JVC LT-19DA9 Series - Printed Wiring Board Parts List [Lt-26 Dc9 Bh]; Main P.w. Board Assy (Hu-71200026); Mpeg P.w. Board Assy (Hu-71200012)

3-20(No.YA606<Rev.002>)
PRINTED WIRING BOARD PARTS LIST [LT-26DC9BH]
MAIN P.W. BOARD ASS'Y (HU-71200026)
REFER TO PARTS LIST IN PAGE 3-15 FOR THIS P.W. BOARD.
MPEG P.W. BOARD ASS'Y (HU-71200012)
 Ref No. Part No. Part Name Description Local
U1 HU-000030020 IC ASIC
U2 HU-000120027 IC INVERTER
U81 SN74LVC244APW-X IC CMOS
U82 SN74LVC244APW-X IC CMOS
U230 HU-0140400003 TUNER
U280 HU-000270008 IC QAM DEMOD
U330 HU-000100150 IC MPEG DECODER
U480 HU-000010440 IC PROCESSOR
U580 HU-0000400003 IC SDRAM
U750 HU-000140450 IC AUDIO DAC
U800 HU-000090170 IC REGULATOR
U803 BA50BC0WFP-X IC REGULATOR
U804 HU-000091100 IC REGULATOR
U805 HU-000091100 IC REGULATOR
U806 HU-000091100 IC REGULATOR
Q40 HU-004020004 FET
Q41 HU-004000410 TRANSISTOR
Q480 HU-004000410 TRANSISTOR
Q700 HU-004000410 TRANSISTOR
C1 HU-001060250 C CAPACITOR 0.1uF 16V K
C2 HU-001060250 C CAPACITOR 0.1uF 16V K
C3 HU-001060250 C CAPACITOR 0.1uF 16V K
C4 HU-001060250 C CAPACITOR 0.1uF 16V K
C5 HU-001060250 C CAPACITOR 0.1uF 16V K
C40 HU-001060282 C CAPACITOR 6.8nF 50V K
C41 HU-001060250 C CAPACITOR 0.1uF 16V K
C42 HU-001060250 C CAPACITOR 0.1uF 16V K
C43 HU-001060250 C CAPACITOR 0.1uF 16V K
C44 HU-001060267 C CAPACITOR 68pF 50V J
C45 HU-001060250 C CAPACITOR 0.1uF 16V K
C46 HU-001060250 C CAPACITOR 0.1uF 16V K
C81 HU-001060250 C CAPACITOR 0.1uF 16V K
C82 HU-001060250 C CAPACITOR 0.1uF 16V K
C230 HU-001071224 E CAPACITOR 220uF 16V
C231 HU-001060250 C CAPACITOR 0.1uF 16V K
C232 HU-001060219 C CAPACITOR 1000pF 50V K
C233 HU-001060297 C CAPACITOR 0.01pF 50V K
C235 HU-001071224 E CAPACITOR 220uF 16V
C236 HU-001060250 C CAPACITOR 0.1uF 16V K
C237 HU-001060219 C CAPACITOR 1000pF 50V K
C238 HU-001060297 C CAPACITOR 0.01pF 50V K
C280 HU-001060236 C CAPACITOR 10uF 25V
C281 HU-001060297 C CAPACITOR 0.01pF 50V K
C282 HU-001060236 C CAPACITOR 10uF 25V
C283 HU-001060297 C CAPACITOR 0.01pF 50V K
C284 HU-001060250 C CAPACITOR 0.1uF 16V K
C285 HU-001060250 C CAPACITOR 0.1uF 16V K
C286 HU-001060250 C CAPACITOR 0.1uF 16V K
C287 HU-001060250 C CAPACITOR 0.1uF 16V K
C288 HU-001060221 C CAPACITOR 22pF 50V J
C289 HU-001060250 C CAPACITOR 0.1uF 16V K
C290 HU-001060250 C CAPACITOR 0.1uF 16V K
C291 HU-001060250 C CAPACITOR 0.1uF 16V K
C292 HU-001060236 C CAPACITOR 10uF 25V
C293 HU-001060250 C CAPACITOR 0.1uF 16V K
C294 HU-001060297 C CAPACITOR 0.01pF 50V K
C295 HU-001060236 C CAPACITOR 10uF 25V
C296 HU-001060250 C CAPACITOR 0.1uF 16V K
C297 HU-001060297 C CAPACITOR 0.01pF 50V K
C298 HU-001060250 C CAPACITOR 0.1uF 16V K
C299 HU-001060082 C CAPACITOR 0.1uF 50V
C300 HU-001060082 C CAPACITOR 0.1uF 50V
C301 HU-001060236 C CAPACITOR 10uF 25V
C302 HU-001060297 C CAPACITOR 0.01pF 50V K
C303 HU-001060300 C CAPACITOR 1uF 16V
C304 HU-001060258 C CAPACITOR 30pF 50V J
C305 HU-001060258 C CAPACITOR 30pF 50V J
C307 HU-001060250 C CAPACITOR 0.1uF 16V K
C309 HU-001060250 C CAPACITOR 0.1uF 16V K
C330 HU-001060250 C CAPACITOR 0.1uF 16V K
C331 HU-001071223 E CAPACITOR 100uF 16V
C332 HU-001060250 C CAPACITOR 0.1uF 16V K
C333 HU-001060250 C CAPACITOR 0.1uF 16V K
C334 HU-001060250 C CAPACITOR 0.1uF 16V K
C335 HU-001071223 E CAPACITOR 100uF 16V
C336 HU-001060250 C CAPACITOR 0.1uF 16V K
C337 HU-001060250 C CAPACITOR 0.1uF 16V K
C338 HU-001060250 C CAPACITOR 0.1uF 16V K
C339 HU-001060250 C CAPACITOR 0.1uF 16V K
C340 HU-001060250 C CAPACITOR 0.1uF 16V K
C341 HU-001060250 C CAPACITOR 0.1uF 16V K
C342 HU-001060250 C CAPACITOR 0.1uF 16V K
C343 HU-001060250 C CAPACITOR 0.1uF 16V K
C344 HU-001060250 C CAPACITOR 0.1uF 16V K
C345 HU-001071223 E CAPACITOR 100uF 16V
C346 HU-001060250 C CAPACITOR 0.1uF 16V K
C347 HU-001060250 C CAPACITOR 0.1uF 16V K
C348 HU-001060250 C CAPACITOR 0.1uF 16V K
C349 HU-001060250 C CAPACITOR 0.1uF 16V K
C350 HU-001060250 C CAPACITOR 0.1uF 16V K
C380 HU-001060259 C CAPACITOR 33pF 50V
C381 HU-001060259 C CAPACITOR 33pF 50V
C530 HU-001060250 C CAPACITOR 0.1uF 16V K
C531 HU-001060250 C CAPACITOR 0.1uF 16V K
C532 HU-001060250 C CAPACITOR 0.1uF 16V K
C533 HU-001060250 C CAPACITOR 0.1uF 16V K
C580 HU-001071223 E CAPACITOR 100uF 16V
C581 HU-001060250 C CAPACITOR 0.1uF 16V K
C582 HU-001060250 C CAPACITOR 0.1uF 16V K
C583 HU-001060250 C CAPACITOR 0.1uF 16V K
C584 HU-001060250 C CAPACITOR 0.1uF 16V K
C585 HU-001060250 C CAPACITOR 0.1uF 16V K
C586 HU-001060250 C CAPACITOR 0.1uF 16V K
C587 HU-001060250 C CAPACITOR 0.1uF 16V K
C632 HU-001060339 C CAPACITOR 560pF 50V K
C633 HU-001060339 C CAPACITOR 560pF 50V K
C634 HU-001060339 C CAPACITOR 560pF 50V K
C635 HU-001060339 C CAPACITOR 560pF 50V K
C636 HU-001060339 C CAPACITOR 560pF 50V K
C637 HU-001060339 C CAPACITOR 560pF 50V K
C660 HU-001060250 C CAPACITOR 0.1uF 16V K
C661 HU-001060250 C CAPACITOR 0.1uF 16V K
C662 HU-001060250 C CAPACITOR 0.1uF 16V K
C663 HU-001060250 C CAPACITOR 0.1uF 16V K
C664 HU-001071223 E CAPACITOR 100uF 16V
C700 HU-001060250 C CAPACITOR 0.1uF 16V K
C701 HU-001071223 E CAPACITOR 100uF 16V
C750 HU-001071192 E CAPACITOR 10uF 25V
C751 HU-001071192 E CAPACITOR 10uF 25V
C752 HU-001060286 C CAPACITOR 10uF 10V
C753 HU-001060250 C CAPACITOR 0.1uF 16V K
C754 HU-001071192 E CAPACITOR 10uF 25V
C755 HU-001071192 E CAPACITOR 10uF 25V
C756 HU-001060250 C CAPACITOR 0.1uF 16V K
C757 HU-001060250 C CAPACITOR 0.1uF 16V K
C809 HU-001071223 E CAPACITOR 100uF 16V
C810 HU-001060286 C CAPACITOR 10uF 10V
C811 HU-001060286 C CAPACITOR 10uF 10V
C812 HU-001071223 E CAPACITOR 100uF 16V
C813 HU-001060250 C CAPACITOR 0.1uF 16V K
C814 HU-001060250 C CAPACITOR 0.1uF 16V K
C815 HU-001060249 C CAPACITOR 100pF 50V J
C816 HU-001071223 E CAPACITOR 100uF 16V
C817 HU-001060286 C CAPACITOR 10uF 10V
C819 HU-001071223 E CAPACITOR 100uF 16V
C820 HU-001060286 C CAPACITOR 10uF 10V
C821 HU-001060286 C CAPACITOR 10uF 10V
C822 HU-001060250 C CAPACITOR 0.1uF 16V K
C823 HU-001071223 E CAPACITOR 100uF 16V
C825 HU-001071223 E CAPACITOR 100uF 16V
C826 HU-001060286 C CAPACITOR 10uF 10V
C827 HU-001071223 E CAPACITOR 100uF 16V
C828 HU-001060286 C CAPACITOR 10uF 10V
C900 HU-001060250 C CAPACITOR 0.1uF 16V K
C902 HU-001060250 C CAPACITOR 0.1uF 16V K
C903 HU-001071194 E CAPACITOR 100uF 25V
C904 HU-001071194 E CAPACITOR 100uF 25V
C905 HU-001060250 C CAPACITOR 0.1uF 16V K
C906 HU-001071194 E CAPACITOR 100uF 25V
PR2 HU-002070006 NET RESISTOR 47
Ω x4
PR3 HU-002070006 NET RESISTOR 47
Ω x4
PR5 HU-002070006 NET RESISTOR 47
Ω x4
PR6 HU-002070006 NET RESISTOR 47
Ω x4
PR40 HU-002070003 NET RESISTOR 10k
Ω x4
PR41 HU-002070003 NET RESISTOR 10k
Ω x4
PR280 HU-002070006 NET RESISTOR 47
Ω x4
PR281 HU-002070006 NET RESISTOR 47
Ω x4
PR282 HU-002070006 NET RESISTOR 47
Ω x4
PR380 HU-002070050 NET RESISTOR 47
Ω x4
PR381 HU-002070050 NET RESISTOR 47
Ω x4
PR382 HU-002070050 NET RESISTOR 47
Ω x4
 Ref No. Part No. Part Name Description Local
