1-2 (No.YA606<Rev.002>)
Design & specifications are subject to change without notice.
Items
Contents
LT-26DA9BJ
LT-26DA9BN
LT-26DA9BU
LT-26DC9BH
Dimensions ( W × H × D ) 66.0 cm × 48.2 cm × 20.0 cm [66.0 cm × 44.0 cm × 9.0 cm (Without stand)]
Mass 10.5 kg [9.0 kg (Without stand)]
Power Input AC220V - AC240 V, 50 Hz
Power Consumption 95 W (Standby: 0.9 W)
TV RF System Analog CCIR (B/G, I, D/K, L)
Digital DVB-T DVB-C
Colour System PAL, SECAM, NTSC 3.58/4.43 [EXT only]
Stereo System NICAM (B/G, I, D/K, L), A2 (B/G, D/K)
Receiving
Frequency
Analog VHF: 46.25 MHz - 470MHz
UHF: 470 MHz - 855.25 MHz
CATV: 116MHz - 172MHz / 220MHz - 469MHz
Digital UHF:474 MHz - 858 MHz CATV:47MHz~862MHz
Intermediate
Frequency
VIF 38.9MHz (B/G, I, D/K, L)
SIF 33.4MHz (5.5MHz:B/G)
32.9MHz (6.0MHz:I)
32.4MHz (6.5MHz:D/K)
Colour Sub
Carrier
Frequency
PAL 4.43MHz
SECAM 4.40625MHz / 4.25MHz
NTSC 3.58MHz / 4.43MHz
Teletext Sys-
tem
Analog FLOF (Fastext), TOP
Digital MHEG 5 UK profile EBU TEXT
LCD panel 26-inch wide aspect (16 : 9)
Screen Size Diagonal : 66.0 cm (H: 57.8 cm × V: 32.6 cm)
Display Pixels Horizontal : 1366 dots × Vertical : 768 dots
Audio Power Output 5 W + 5 W
Speaker 3.5 cm × 11.5 cm, oval type × 2
Aerial terminal (VHF/UHF) 75 Ω unbalanced, coaxial × 1
EXT-1 / EXT-2 (Input/Output) 21-pin Euro connector (SCART socket ) × 2
EXT-3
(Input)
Component Video
750p / 1125i
625p / 525p / 625i / 525i
RCA pin jack × 3
Y: 1 V (p-p) (Sync signal: ±0.35V(p-p), 3-value sync.), 75Ω / Pb/Pr: ±0.35V(p-p), 75 Ω
Y: 1 V (p-p), Positive (Negative sync.), 75 Ω / Cb/Cr: 0.7V(p-p), 75 Ω
Audio 500 mV(rms) (-4dBs), high impedance, RCA pin jack × 2
EXT-4
(Input)
S-Video Mini-DIN 4 pin × 1
Y: 1 V (p-p), Positive (Negative sync provided), 75 Ω
C: 0.286 V (p-p) (Burst signal), 75 Ω
Video 1V (p-p), Positive (Negative sync provided), 75 Ω, RCA pin jack × 1
Audio 500 mV (rms), High impedance, RCA pin jack × 2
EXT-5 / EXT-6
/ EXT-7
(Digital Input)
Video / Audio HDMI 2-row 19pin connector × 3
(Digital-input terminal is not compatible with picture signals of personal computer)
576i(625i),576p(625p),480i(525i),480p(525p),720p(750p),1080i(1125i) signals are available.
Digital Audio Optical Output Digital SPDIF × 1
Headphone 3.5 mm stereo mini jack × 1
Remote Control Unit RM-C1892B (AA/R6 dry cell battery × 2)
