(No.YA606<Rev.002>)3-9
MPEG P.W. BOARD ASS'Y (HU-71200005)
Ref No. Part No. Part Name Description Local
U1 HU-000030020 IC ASIC
U2 HU-000120027 IC
CMOS 1-INPUT INVERTER
U80 SN74LVC244APW-X IC CMOS
U82 SN74LVC244APW-X IC CMOS
U130 HU-014040930 TUNER
U131 HU-000300001 IC
DUAL COMPARATOR
U180 HU-000270090 IC DEMODULATOR
U380 HU-000100410 IC DECODER
U430 HU-000990052 IC
VOLTAGE DETECTOR
U432 HU-000990140 IC VCXO 27MHz
U530 HU-000040710 IC SDRAM
U531 HU-000040930 IC SDRAM
U580 HU-000060016 IC OP AMP
U750 HU-000140450 IC AUDIO DAC
U800 HU-000090760 IC REGULATOR
U801 HU-000091100 IC REGULATOR
U802 HU-000091100 IC REGULATOR
U803 BA50BC0WFP-X IC REGULATOR
U804 HU-000091100 IC REGULATOR
Q40 HU-004020004 FET
Q41 HU-004001001 TRANSISTOR
Q80 HU-004001001 TRANSISTOR
Q430 HU-004001001 TRANSISTOR
Q431 HU-004001001 TRANSISTOR
Q432 HU-004001001 TRANSISTOR
Q433 HU-004001001 TRANSISTOR
Q434 HU-004001001 TRANSISTOR
Q700 HU-004001001 TRANSISTOR
D800 HU-003000004 SI DIODE
C1 HU-001060250 C CAPACITOR 0.1uF 16V K
C2 HU-001060250 C CAPACITOR 0.1uF 16V K
C3 HU-001060250 C CAPACITOR 0.1uF 16V K
C4 HU-001060250 C CAPACITOR 0.1uF 16V K
C5 HU-001060250 C CAPACITOR 0.1uF 16V K
C40 HU-001060282 C CAPACITOR 6.8nF 50V K
C41 HU-001060250 C CAPACITOR 0.1uF 16V K
C42 HU-001060250 C CAPACITOR 0.1uF 16V K
C43 HU-001060250 C CAPACITOR 0.1uF 16V K
C44 HU-001060267 C CAPACITOR 68pF 50V J
C45 HU-001060250 C CAPACITOR 0.1uF 16V K
C46 HU-001060250 C CAPACITOR 0.1uF 16V K
C80 HU-001060250 C CAPACITOR 0.1uF 16V K
C81 HU-001060250 C CAPACITOR 0.1uF 16V K
C82 HU-001060250 C CAPACITOR 0.1uF 16V K
C130 HU-001071224 E CAPACITOR 220uF 16V
C131 HU-001060250 C CAPACITOR 0.1uF 16V K
C132 HU-001060250 C CAPACITOR 0.1uF 16V K
C133 HU-001060250 C CAPACITOR 0.1uF 16V K
C134 HU-001060219 C CAPACITOR 1000pF 50V K
C135 HU-001071224 E CAPACITOR 220uF 16V
C136 HU-001060250 C CAPACITOR 0.1uF 16V K
C137 HU-001060219 C CAPACITOR 1000pF 50V K
C138 HU-001060250 C CAPACITOR 0.1uF 16V K
C141 HU-001071224 E CAPACITOR 220uF 16V
C142 HU-001060250 C CAPACITOR 0.1uF 16V K
C143 HU-001060219 C CAPACITOR 1000pF 50V K
C180 HU-001060250 C CAPACITOR 0.1uF 16V K
C181 HU-001060250 C CAPACITOR 0.1uF 16V K
C183 HU-001060265 C CAPACITOR 1uF 16V K
C184 HU-001060265 C CAPACITOR 1uF 16V K
C186 HU-001060258 C CAPACITOR 30pF 50V J
C187 HU-001060258 C CAPACITOR 30pF 50V J
C188 HU-001060250 C CAPACITOR 0.1uF 16V K
C189 HU-001060250 C CAPACITOR 0.1uF 16V K
C190 HU-001060250 C CAPACITOR 0.1uF 16V K
C191 HU-001060250 C CAPACITOR 0.1uF 16V K
C192 HU-001060250 C CAPACITOR 0.1uF 16V K
C193 HU-001060250 C CAPACITOR 0.1uF 16V K
C194 HU-001060250 C CAPACITOR 0.1uF 16V K
C195 HU-001060250 C CAPACITOR 0.1uF 16V K
C330 HU-001060286 C CAPACITOR 10uF 10V
C331 HU-001060250 C CAPACITOR 0.1uF 16V K
C332 HU-001060250 C CAPACITOR 0.1uF 16V K
C333 HU-001060250 C CAPACITOR 0.1uF 16V K
C334 HU-001060250 C CAPACITOR 0.1uF 16V K
C335 HU-001060250 C CAPACITOR 0.1uF 16V K
C336 HU-001060250 C CAPACITOR 0.1uF 16V K
C337 HU-001060250 C CAPACITOR 0.1uF 16V K
C338 HU-001060286 C CAPACITOR 10uF 10V
C339 HU-001060286 C CAPACITOR 10uF 10V
C340 HU-001060286 C CAPACITOR 10uF 10V
C341 HU-001060250 C CAPACITOR 0.1uF 16V K
C342 HU-001060250 C CAPACITOR 0.1uF 16V K
C343 HU-001060250 C CAPACITOR 0.1uF 16V K
C344 HU-001060250 C CAPACITOR 0.1uF 16V K
C345 HU-001060250 C CAPACITOR 0.1uF 16V K
C346 HU-001060250 C CAPACITOR 0.1uF 16V K
C347 HU-001060250 C CAPACITOR 0.1uF 16V K
C380 HU-001060250 C CAPACITOR 0.1uF 16V K
C381 HU-001060286 C CAPACITOR 10uF 10V
C382 HU-001060219 C CAPACITOR 1000pF 50V K
C383 HU-001060250 C CAPACITOR 0.1uF 16V K
C384 HU-001060286 C CAPACITOR 10uF 10V
C385 HU-001060219 C CAPACITOR 1000pF 50V K
C386 HU-001060250 C CAPACITOR 0.1uF 16V K
C387 HU-001060286 C CAPACITOR 10uF 10V
C388 HU-001060219 C CAPACITOR 1000pF 50V K
C389 HU-001060250 C CAPACITOR 0.1uF 16V K
C390 HU-001060286 C CAPACITOR 10uF 10V
C430 HU-001060250 C CAPACITOR 0.1uF 16V K
C431 HU-001071221 E CAPACITOR 4.7uF 35V
C432 HU-001060150 C CAPACITOR 1uF 25V
C433 HU-001060250 C CAPACITOR 0.1uF 16V K
C434 HU-001060250 C CAPACITOR 0.1uF 16V K
C435 HU-001060219 C CAPACITOR 1000pF 50V K
C436 HU-001060286 C CAPACITOR 10uF 10V
C437 HU-001063090 C CAPACITOR 3.3pF 50V
C438 HU-001060108 C CAPACITOR 0.01uF 50V
C480 HU-001060250 C CAPACITOR 0.1uF 16V K
C481 HU-001060250 C CAPACITOR 0.1uF 16V K
C482 HU-001060286 C CAPACITOR 10uF 10V
C483 HU-001060250 C CAPACITOR 0.1uF 16V K
C484 HU-001060250 C CAPACITOR 0.1uF 16V K
C530 HU-001060250 C CAPACITOR 0.1uF 16V K
C531 HU-001060250 C CAPACITOR 0.1uF 16V K
C532 HU-001060250 C CAPACITOR 0.1uF 16V K
C533 HU-001060250 C CAPACITOR 0.1uF 16V K
C534 HU-001060250 C CAPACITOR 0.1uF 16V K
C535 HU-001060286 C CAPACITOR 10uF 10V
C536 HU-001060250 C CAPACITOR 0.1uF 16V K
C537 HU-001060250 C CAPACITOR 0.1uF 16V K
C538 HU-001060250 C CAPACITOR 0.1uF 16V K
C539 HU-001060250 C CAPACITOR 0.1uF 16V K
C540 HU-001060250 C CAPACITOR 0.1uF 16V K
C541 HU-001060286 C CAPACITOR 10uF 10V
C580 HU-001060250 C CAPACITOR 0.1uF 16V K
C581 HU-001071223 E CAPACITOR 100uF 16V
C582 HU-001060250 C CAPACITOR 0.1uF 16V K
C583 HU-001060250 C CAPACITOR 0.1uF 16V K
C585 HU-001060221 C CAPACITOR 22pF 50V J
C587 HU-001060221 C CAPACITOR 22pF 50V J
C589 HU-001060221 C CAPACITOR 22pF 50V J
C591 HU-001060221 C CAPACITOR 22pF 50V J
C700 HU-001060250 C CAPACITOR 0.1uF 16V K
C701 HU-001071223 E CAPACITOR 100uF 16V
C750 HU-001071192 E CAPACITOR 10uF 25V
C751 HU-001071192 E CAPACITOR 10uF 25V
C752 HU-001060286 C CAPACITOR 10uF 10V
C753 HU-001060250 C CAPACITOR 0.1uF 16V K
C754 HU-001071192 E CAPACITOR 10uF 25V
C755 HU-001071192 E CAPACITOR 10uF 25V
C756 HU-001060250 C CAPACITOR 0.1uF 16V K
C757 HU-001060250 C CAPACITOR 0.1uF 16V K
C802 HU-001060286 C CAPACITOR 10uF 10V
C803 HU-001071223 E CAPACITOR 100uF 16V
C804 HU-001071223 E CAPACITOR 100uF 16V
C806 HU-001060286 C CAPACITOR 10uF 10V
C807 HU-001060286 C CAPACITOR 10uF 10V
C809 HU-001071223 E CAPACITOR 100uF 16V
C810 HU-001060286 C CAPACITOR 10uF 10V
C811 HU-001060286 C CAPACITOR 10uF 10V
C812 HU-001071223 E CAPACITOR 100uF 16V
C813 HU-001060250 C CAPACITOR 0.1uF 16V K
C814 HU-001060250 C CAPACITOR 0.1uF 16V K
C815 HU-001060249 C CAPACITOR 100pF 50V J
C816 HU-001071223 E CAPACITOR 100uF 16V
C817 HU-001060250 C CAPACITOR 0.1uF 16V K
C819 HU-001071223 E CAPACITOR 100uF 16V
C820 HU-001060286 C CAPACITOR 10uF 10V
C821 HU-001060286 C CAPACITOR 10uF 10V
C822 HU-001071228 E CAPACITOR 470uF 16V
C823 HU-001060250 C CAPACITOR 0.1uF 16V K
C824 HU-001060250 C CAPACITOR 0.1uF 16V K
C900 HU-001060250 C CAPACITOR 0.1uF 16V K
C901 HU-001060250 C CAPACITOR 0.1uF 16V K
C902 HU-001060250 C CAPACITOR 0.1uF 16V K
C903 HU-001071194 E CAPACITOR 100uF 25V
C904 HU-001071194 E CAPACITOR 100uF 25V
C905 HU-001060250 C CAPACITOR 0.1uF 16V K
C906 HU-001071194 E CAPACITOR 100uF 25V
PR2 HU-002070006 NET RESISTOR 47
Ω
x4
PR3 HU-002070006 NET RESISTOR 47
Ω
x4
Ref No. Part No. Part Name Description Local
