JVC LT-19DA9 Series - Ir P.w. Board Assy (Hu-72200001); Key P.w. Board Assy (Hu-72200002)

(No.YA606<Rev.002>)3-11
IR P.W. BOARD ASS'Y (HU-72200001)
KEY P.W. BOARD ASS'Y (HU-72200002)
L900 NQR0154-002X FERRITE CORE
L901 HU-011030025 FERRITE BEADS
L902 HU-011030025 FERRITE BEADS
JP40 HU-009030060 PCMCIA CONNECTOR CI SLOT
Y180 HU-005000940 CRYSTAL 16MHz
Y430 HU-005001080 CRYSTAL 27MHz
 Ref No. Part No. Part Name Description Local
U1 HU-006050110 REMOCON SENSOR
D1 HU-006020000 LED
C1 HU-001060288 C CAPACITOR 1uF 25V
C2 HU-001060288 C CAPACITOR 1uF 25V
C3 HU-0010900002 TA CAPACITOR 220uF 10V
R2 HU-002000390 MG RESISTOR 20
Ω
RV1 HU-002110004 VARISTOR 100pF 5.6V
RV2 HU-002110004 VARISTOR 100pF 5.6V
 Ref No. Part No. Part Name Description Local
R5 HU-002000500 MG RESISTOR 27
Ω
R6 HU-002000500 MG RESISTOR 27 Ω
R7 HU-002000453 MG RESISTOR 470 Ω
R8 HU-002000453 MG RESISTOR 470 Ω
R9 HU-002000405 MG RESISTOR 1k Ω
R11 HU-002001050 MG RESISTOR 2.7k Ω
R12 HU-002000405 MG RESISTOR 1k Ω
R13 HU-002001050 MG RESISTOR 2.7k Ω
RV3 HU-002110004 VARISTOR 100pF 5.6V
RV4 HU-002110004 VARISTOR 100pF 5.6V
S1 HU-008020050 TACT SW TV/AV
S2 HU-008020050 TACT SW PROGRAM +
S3 HU-008020050 TACT SW MENU/OK
S4 HU-008020050 TACT SW PROGRAM -
S5 HU-008020050 TACT SW VOL -
S6 HU-008020050 TACT SW POWER ON/OFF
S7 HU-008020050 TACT SW VOL +
 Ref No. Part No. Part Name Description Local
