MPEG PWB ASS'Y (8/18)
[STI5518 Decoupling cap]
HU-71200005 [LT-26DA9BJ, LT-26DA9BU]
HU-71200006 [LT-26DB9BD]
lt-19db9bd_mpeg-09_0520_9/21_0.0
1
1
2
2
3
3
4
4
5
5
6
6
D D
C C
B B
A A
# Vcc Cap is to be located in the vicinity of STi5518
All locations are from 330 to 379 in this page
+2V5_1V8
+3V3
C343
104p/1005
C345
104p/1005
C346
104p/1005
C332
104p/1005
C333
104p/1005
C340
106p/2012
C336
104p/1005
C347
104p/1005
C341
104p/1005
C344
104p/1005
C334
104p/1005
C338
106p/2012
C331
104p/1005
C337
104p/1005
C335
104p/1005
C339
106p/2012C330
106p/2012
C342
104p/1005
MPEG PWB CIRCUIT DIAGRAM (8/18) [STI5518 Decoupling cap]
