JVC LT-19DA9 Series - Ir P.w. Board Assy (Hu-72200001); Key P.w. Board Assy (Hu-72200002)

(No.YA606<Rev.002>)3-21
IR P.W. BOARD ASS'Y (HU-72200001)
REFER TO PARTS LIST IN PAGE 3-11 FOR THIS P.W. BOARD.
KEY P.W. BOARD ASS'Y (HU-72200002)
REFER TO PARTS LIST IN PAGE 3-11 FOR THIS P.W. BOARD.
PR383 HU-002070050 NET RESISTOR 47 Ω x4
PR750 HU-002070014 NET RESISTOR 33
Ω x4
R1 HU-002000090 COIL
R3 HU-002000520 MG RESISTOR 47
Ω
R4 HU-002000520 MG RESISTOR 47 Ω
R6 HU-002000520 MG RESISTOR 47 Ω
R9 HU-002000520 MG RESISTOR 47 Ω
R10 HU-002000520 MG RESISTOR 47 Ω
R11 HU-002000520 MG RESISTOR 47 Ω
R12 HU-002000437 MG RESISTOR 10k Ω
R13 HU-002000417 MG RESISTOR 4.7k Ω
R16 HU-002000417 MG RESISTOR 4.7k Ω
R18 HU-002000090 COIL
R40 HU-002000087 MG RESISTOR 4.7k
Ω
R41 HU-002000096 MG RESISTOR 10k Ω
R42 HU-002000417 MG RESISTOR 4.7k Ω
R43 HU-002000538 MG RESISTOR 120 Ω
R45 HU-002000417 MG RESISTOR 4.7k Ω
R46 HU-002000096 MG RESISTOR 10k Ω
R47 HU-002000437 MG RESISTOR 10k Ω
R48 HU-002000437 MG RESISTOR 10k Ω
R49 HU-002000437 MG RESISTOR 10k Ω
R50 HU-002000417 MG RESISTOR 4.7k Ω
R51 HU-002000417 MG RESISTOR 4.7k Ω
R52 HU-002000437 MG RESISTOR 10k Ω
R53 HU-002000437 MG RESISTOR 10k Ω
R54 HU-002000437 MG RESISTOR 10k Ω
R55 HU-002000437 MG RESISTOR 10k Ω
R56 HU-002000437 MG RESISTOR 10k Ω
R57 HU-002000437 MG RESISTOR 10k Ω
R58 HU-002000417 MG RESISTOR 4.7k Ω
R80 HU-002000527 MG RESISTOR 100 Ω
R82 HU-002000527 MG RESISTOR 100 Ω
R84 HU-002000527 MG RESISTOR 100 Ω
R86 HU-002000527 MG RESISTOR 100 Ω
R88 HU-002000527 MG RESISTOR 100 Ω
R90 HU-002000527 MG RESISTOR 100 Ω
R92 HU-002000527 MG RESISTOR 100 Ω
R94 HU-002000527 MG RESISTOR 100 Ω
R99 HU-002000527 MG RESISTOR 100 Ω
R100 HU-002000527 MG RESISTOR 100 Ω
R101 HU-002000527 MG RESISTOR 100 Ω
R102 HU-002000437 MG RESISTOR 10k Ω
R116 HU-002000437 MG RESISTOR 10k Ω
R230 HU-002000417 MG RESISTOR 4.7k Ω
R231 HU-002000527 MG RESISTOR 100 Ω
R232 HU-002000527 MG RESISTOR 100 Ω
R280 HU-002000417 MG RESISTOR 4.7k Ω
R281 HU-002000417 MG RESISTOR 4.7k Ω
R283 HU-002000526 MG RESISTOR 3.3k Ω
R284 HU-002000526 MG RESISTOR 3.3k Ω
R287 HU-002000454 MG RESISTOR 47k Ω
R290 HU-002000433 MG RESISTOR 0 Ω
R291 HU-002000417 MG RESISTOR 4.7k Ω
R293 HU-002000433 MG RESISTOR 0 Ω
R294 HU-002000405 MG RESISTOR 1k Ω
R295 HU-002000118 MG RESISTOR 33 Ω
R296 HU-002000118 MG RESISTOR 33 Ω
R298 HU-002000433 MG RESISTOR 0 Ω
R299 HU-002000433 MG RESISTOR 0 Ω
R380 HU-002000417 MG RESISTOR 4.7k Ω
R382 HU-002000437 MG RESISTOR 10k Ω
R384 HU-002000437 MG RESISTOR 10k Ω
R385 HU-002000448 MG RESISTOR 33 Ω
R387 HU-002000417 MG RESISTOR 4.7k Ω
R389 HU-002000437 MG RESISTOR 10k Ω
R390 HU-002000437 MG RESISTOR 10k Ω
R391 HU-002000417 MG RESISTOR 4.7k Ω
R392 HU-002000417 MG RESISTOR 4.7k Ω
R393 HU-002001050 MG RESISTOR 2.7k Ω
R394 HU-002001050 MG RESISTOR 2.7k Ω
R402 HU-002000520 MG RESISTOR 47 Ω
R404 HU-002000405 MG RESISTOR 1k Ω
R405 HU-002000522 MG RESISTOR 680 Ω
R408 HU-002000405 MG RESISTOR 1k Ω
R411 HU-002000405 MG RESISTOR 1k Ω
R441 HU-002000516 MG RESISTOR 1.2k Ω
R442 HU-002000601 MG RESISTOR 20 Ω
R443 HU-002000601 MG RESISTOR 20 Ω
R444 HU-002000421 MG RESISTOR 75 Ω
R445 HU-002000421 MG RESISTOR 75 Ω
R446 HU-002000443 MG RESISTOR 22 Ω
R483 HU-002000437 MG RESISTOR 10k Ω
R484 HU-002000437 MG RESISTOR 10k Ω
R580 HU-002000417 MG RESISTOR 4.7k Ω
R631 HU-002000421 MG RESISTOR 75 Ω
R633 HU-002000421 MG RESISTOR 75 Ω
R635 HU-002000421 MG RESISTOR 75 Ω
R637 HU-002000421 MG RESISTOR 75 Ω
 Ref No. Part No. Part Name Description Local
R700 HU-002000407 MG RESISTOR 2.2K Ω
R701 HU-002000437 MG RESISTOR 10k Ω
R702 HU-002000437 MG RESISTOR 10k Ω
R703 HU-002000437 MG RESISTOR 10k Ω
R704 HU-002000407 MG RESISTOR 2.2K Ω
R705 HU-002000437 MG RESISTOR 10k Ω
R750 HU-002000417 MG RESISTOR 4.7k Ω
R751 HU-002000453 MG RESISTOR 470 Ω
R752 HU-002000453 MG RESISTOR 470 Ω
R753 HU-002000433 MG RESISTOR 0 Ω
R802 HU-002000547 MG RESISTOR 120 Ω
R803 HU-002000509 MG RESISTOR 200 Ω
R806 HU-002000547 MG RESISTOR 120 Ω
R807 HU-002000509 MG RESISTOR 200 Ω
R808 HU-002000547 MG RESISTOR 120 Ω
R809 HU-002001002 MG RESISTOR 56 Ω
R900 HU-002000433 MG RESISTOR 0 Ω
R901 HU-002000433 MG RESISTOR 0 Ω
R902 HU-002000433 MG RESISTOR 0 Ω
R903 HU-002000433 MG RESISTOR 0 Ω
R904 HU-002000433 MG RESISTOR 0 Ω
R905 HU-002000433 MG RESISTOR 0 Ω
R906 HU-002000433 MG RESISTOR 0 Ω
R907 HU-002000433 MG RESISTOR 0 Ω
R908 HU-002000433 MG RESISTOR 0 Ω
L1 NQR0129-003X FERRITE BEADS
L40 NQR0129-003X FERRITE BEADS
L230 NQR0154-002X FERRITE CORE
L231 NQR0154-002X FERRITE CORE
L232 HU-002000090 COIL
L233 HU-002000090 COIL
L280 NQR0154-002X FERRITE CORE
L281 NQR0154-002X FERRITE CORE
L282 NQR0154-002X FERRITE CORE
L283 NQR0154-002X FERRITE CORE
L284 NQR0154-002X FERRITE CORE
L285 NQR0154-002X FERRITE CORE
L288 NQR0154-002X FERRITE CORE
L330 NQR0154-002X FERRITE CORE
L331 NQR0154-002X FERRITE CORE
L332 NQR0154-002X FERRITE CORE
L333 NQR0154-002X FERRITE CORE
L580 NQR0154-002X FERRITE CORE
L630 HU-002000090 COIL
L631 HU-011000065 INDUCTOR 1.5uH
L632 HU-011000065 INDUCTOR 1.5uH
L633 HU-011000065 INDUCTOR 1.5uH
L660 NQR0154-002X FERRITE CORE
L661 NQR0154-002X FERRITE CORE
L662 NQR0154-002X FERRITE CORE
L663 HU-002000090 COIL
L664 NQR0129-003X FERRITE BEADS
L665 HU-002000090 COIL
L666 HU-002000090 COIL
L667 NQR0129-003X FERRITE BEADS
L668 NQR0154-002X FERRITE CORE
L750 NQR0154-002X FERRITE CORE
L806 NQR0154-007X FERRITE CORE
L900 NQR0154-002X FERRITE CORE
L901 HU-011030025 FERRITE BEADS
L902 HU-011030025 FERRITE BEADS
JP40 HU-009030060 PCMCIA CONNECTOR CI SLOT
Y280 HU-005000940 CRYSTAL 16MHz
Y380 HU-005000880 CRYSTAL 4MHz
 Ref No. Part No. Part Name Description Local
