3-10(No.YA180)
FRONT CONTROL P.W. BOARD ASS'Y
(SFL-7011A-M2)
FRONT SENSOR PWB P.W. BOARD ASS'Y
(SFL-8011A-M2)
REGULATOR P.W. BOARD ASS'Y (SFL-9105A-M2)
POWER P.W. BOARD ASS'Y (SFL-9005A-M2)
Ref No. Part No. Part Name Description Local
Q7701 UN2212-X DIGI TRANSISTOR
Q7702 UN2212-X DIGI TRANSISTOR
Q7703 UN2110-X DIGI TRANSISTOR
Q7704 UN2110-X DIGI TRANSISTOR
Q7705 UN2110-X DIGI TRANSISTOR
D7011 MA8062/M/-X Z DIODE
D7702 HLMPNS30J00-T16 LED POWER
C7011 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7012 NCB31HK-104X C CAPACITOR 0.1uF 50V K
R7011 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7012 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7013 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7014 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7015 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7016 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7018 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R7701 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R7702 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R7703 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R7704 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R7711 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7712 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7713 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7714 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
L7001 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
L7002 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
CN0008 QGB2542K1-08 CONNECTOR B-B (1-8)
J7001 QMS3004-C01 H.P.JACK HEADPHONE
K7001 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
S7701 QSW0797-001 TACT SWITCH CH+
S7702 QSW0797-001 TACT SWITCH CH-
S7703 QSW0797-001 TACT SWITCH INPUT
S7704 QSW0797-001 TACT SWITCH MENU
S7705 QSW0797-001 TACT SWITCH VOL+
S7706 QSW0797-001 TACT SWITCH VOL-
S7707 QSW0797-001 TACT SWITCH POWER
Ref No. Part No. Part Name Description Local
IC8752 GP1UM281QK IR DETECT UNIT 38kHz
C8752 NEH71CM-476X E CAPACITOR 47uF 16V M
R8757 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R8759 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
CN1008 QGB2542J1-08 CONNECTOR B-B (1-8)
Ref No. Part No. Part Name Description Local
IC9801 PQ20WZ11-X IC
IC9802 MP1410ES-X IC
IC9803 MP1583DN-X IC
Q9802 2SD601A/QR/-X TRANSISTOR
Q9803 2SD601A/QR/-X TRANSISTOR
D9801 D1FS4-X SB DIODE
D9803 SD883-04-X SB DIODE
D9804 MA111-X SI DIODE
D9805 MA3030/H/-X Z DIODE
D9806 SD883-04-X SB DIODE
D9807 PTZ6.8B-X Z DIODE
D9808 MA111-X SI DIODE
D9810 PTZ6.8B-X Z DIODE
D9813 MA111-X SI DIODE
C9801 NEH91CM-476X E CAPACITOR 47uF 16V M
C9802 NEH91CM-476X E CAPACITOR 47uF 16V M
C9803 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9805 NCJ41EK-106X-U C CAPACITOR 10mF 25V K
C9806 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9809 NEH91HM-105X E CAPACITOR 1uF 50V M
C9810 NCJ41EK-106X-U C CAPACITOR 10mF 25V K
C9812 NCJ41CK-226X-U C CAPACITOR 22mF 16V K
C9813 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9814 NEH90JM-107X E CAPACITOR 100uF 6.3V M
C9818 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9819 NDC31HJ-101X C CAPACITOR 100pF 50V J
C9821 NCJ41CK-226X-U C CAPACITOR 22mF 16V K
C9822 NDC31HJ-121X C CAPACITOR 120pF 50V J
C9823 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9824 NCB11EK-104X C CAPACITOR 0.1uF 25V K
C9826 NCB31HK-222X C CAPACITOR 2200pF 50V K
R9801 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9802 NRSA63D-472X MG RESISTOR 4.7k
Ω
1/16W D
R9803 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R9804 NRSA63D-332X MG RESISTOR 3.3k
Ω
1/16W D
R9810 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9811 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
R9812 NRVA02D-473X CMF RESISTOR 47k
Ω
1/10W D
R9813 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R9814 NRSA63D-124X MG RESISTOR 120k
Ω
1/16W D
R9815 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R9816 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R9817 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R9818 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9819 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9820 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R9821 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
R9822 NRSA63D-473X MG RESISTOR 47k
Ω
1/16W D
R9823 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R9824 NRSA63D-124X MG RESISTOR 120k
Ω
1/16W D
R9825 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9826 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R9827 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R9828 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9830 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R9831 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
L9804 NQL71EM-150X COIL 15uH M
L9806 NQL71EM-150X COIL 15uH M
L9807 NQL80CL-100X COIL 10uH L
CN1006 QGB2501K2-13 CONNECTOR B-B (1-13)
Ref No. Part No. Part Name Description Local
IC9141 BA05FP-X IC
IC9211 FA5500AN-W IC
IC9501 F9222L-F219 IC
IC9541 UTCTL431-T IC
IC9602 M62320FP-X IC
IC9901 MP1580HS-X IC
Q9021 UN2211-X TRANSISTOR
Q9151 2SA1530A/QR/-X TRANSISTOR
Q9152 2SD601A/QR/-X TRANSISTOR
Q9211 2SK3522-01-F1 POWER MOS FET
Q9212 2SD601A/QR/-X TRANSISTOR
Q9213 IMD3A-W TRANSISTOR
Q9215 2SD601A/QR/-X TRANSISTOR
Q9216 UN2212-X DIGI TRANSISTOR
Q9251 UN2213-X DIGI TRANSISTOR
Q9252 UN2213-X DIGI TRANSISTOR
Q9501 2SD601A/QR/-X TRANSISTOR
Q9502 2SK2071-01S-W POWER MOS FET
Q9503 2SD601A/QR/-X TRANSISTOR
Q9504 2SK2018-01S-W POWER MOS FET
Q9506 UN2213-X DIGI TRANSISTOR
Q9541 UN2212-X DIGI TRANSISTOR
Q9602 2SB1188/QR/-W TRANSISTOR
Q9603 UN2213-X DIGI TRANSISTOR
Q9901 2SD601A/QR/-X TRANSISTOR
D9001 MA8091/L/-X Z DIODE
D9002 S1WB/A/60-X BRIDGE DIODE
Ref No. Part No. Part Name Description Local
