JVC LT-19DA9 Series - Ir P.w. Board Assy (Hu-72200001); Key P.w. Board Assy (Hu-72200002)

3-14(No.YA606<Rev.002>)
IR P.W. BOARD ASS'Y (HU-72200001)
REFER TO PARTS LIST IN PAGE 3-11 FOR THIS P.W. BOARD.
KEY P.W. BOARD ASS'Y (HU-72200002)
REFER TO PARTS LIST IN PAGE 3-11 FOR THIS P.W. BOARD.
R703 HU-002000437 MG RESISTOR 10k Ω
R704 HU-002000407 MG RESISTOR 2.2K Ω
R705 HU-002000437 MG RESISTOR 10k Ω
R750 HU-002000417 MG RESISTOR 4.7k Ω
R751 HU-002000453 MG RESISTOR 470 Ω
R752 HU-002000453 MG RESISTOR 470 Ω
R753 HU-002000433 MG RESISTOR 0 Ω
R800 HU-002000547 MG RESISTOR 120 Ω
R801 HU-002000509 MG RESISTOR 200 Ω
R802 HU-002000548 MG RESISTOR 1.2k Ω
R803 HU-002001152 MG RESISTOR 680 Ω
R804 HU-002000405 MG RESISTOR 1k Ω
R806 HU-002000547 MG RESISTOR 120 Ω
R807 HU-002000509 MG RESISTOR 200 Ω
R900 HU-002000433 MG RESISTOR 0 Ω
R901 HU-002000433 MG RESISTOR 0 Ω
R902 HU-002000433 MG RESISTOR 0 Ω
R903 HU-002000433 MG RESISTOR 0 Ω
R904 HU-002000433 MG RESISTOR 0 Ω
R905 HU-002000433 MG RESISTOR 0 Ω
R906 HU-002000433 MG RESISTOR 0 Ω
R907 HU-002000433 MG RESISTOR 0 Ω
R908 HU-002000433 MG RESISTOR 0 Ω
R909 HU-002000433 MG RESISTOR 0 Ω
R911 HU-002000526 MG RESISTOR 3.3k Ω
L1 NQR0129-003X FERRITE BEADS
L40 NQR0129-003X FERRITE BEADS
L130 NQR0154-002X FERRITE CORE
L131 NQR0154-002X FERRITE CORE
L132 NQR0154-002X FERRITE CORE
L180 NQR0154-007X FERRITE CORE
L181 NQR0154-007X FERRITE CORE
L182 NQR0154-007X FERRITE CORE
L183 NQR0154-007X FERRITE CORE
L184 NQR0154-007X FERRITE CORE
L230 NQR0154-002X FERRITE CORE
L231 NQR0154-002X FERRITE CORE
L232 NQR0154-002X FERRITE CORE
L233 NQR0154-002X FERRITE CORE
L280 NQR0154-002X FERRITE CORE
L281 NQR0154-002X FERRITE CORE
L282 HU-011001390 INDUCTOR 22uH
L283 HU-011040002 FERRITE BEADS
L380 NQR0154-002X FERRITE CORE
L381 HU-002000090 COIL
L382 HU-002000090 COIL
L383 NQR0154-002X FERRITE CORE
L385 NQR0154-002X FERRITE CORE
L386 NQR0154-002X FERRITE CORE
L390 NQR0154-002X FERRITE CORE
L391 NQR0154-002X FERRITE CORE
L392 NQR0154-002X FERRITE CORE
L393 NQR0154-002X FERRITE CORE
L430 HU-002000090 COIL
L431 HU-002000090 COIL
L530 NQR0154-002X FERRITE CORE
L531 NQR0154-002X FERRITE CORE
L580 NQR0154-002X FERRITE CORE
L750 NQR0154-002X FERRITE CORE
L805 NQR0154-007X FERRITE CORE
L900 NQR0154-002X FERRITE CORE
L901 HU-011030025 FERRITE BEADS
L902 HU-011030025 FERRITE BEADS
JP40 HU-009030060 PCMCIA CONNECTOR CI SLOT
Y180 HU-005000940 CRYSTAL 16MHz
Y430 HU-005001080 CRYSTAL 27MHz
 Ref No. Part No. Part Name Description Local
