JVC LT-32E488 User Manual

14
Quick Setup
Notes:
• Green, blue and red are the most common colors for DVD cables. Some models may vary
colors. Please consult the user’s manual for your DVD player for more information.
• Be careful not to confuse the red DVD cable with the red audio cable. It is best to complete
one set of connections (DVD or audio output) before starting the other to avoid accidentally
switching the cables.
• You may also connect the DVD player to Input 1.
INPUT 3 INPUT 4
S-VIDEO
Y
P
B
PR
VIDEO
L
R
COMPONENT
AUDIO
Y
P
B
PR
VIDEO
L
R
COMPONENT
AUDIO
VIDEO
L
R
AUDIO
L
R
AUDIO
75 Ω
(VHF/UHF)
DIGITAL AUDIO
OPTICAL OUT
INPUT 1 INPUT 2
PHOTO VIEWER /
SERVICE
TV Rear Panel
C
able or Antenna
Output
Coaxial Cable
VCR
DVD Player
OR
IN
OUT
IN
OUT
R L V
Y
P
B
P R
OUT
AUDIO OUT
R L
Green
Blue
Red
INPUT 5
/ INPUT 1
AUDIO
AUDIO
OUT
VCR • DVD Connection
Note:
• If this connection setup does not work for you, try the connection setup on page 15.
Diagram #1
LCT2224-001B-A English.indd 14LCT2224-001B-A English.indd 14 2/15/07 11:04:56 AM2/15/07 11:04:56 AM

JVC LT-32E488 Specifications

General

I/O ports	2 HDMI/HDCP
Processor frequency	0.075 GHz
Display diagonal	31.5 \
Display brightness	500 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Native aspect ratio	16:9
Contrast ratio (typical)	1200:1
On Screen Display (OSD)	Yes
AV input	3
RF ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	2
Product color	Black
RMS rated power	20 W

Weight and Dimensions

Depth (with stand)	230 mm
Width (with stand)	800 mm
Height (with stand)	593 mm
Weight (with stand)	14300 g
Depth (without stand)	99 mm
Height (without stand)	545 mm
Weight (without stand)	13500 g
