(No.YA180)3-19
PRINTED WIRING BOARD PARTS LIST [LT-32X585/KA]
ANALOG SIGNAL P.W. BOARD ASS'Y
(SFL-1012A-M2)
REFER TO PARTS LIST IN PAGE 3-6 FOR THIS P.W. BOARD.
CONNECTOR P.W. BOARD ASS'Y (SFL-4011A-M2)
REFER TO PARTS LIST IN PAGE 3-9 FOR THIS P.W. BOARD.
FRONT CONTROL P.W. BOARD ASS'Y
(SFL-7011A-M2)
REFER TO PARTS LIST IN PAGE 3-10 FOR THIS P.W. BOARD.
FRONT SENSOR PWB P.W. BOARD ASS'Y
(SFL-8011A-M2)
REFER TO PARTS LIST IN PAGE 3-10 FOR THIS P.W. BOARD.
REGULATOR P.W. BOARD ASS'Y (SFL-9105A-M2)
REFER TO PARTS LIST IN PAGE 3-10 FOR THIS P.W. BOARD.
POWER P.W. BOARD ASS'Y (SFL-9005A-M2)
REFER TO PARTS LIST IN PAGE 3-10 FOR THIS P.W. BOARD.
DIGITAL SIGNAL P.W. BOARD ASS'Y (SFL0D104A-M2)
 Ref No. Part No. Part Name Description Local
SFL0D104A-M2 DIGITAL BOARD ASSY
IC0401 SN74AHCT1G32V-X IC
IC1001 TC90A92AFG IC
IC1002 MM1572FN-X IC
IC1502 NJM2235V-X IC
IC3001 JCC5055 IC
IC3004 TC7MB3257FK-X IC
IC3005 SN74LVC1G08V-X IC
IC3006 SN74LVC2G126T-X IC
IC3403 S-80928CLNB-W IC
IC3501 K4D263238F-UC50 IC
IC3502 K4D263238F-UC50 IC
IC3503 LP2996MR-X IC
IC4001 JCC5057 IC
IC4003 AT29LV01-32X585 IC (SERVICE)
IC4004 AT24C25632X585D IC (SERVICE)
IC4005 SN74LVC1G08V-X IC
IC6502 THC63LVDM83R-W IC
IC7001 MN102H60KPC IC(MCU)
IC7002 AT24C256-32X585 IC (SERVICE)
IC7401 S-80828CLNB-W IC
IC7601 M306V7MG-090FP IC(MCU)
IC7602 AT24C16-32X585 IC (SERVICE)
IC7603 SN74LVC1G04V-X IC
IC7607 MM1510XN-X IC
IC7608 MM1510XN-X IC
IC9001 MP1580HS-X IC
IC9101 MP1580HS-X IC
IC9201 MP1580HS-X IC
Q0101 2SC3837K/NP/-X TRANSISTOR
Q0102 2SA1022/BC/-X TRANSISTOR
Q0104 2SA1022/BC/-X TRANSISTOR
Q0107 2SA1530A/QR/-X TRANSISTOR
Q0108 2SC3928A/QR/-X TRANSISTOR
Q0109 HN1C01F/Y/-X PAIR TRANSISTOR
Q0110 HN1C01F/Y/-X PAIR TRANSISTOR
Q0201 2SC3837K/NP/-X TRANSISTOR
Q0202 2SA1022/BC/-X TRANSISTOR
Q0203 2SC3928A/QR/-X TRANSISTOR
Q0204 2SA1022/BC/-X TRANSISTOR
Q0207 2SA1530A/QR/-X TRANSISTOR
Q0208 2SC3928A/QR/-X TRANSISTOR
Q0209 HN1C01F/Y/-X PAIR TRANSISTOR
Q0210 HN1C01F/Y/-X PAIR TRANSISTOR
Q0301 2SC3837K/NP/-X TRANSISTOR
Q0302 2SA1022/BC/-X TRANSISTOR
Q0303 2SC3928A/QR/-X TRANSISTOR
Q0304 2SA1022/BC/-X TRANSISTOR
Q0307 2SA1530A/QR/-X TRANSISTOR
Q0308 2SC3928A/QR/-X TRANSISTOR
Q0309 HN1C01F/Y/-X PAIR TRANSISTOR
Q0310 HN1C01F/Y/-X PAIR TRANSISTOR
Q1001 UN2213-X DIGI TRANSISTOR
Q1003 2SC3928A/QR/-X TRANSISTOR
Q1004 2SA1530A/QR/-X TRANSISTOR
Q1101 2SC3928A/QR/-X TRANSISTOR
Q1103 2SA1530A/QR/-X TRANSISTOR
Q1201 2SC3928A/QR/-X TRANSISTOR
Q1203 2SA1530A/QR/-X TRANSISTOR
Q1301 2SC3928A/QR/-X TRANSISTOR
Q1303 2SA1530A/QR/-X TRANSISTOR
Q1401 2SC3928A/QR/-X TRANSISTOR
Q1403 2SA1530A/QR/-X TRANSISTOR
Q3001 2SC3928A/QR/-X TRANSISTOR
Q3002 2SA1530A/QR/-X TRANSISTOR
Q3003 2SC3928A/QR/-X TRANSISTOR
Q3004 2SA1530A/QR/-X TRANSISTOR
Q4001 2SC3928A/QR/-X TRANSISTOR
Q6501 2SC3928A/QR/-X TRANSISTOR
Q7206 UN2213-X DIGI TRANSISTOR
Q7207 DTA144EKA-X DIGI TRANSISTOR
D1001 EC30HA03L-X SB DIODE
D1002 EC30HA03L-X SB DIODE
D7001 MA111-X SI DIODE
D7003 MA111-X SI DIODE
D7005 MA8082/M/-X Z DIODE
D7006 MA8082/M/-X Z DIODE
D7007 MA8082/M/-X Z DIODE
D7008 MA8082/M/-X Z DIODE
D7009 MA8082/M/-X Z DIODE
D7010 MA111-X SI DIODE
D7203 MA111-X SI DIODE
D7210 RB501V-40-X SB DIODE
D7601 MA111-X SI DIODE
D9001 EC30HA03L-X SB DIODE
D9003 PTZ3.9B-X Z DIODE
D9101 EC30HA03L-X SB DIODE
D9102 EC30HA03L-X SB DIODE
D9103 PTZ3.9B-X Z DIODE
D9104 MA111-X SI DIODE
D9201 EC30HA03L-X SB DIODE
D9203 PTZ3.9B-X Z DIODE
D9204 MA111-X SI DIODE
C0103 NDC31HJ-330X C CAPACITOR 33pF 50V J
C0105 NDC31HJ-270X C CAPACITOR 27pF 50V J
C0107 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C0109 NCB11AK-106X C CAPACITOR 10uF 10V K
C0110 NCB11AK-106X C CAPACITOR 10uF 10V K
C0111 NDC31HJ-820X C CAPACITOR 82pF 50V J
C0112 NDC31HJ-820X C CAPACITOR 82pF 50V J
C0113 NCB11AK-106X C CAPACITOR 10uF 10V K
C0114 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C0115 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C0116 NCB11AK-106X C CAPACITOR 10uF 10V K
C0117 NDC31HJ-560X C CAPACITOR 56pF 50V J
C0203 NDC31HJ-330X C CAPACITOR 33pF 50V J
C0205 NDC31HJ-270X C CAPACITOR 27pF 50V J
C0207 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C0209 NCB11AK-106X C CAPACITOR 10uF 10V K
C0210 NCB11AK-106X C CAPACITOR 10uF 10V K
C0211 NDC31HJ-820X C CAPACITOR 82pF 50V J
C0212 NDC31HJ-820X C CAPACITOR 82pF 50V J
C0213 NCB11AK-106X C CAPACITOR 10uF 10V K
C0214 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C0215 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C0217 NDC31HJ-560X C CAPACITOR 56pF 50V J
C0303 NDC31HJ-330X C CAPACITOR 33pF 50V J
C0305 NDC31HJ-270X C CAPACITOR 27pF 50V J
C0307 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C0309 NCB11AK-106X C CAPACITOR 10uF 10V K
 Ref No. Part No. Part Name Description Local
