JVC MX-G950V User Manual

1-18
MX-G950V/MX-G880V
MX-G850V/MX-G750V
Remove the four screws F on the back of the body.
Disconnect the wires from the two terminals on the
rear speaker.
Remove the four screws G on the back of the front
cover.
1.
2.
3.
<Removing the Rear speaker>
Removing the Rear cover (See Fig.7 ~ 9 )
Fig.8(SP-MXG950V)
Fig.7(SP-MXG950V)
Fig.9(SP-MXG950V)
G
G
F
F
Rear speaker terminals
Rear speaker terminals
Rear speaker
Rear cover
Rear cover
Front cover
Front cover
