JVC LVT1140-004A User Manual

39
Specifications
Amplifier
Output Power
At Stereo operation
Front channels: 100 W per channel, min. RMS, driven into
8 Ω, at 1 kHz with no more than 0.8% total
harmonic distortion (IEC268-3/DIN).
At Surround operation
Front channels: 100 W per channel, min. RMS, driven into
8 Ω, at 1 kHz with no more than 0.8% total
harmonic distortion.
Center channel: 100 W, min. RMS, driven into 8 Ω, at 1 kHz
with no more than 0.8% total harmonic
distortion.
Surround channels: 100 W per channel, min. RMS, driven into
8 Ω, at 1 kHz with no more than 0.8% total
harmonic distortion.
Audio
Audio Input Sensitivity/Impedance (1 kHz)
CD, TAPE/CDR, VCR, TV SOUND, DVD: 220 mV/47 kΩ
Audio Input (DIGITAL IN)*
Coaxial
DIGITAL 1 (DVD): 0.5 V(p-p)/75 Ω
Optical
DIGITAL 2 (CD), DIGITAL 3 (TV):
–21 dBm to –15 dBm (660 nm ±30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS
Digital Surround (with sampling frequency—32 kHz,
44.1 kHz, 48 kHz)
Recording Output Level
TAPE/CDR, VCR: 220 mV
Signal-to-Noise Ratio (’66 IHF/DIN)
CD, TAPE/CDR, VCR, TV SOUND, DVD: 87 dB/62 dB
Frequency Response (8 Ω)
CD, TAPE/CDR, VCR, TV SOUND, DVD:
20 Hz to 50 kHz (+1 dB, –3 dB)
Bass Boost: +3 dB ±1 dB at 100 Hz
Equalization (5 bands)
63 Hz, 250 Hz, 1 kHz, 4 kHz, 16 kHz: ±8 dB (in 2 dB steps)
Video
Video Input Sensitivity/Impedance
Composite video
DVD, VCR: 1 V(p-p)/75 Ω
S-video
DVD, VCR (Y: luminance): 1 V(p-p)/75 Ω
(C: chrominance, burst): 0.286 V(p-p)/75 Ω
Component
DVD, VCR (Y: luminance): 1 V(p-p)/75 Ω
(P
B, PR): 0.7 V(p-p)/75 Ω
Video Output Level
Composite video
VCR, MONITOR OUT: 1 V(p-p)/75 Ω
S-video
VCR, MONITOR OUT
(Y: luminance): 1 V(p-p)/75 Ω
(C: chrominance, burst): 0.286 V(p-p)/75 Ω
Component
MONITOR OUT (Y: luminance): 1 V(p-p)/75 Ω
(P
B, PR): 0.7 V(p-p)/75 Ω
Synchronization: Negative
Signal-to-Noise Ratio: 45 dB
FM tuner (IHF)
Tuning Range: 87.50 MHz to 108.00 MHz
Usable Sensitivity
Monaural: 17.0 dBf (1.9 µV/75 Ω)
50 dB Quieting Sensitivity
Monaural: 21.3 dBf (3.2 µV/75 Ω)
Stereo: 41.3 dBf (31.8 µV/75 Ω)
Stereo Separation at OUT (REC): 35 dB at 1 kHz
AM (MW) tuner
Tuning Range: 522 kHz to 1 629 kHz
General
Power Requirements: AC 230 V , 50 Hz
Power Consumption: 200 W (at operation)
2 W (in standby mode)
Dimensions (W x H x D): 435 mm x 146.5 mm x 409.5 mm
Mass: 8.8 kg
Designs and specifications are subject to change without notice.
