JVC LT-32E488 User Manual

15
Quick Setup
Diagram #2
Two-Way Splitter
(Not supplied)
Cable or Antenna
Output
TV Rear Panel
Coaxial Cable
VCR
DVD Player
Green
Blue
Red
OR
INPUT 3 INPUT 4
S-VIDEO
Y
P
B
P R
VIDEO
L
R
COMPONENT
AUDIO
Y
P
B
P R
VIDEO
L
R
COMPONENT
AUDIO
VIDEO
L
R
AUDIO
L
R
AUDIO
75 Ω
(VHF/UHF)
DIGITAL AUDIO
OPTICAL OUT
INPUT 1 INPUT 2
PHOTO VIEWER /
SERVICE
IN
OUT
IN
OUT
R L V
Y
P
B
P R
OUT
AUDIO OUT
R L
IN
OUT OUT
INPUT 5
/ INPUT 1
AUDIO
AUDIO
OUT
LCT2224-001B-A English.indd 15LCT2224-001B-A English.indd 15 2/15/07 11:04:57 AM2/15/07 11:04:57 AM

JVC LT-32E488 Specifications

General

I/O ports	2 HDMI/HDCP
Processor frequency	0.075 GHz
Display diagonal	31.5 \
Display brightness	500 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Native aspect ratio	16:9
Contrast ratio (typical)	1200:1
On Screen Display (OSD)	Yes
AV input	3
RF ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	2
Product color	Black
RMS rated power	20 W

Weight and Dimensions

Depth (with stand)	230 mm
Width (with stand)	800 mm
Height (with stand)	593 mm
Weight (with stand)	14300 g
Depth (without stand)	99 mm
Height (without stand)	545 mm
Weight (without stand)	13500 g
