
C 941 NCB21EK-104X C CAPACITOR
C 942 NCB21EK-104X C CAPACITOR
C 943 NCB21EK-104X C CAPACITOR
C 944 NCB21EK-104X C CAPACITOR
C 945 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 961 QETM1CM-228 E CAPACITOR 2200MF 20% 16V
C 962 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 963 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 964 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 965 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 966 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 967 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 969 NCB21EK-473X C CAPACITOR
C 970 NCB21EK-473X C CAPACITOR
C 971 NCB21EK-104X C CAPACITOR
C 977 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 978 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 979 QEKJ1CM-106Z E CAPACITOR 10MF 20% 16V
C 980 NCB21HK-473X C CAPACITOR
C 981 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 982 QEKJ1CM-106Z E CAPACITOR 10MF 20% 16V
C 984 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
CJ701 VMC0334-001 CONNECTOR
CJ901 QGA2002C1-05 CONNECTOR
CJ902 QGA2002F1-06 CONNECTOR
CN901 QGB1214J1-06S CONNECTOR
CN902 QGB1214J1-06S CONNECTOR
CP901 QGB1214K1-06S CONNECTOR
CP902 QGB1214K1-06S CONNECTOR
CP961 QNZ0112-001 CAR CONNECTOR
D 1 1SS119-041 SI DIODE
D 2 1SS119-041 SI DIODE
D 3 MA152WK-X SI DIODE
D 5 1SS119-041 SI DIODE
D 6 MTZJ9.1C-T2 Z DIODE
D 701 RB721Q-T2 S.B.DIODE
D 741 1SS119-041 SI DIODE
D 742 1SS119-041 SI DIODE
D 744 DSK10C-T1 DIODE
D 776 DSK10C-T1 DIODE
D 931 MA152WA-X DIODE
D 951 1SS133-T2 SI DIODE
D 961 1N5401-TU-15 DIODE
D 963 MA152WA-X DIODE
D 965 DSK10C-T1 DIODE
D 966 DSK10C-T1 DIODE
D 977 MA152WK-X SI DIODE
Electrical parts list (Main board)
Block No. 01
Item
Parts number Parts name Ar
e
a
Remarks
A

JVC KS-F363R Specifications

General

Brand	JVC
Model	KS-F363R
Category	Car Receiver
Language	English
