Step 2 - Connecting your devices

Quick Setup

Notes:

• The following connection diagrams are examples.

• After you are finished connecting your devices, plug the power cord into the nearest power

outlet and turn on the TV.

• If you follow these diagrams and the television does not work properly, contact your local

cable operator.

• To connect a DVD player, see VCR Connection.

• If you have a satellite television system, refer to the satellite TV manual.

Used to connect an external

antenna or cable TV system to your

TV.

Used to make video connections

with S-Video VCRs, Camcorders

and DVD players.

Coaxial Cables

S-Video Cable

Used to connect audio/video

devices like VCRs, DVD players,

stereo amplifiers, game consoles,

etc.

Component Cables

Composite Cables

Audio Cables

To make these connections, you will use plugs like the ones illustrated below.

TV Rear Panel

Cable or Antenna

Output

Coaxial Cable

75 Ω

(VHF/UHF)

DIGITAL AUDIO

OPTICAL OUT

INPUT 1 INPUT 2

PHOTO VIEWER /

SERVICE

No VCR Connection
