JVC LT-19DA9 Series Service Manual

3-6(No.YA606<Rev.002>)
C237 HU-001060236 C CAPACITOR 10uF 25V
C238 HU-001060219 C CAPACITOR 1000pF 50V K
C263 HU-001060219 C CAPACITOR 1000pF 50V K
C264 HU-001060219 C CAPACITOR 1000pF 50V K
C265 HU-001060236 C CAPACITOR 10uF 25V
C266 HU-001060219 C CAPACITOR 1000pF 50V K
C267 HU-001060236 C CAPACITOR 10uF 25V
C268 HU-001060219 C CAPACITOR 1000pF 50V K
C299 HU-001060250 C CAPACITOR 0.1uF 16V K
C370 HU-001060250 C CAPACITOR 0.1uF 16V K
C371 HU-001060250 C CAPACITOR 0.1uF 16V K
C372 HU-001060286 C CAPACITOR 10uF 10V
C373 HU-001060250 C CAPACITOR 0.1uF 16V K
C374 HU-001060286 C CAPACITOR 10uF 10V
C375 HU-001060250 C CAPACITOR 0.1uF 16V K
C470 HU-001060219 C CAPACITOR 1000pF 50V K
C471 HU-001060219 C CAPACITOR 1000pF 50V K
C472 HU-001060219 C CAPACITOR 1000pF 50V K
C473 HU-001060219 C CAPACITOR 1000pF 50V K
C474 HU-001060219 C CAPACITOR 1000pF 50V K
C475 HU-001060297 C CAPACITOR 0.01pF 50V K
C476 HU-001060297 C CAPACITOR 0.01pF 50V K
C477 HU-001060297 C CAPACITOR 0.01pF 50V K
C488 HU-001060250 C CAPACITOR 0.1uF 16V K
C489 HU-001060250 C CAPACITOR 0.1uF 16V K
C490 HU-001060250 C CAPACITOR 0.1uF 16V K
C491 HU-001060250 C CAPACITOR 0.1uF 16V K
C492 HU-001060250 C CAPACITOR 0.1uF 16V K
C493 HU-001060250 C CAPACITOR 0.1uF 16V K
C494 HU-001060250 C CAPACITOR 0.1uF 16V K
C495 HU-001060250 C CAPACITOR 0.1uF 16V K
C496 HU-001060250 C CAPACITOR 0.1uF 16V K
C497 HU-001060288 C CAPACITOR 1uF 25V
C498 HU-001060286 C CAPACITOR 10uF 10V
C499 HU-001060286 C CAPACITOR 10uF 10V
C500 HU-001060286 C CAPACITOR 10uF 10V
C501 HU-001060286 C CAPACITOR 10uF 10V
C502 HU-001060286 C CAPACITOR 10uF 10V
C503 HU-001060273 C CAPACITOR 24pF 50V
C504 HU-001060273 C CAPACITOR 24pF 50V
C505 HU-001063027 C CAPACITOR 2pF 50V
C560 HU-001060286 C CAPACITOR 10uF 10V
C561 HU-001060236 C CAPACITOR 10uF 25V
C562 HU-001060236 C CAPACITOR 10uF 25V
C563 HU-001060250 C CAPACITOR 0.1uF 16V K
C564 HU-001060236 C CAPACITOR 10uF 25V
C565 HU-001060236 C CAPACITOR 10uF 25V
C566 HU-001060250 C CAPACITOR 0.1uF 16V K
C567 HU-001060250 C CAPACITOR 0.1uF 16V K
C580 HU-001060219 C CAPACITOR 1000pF 50V K
C581 HU-001060288 C CAPACITOR 1uF 25V
C582 HU-001071082 E CAPACITOR 470uF 25V
C583 HU-001060288 C CAPACITOR 1uF 25V
C584 HU-001060288 C CAPACITOR 1uF 25V
C585 HU-001071082 E CAPACITOR 470uF 25V
C586 HU-001060288 C CAPACITOR 1uF 25V
C587 HU-001060219 C CAPACITOR 1000pF 50V K
C588 HU-001060199 C CAPACITOR 0.22uF 25V
C589 HU-001060199 C CAPACITOR 0.22uF 25V
C590 HU-001060288 C CAPACITOR 1uF 25V
C591 HU-001060288 C CAPACITOR 1uF 25V
C592 HU-001060224 C CAPACITOR 0.47uF 16V
C593 HU-001060288 C CAPACITOR 1uF 25V
C594 HU-001060219 C CAPACITOR 1000pF 50V K
C595 HU-001060288 C CAPACITOR 1uF 25V
C596 HU-001060199 C CAPACITOR 0.22uF 25V
C597 HU-001060199 C CAPACITOR 0.22uF 25V
C598 HU-001060199 C CAPACITOR 0.22uF 25V
C599 HU-001060199 C CAPACITOR 0.22uF 25V
C600 HU-001060224 C CAPACITOR 0.47uF 16V
C601 HU-001060199 C CAPACITOR 0.22uF 25V
C602 HU-001060199 C CAPACITOR 0.22uF 25V
C603 HU-001060230 C CAPACITOR 0.022uF 16V K
C604 HU-001060297 C CAPACITOR 0.01pF 50V K
C605 HU-001060288 C CAPACITOR 1uF 25V
C606 HU-001060230 C CAPACITOR 0.022uF 16V K
C607 HU-001060250 C CAPACITOR 0.1uF 16V K
C608 HU-001060288 C CAPACITOR 1uF 25V
C610 HU-001071191 E CAPACITOR 47uF 16V
C611 HU-001071191 E CAPACITOR 47uF 16V
C612 HU-001060288 C CAPACITOR 1uF 25V
C613 HU-001060288 C CAPACITOR 1uF 25V
C615 HU-001060286 C CAPACITOR 10uF 10V
C616 HU-001060288 C CAPACITOR 1uF 25V
C630 HU-001060288 C CAPACITOR 1uF 25V
C631 HU-001060250 C CAPACITOR 0.1uF 16V K
C632 HU-001060236 C CAPACITOR 10uF 25V
C633 HU-001060105 C CAPACITOR 0.1uF 50V
C636 HU-001060236 C CAPACITOR 10uF 25V
 Ref No. Part No. Part Name Description Local
C637 HU-001060250 C CAPACITOR 0.1uF 16V K
C660 HU-001060250 C CAPACITOR 0.1uF 16V K
C661 HU-001060250 C CAPACITOR 0.1uF 16V K
C662 HU-001060250 C CAPACITOR 0.1uF 16V K
C663 HU-001060250 C CAPACITOR 0.1uF 16V K
C664 HU-001060286 C CAPACITOR 10uF 10V
C665 HU-001060250 C CAPACITOR 0.1uF 16V K
C680 HU-001060250 C CAPACITOR 0.1uF 16V K
C681 HU-001071236 E CAPACITOR 470uF 16V
C682 HU-001060250 C CAPACITOR 0.1uF 16V K
C683 HU-001071236 E CAPACITOR 470uF 16V
C684 HU-001060318 C CAPACITOR 0.1uF 50V
C685 HU-001071236 E CAPACITOR 470uF 16V
C686 HU-001060250 C CAPACITOR 0.1uF 16V K
C687 HU-001060286 C CAPACITOR 10uF 10V
C688 HU-001060250 C CAPACITOR 0.1uF 16V K
C724 HU-001071223 E CAPACITOR 100uF 16V
C726 HU-001060286 C CAPACITOR 10uF 10V
C728 HU-001060312 C CAPACITOR 22uF 6.3V M
C729 HU-001060312 C CAPACITOR 22uF 6.3V M
C730 HU-001060312 C CAPACITOR 22uF 6.3V M
C731 HU-001060250 C CAPACITOR 0.1uF 16V K
C732 HU-001071223 E CAPACITOR 100uF 16V
C733 HU-001060312 C CAPACITOR 22uF 6.3V M
C734 HU-001060297 C CAPACITOR 0.01pF 50V K
C737 HU-001060286 C CAPACITOR 10uF 10V
C738 HU-001060250 C CAPACITOR 0.1uF 16V K
C743 HU-001071223 E CAPACITOR 100uF 16V
C745 HU-001060286 C CAPACITOR 10uF 10V
C746 HU-001060250 C CAPACITOR 0.1uF 16V K
C747 HU-001071223 E CAPACITOR 100uF 16V
C748 HU-001060250 C CAPACITOR 0.1uF 16V K
C751 HU-001060250 C CAPACITOR 0.1uF 16V K
C752 HU-001060286 C CAPACITOR 10uF 10V
C753 HU-001060250 C CAPACITOR 0.1uF 16V K
C754 HU-001060274 C CAPACITOR 3300pF 50V
C770 HU-001060250 C CAPACITOR 0.1uF 16V K
C772 HU-001071228 E CAPACITOR 470uF 16V
C773 HU-001060309 C CAPACITOR 10uF 16V K
C774 HU-001060250 C CAPACITOR 0.1uF 16V K
C775 HU-001060309 C CAPACITOR 10uF 16V K
C776 HU-001060105 C CAPACITOR 0.1uF 50V
C777 HU-001060309 C CAPACITOR 10uF 16V K
C778 HU-001060250 C CAPACITOR 0.1uF 16V K
C779 HU-001060249 C CAPACITOR 100pF 50V J
C780 HU-001071225 E CAPACITOR 2.2uF 50V
C781 HU-001060171 C CAPACITOR 33pF 50V
C782 HU-001060171 C CAPACITOR 33pF 50V
C800 HU-001060250 C CAPACITOR 0.1uF 16V K
C801 HU-001060346 C CAPACITOR 1uF 16V K
C802 HU-001060286 C CAPACITOR 10uF 10V
C803 HU-001060250 C CAPACITOR 0.1uF 16V K
C804 HU-001060250 C CAPACITOR 0.1uF 16V K
C805 HU-001060250 C CAPACITOR 0.1uF 16V K
C807 HU-001060250 C CAPACITOR 0.1uF 16V K
C808 HU-001060250 C CAPACITOR 0.1uF 16V K
C809 HU-001063058 C CAPACITOR 18pF 50V J
C810 HU-001063058 C CAPACITOR 18pF 50V J
C840 HU-001060219 C CAPACITOR 1000pF 50V K
C841 HU-001060219 C CAPACITOR 1000pF 50V K
PR470 HU-002070025 NET RESISTOR 100
Ω x4
PR471 HU-002070025 NET RESISTOR 100
Ω x4
PR472 HU-002070025 NET RESISTOR 100
Ω x4
PR473 HU-002070025 NET RESISTOR 100
Ω x4
PR474 HU-002070025 NET RESISTOR 100
Ω x4
PR475 HU-002070025 NET RESISTOR 100
Ω x4
PR560 HU-002070039 NET RESISTOR 33
Ω x4
R1 HU-002000453 MG RESISTOR 470
Ω
R2 HU-002000453 MG RESISTOR 470 Ω
R3 HU-002000453 MG RESISTOR 470 Ω
R4 HU-002000453 MG RESISTOR 470 Ω
R5 HU-002000557 MG RESISTOR 6.2k Ω
R6 HU-002000436 MG RESISTOR 100k Ω
R7 HU-002000417 MG RESISTOR 4.7k Ω
R61 HU-002000437 MG RESISTOR 10k Ω
R62 HU-002000437 MG RESISTOR 10k Ω
R63 HU-002000437 MG RESISTOR 10k Ω
R64 HU-002000437 MG RESISTOR 10k Ω
R66 HU-002000448 MG RESISTOR 33 Ω
R68 HU-002000527 MG RESISTOR 100 Ω
R70 HU-002000405 MG RESISTOR 1k Ω
R71 HU-002000405 MG RESISTOR 1k Ω
R72 HU-002000405 MG RESISTOR 1k Ω
R73 HU-002000405 MG RESISTOR 1k Ω
R75 HU-002000405 MG RESISTOR 1k Ω
R76 HU-002000405 MG RESISTOR 1k Ω
R77 HU-002000405 MG RESISTOR 1k Ω
R80 HU-002000405 MG RESISTOR 1k Ω
 Ref No. Part No. Part Name Description Local
