3-12(No.YA180)
DIGITAL SIGNAL P.W. BOARD ASS'Y (SFL0D105A-M2)
R9526 QRE141J-151Y C RESISTOR 150
Ω
1/4W J
R9529 QRL039J-821 OMF RESISTOR 820
Ω
3W J
R9541 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9542 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R9543 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R9544 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R9545 NRSA63D-391X MG RESISTOR 390
Ω
1/16W D
R9546 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R9548 NRSA63D-272X MG RESISTOR 2.7k
Ω
1/16W D
R9549 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R9551 QRT029J-1R8 MF RESISTOR 1.8
Ω
2W J
R9552 QRT029J-1R8 MF RESISTOR 1.8
Ω
2W J
R9615 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R9616 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R9617 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R9618 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R9628 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9629 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R9631 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R9635 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R9901 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
R9902 NRSA63D-104X MG RESISTOR 100k
Ω
1/16W D
R9903 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R9904 NRSA63D-184X MG RESISTOR 180k
Ω
1/16W D
R9905 QRK126J-681X UNF C RESISTOR 680
Ω
1/2W J
R9906 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R9907 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R9908 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9910 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R9911 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9913 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9916 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R9923 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
L9141 NQL52EN-4R7X COIL 4.7uH N
L9201 QQR1468-001 CHOKE COIL
L9202 QQR1513-001 CHOKE COIL
L9541 NQL71EM-150X COIL 15uH M
L9902 NQL80CL-100X COIL 10uH L
L9903 NQL80CL-100X COIL 10uH L
L9904 NQL63EM-470X COIL 47uH M
T9121 QAL0425-001 POWER TRANSF
T9501 QQS0286-001 SW TRANSF
T9502 QQS0286-001 SW TRANSF
CN0006 QGB2501J1-13 CONNECTOR B-B (1-13)
CN000H QGF1201C2-19 CONNECTOR FFC/FPC (1-19)
CN00E1 CE41507-001P LV CONNECTOR
CP9121 QMFZ052-2R0-E FUSE 2A AC250V
CP9211 QMFZ043-2R0Z-J1 FUSE 2A AC250V
F9001 QMF51D2-6R3-J1 FUSE 6.3A AC250V
H9211 LC32819-001A HEAT SINK/AL-F/
H9501 LC32819-001A HEAT SINK/AL-F/
H9541 LC32802-001A HEAT SINK/AL-F/
K9001 QRN143J-0R0X C RESISTOR 0
Ω
1/4W J
K9211 QQR0621-002Z FERRITE BEADS
K9212 QQR0621-002Z FERRITE BEADS
K9501 NQR0413-002X FERRITE BEADS
K9502 NQR0413-002X FERRITE BEADS
K9503 NQR0413-002X FERRITE BEADS
K9504 NQR0413-002X FERRITE BEADS
K9505 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9508 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9541 NQR0413-003X FERRITE BEADS
LF9001 QQR1514-001 LINE FILTER
LF9002 QQR1467-001 LINE FILTER
LF9003 QQR1514-001 LINE FILTER
PC9001 PS2581AL1/QW/ PHOTO COUPLER
PC9541 PS2581AL1/QW/ PHOTO COUPLER
PC9542 PS2581AL1/QW/ PHOTO COUPLER
RY9021 QSK0119-001 RELAY
RY9201 QSK0117-001 RELAY
VA9001 QAF0060-621 VARISTOR 620V
Ref No. Part No. Part Name Description Local
IC0401 SN74AHCT1G32V-X IC
IC1001 TC90A92AFG IC
IC1002 MM1572FN-X IC
IC1502 NJM2235V-X IC
IC3001 JCC5055 IC
IC3004 TC7MB3257FK-X IC
Ref No. Part No. Part Name Description Local
IC3005 SN74LVC1G08V-X IC
IC3006 SN74LVC2G126T-X IC
IC3403 S-80928CLNB-W IC
IC3501 K4D263238F-UC50 IC
IC3502 K4D263238F-UC50 IC
IC3503 LP2996MR-X IC
IC4001 JCC5057 IC
IC4003 AT29LV01-32X585 IC (SERVICE)
IC4004 AT24C25632X585D IC (SERVICE)
IC4005 SN74LVC1G08V-X IC
IC6502 THC63LVDM83R-W IC
IC7001 MN102H60KPC IC(MCU)
IC7002 AT24C256-32X585 IC (SERVICE)
IC7401 S-80828CLNB-W IC
IC7601 M306V7MG-090FP IC(MCU)
IC7602 AT24C16-32X585 IC (SERVICE)
IC7603 SN74LVC1G04V-X IC
IC7607 MM1510XN-X IC
IC7608 MM1510XN-X IC
IC9001 MP1580HS-X IC
IC9101 MP1580HS-X IC
IC9201 MP1580HS-X IC
Q0101 2SC3837K/NP/-X TRANSISTOR
Q0102 2SA1022/BC/-X TRANSISTOR
Q0104 2SA1022/BC/-X TRANSISTOR
Q0107 2SA1530A/QR/-X TRANSISTOR
Q0108 2SC3928A/QR/-X TRANSISTOR
Q0109 HN1C01F/Y/-X PAIR TRANSISTOR
Q0110 HN1C01F/Y/-X PAIR TRANSISTOR
Q0201 2SC3837K/NP/-X TRANSISTOR
Q0202 2SA1022/BC/-X TRANSISTOR
Q0203 2SC3928A/QR/-X TRANSISTOR
Q0204 2SA1022/BC/-X TRANSISTOR
Q0207 2SA1530A/QR/-X TRANSISTOR
Q0208 2SC3928A/QR/-X TRANSISTOR
Q0209 HN1C01F/Y/-X PAIR TRANSISTOR
Q0210 HN1C01F/Y/-X PAIR TRANSISTOR
Q0301 2SC3837K/NP/-X TRANSISTOR
Q0302 2SA1022/BC/-X TRANSISTOR
Q0303 2SC3928A/QR/-X TRANSISTOR
Q0304 2SA1022/BC/-X TRANSISTOR
Q0307 2SA1530A/QR/-X TRANSISTOR
Q0308 2SC3928A/QR/-X TRANSISTOR
Q0309 HN1C01F/Y/-X PAIR TRANSISTOR
Q0310 HN1C01F/Y/-X PAIR TRANSISTOR
Q1001 UN2213-X DIGI TRANSISTOR
Q1003 2SC3928A/QR/-X TRANSISTOR
Q1004 2SA1530A/QR/-X TRANSISTOR
Q1101 2SC3928A/QR/-X TRANSISTOR
Q1103 2SA1530A/QR/-X TRANSISTOR
Q1201 2SC3928A/QR/-X TRANSISTOR
Q1203 2SA1530A/QR/-X TRANSISTOR
Q1301 2SC3928A/QR/-X TRANSISTOR
Q1303 2SA1530A/QR/-X TRANSISTOR
Q1401 2SC3928A/QR/-X TRANSISTOR
Q1403 2SA1530A/QR/-X TRANSISTOR
Q3001 2SC3928A/QR/-X TRANSISTOR
Q3002 2SA1530A/QR/-X TRANSISTOR
Q3003 2SC3928A/QR/-X TRANSISTOR
Q3004 2SA1530A/QR/-X TRANSISTOR
Q4001 2SC3928A/QR/-X TRANSISTOR
Q6501 2SC3928A/QR/-X TRANSISTOR
Q7206 UN2213-X DIGI TRANSISTOR
Q7207 DTA144EKA-X DIGI TRANSISTOR
D1001 EC30HA03L-X SB DIODE
D1002 EC30HA03L-X SB DIODE
D7001 MA111-X SI DIODE
D7003 MA111-X SI DIODE
D7005 MA8082/M/-X Z DIODE
D7006 MA8082/M/-X Z DIODE
D7007 MA8082/M/-X Z DIODE
D7008 MA8082/M/-X Z DIODE
D7009 MA8082/M/-X Z DIODE
D7010 MA111-X SI DIODE
D7203 MA111-X SI DIODE
D7210 RB501V-40-X SB DIODE
D7601 MA111-X SI DIODE
D9001 EC30HA03L-X SB DIODE
D9003 PTZ3.9B-X Z DIODE
D9101 EC30HA03L-X SB DIODE
D9102 EC30HA03L-X SB DIODE
D9103 PTZ3.9B-X Z DIODE
D9104 MA111-X SI DIODE
D9201 EC30HA03L-X SB DIODE
D9203 PTZ3.9B-X Z DIODE
Ref No. Part No. Part Name Description Local
