1-5
MX-G950V/MX-G880V
MX-G850V/MX-G750V
Remove the six screws A on the back of the body.
Remove the two screws B on both sides of the
body.
Remove the metal cover from the body by lifting the
rear part of the cover.
1.
2.
3.
Disassembly method
<Main body>
Removing the metal cover
(See Fig.1 ~ 3)
Do not break the front panel tab fitted to
the metal cover.
CAUTION:
Fig.1
(CA-MXG850VU, CA-MXG950VUX)
Fig.2
Fig.3
A
A
A
Metal cover
Metal cover
B
Metal cover
B
Fig.1
(CA-MXG750VUS)
A
A
A
Metal cover
