JVC MX-JD5 User Manual

3-20
DVD loading switch board
Block No. [0][4]
DVD servo board
R984 QRE141J-153Y C RESISTOR 15k Ω 1/4W J
JD5U
N,JD5
US,JD
5UX
R985 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
JD5U
N,JD5
US,JD
5UX
R986 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
JD5U
N,JD5
US,JD
5UX
R987 QRE141J-561Y C RESISTOR 560 Ω 1/4W J
JD5U
N,JD5
US,JD
5UX
R988 QRE141J-203Y C RESISTOR 20k
Ω 1/4W J
JD5U
N,JD5
US,JD
5UX
R989 QRE141J-510Y C RESISTOR 51
Ω 1/4W J
JD5U
N,JD5
US,JD
5UX
R990 QRE141J-475Y C RESISTOR 4.7M Ω 1/4W J
JD5U
N,JD5
US,JD
5UX
R991 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
JD5U
N,JD5
US,JD
5UX
R992 QRE141J-152Y C RESISTOR 1.5k Ω 1/4W J
JD5U
N,JD5
US,JD
5UX
R993 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
JD5U
N,JD5
US,JD
5UX
R994 QRE141J-123Y C RESISTOR 12k Ω 1/4W J
JD5U
N,JD5
US,JD
5UX
R995 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
JD5U
N,JD5
US,JD
5UX
R996 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
JD5U
N,JD5
US,JD
5UX
R997 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
JD5U
N,JD5
US,JD
5UX
R998 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
JD5U
N,JD5
US,JD
5UX
R999 QRE141J-152Y C RESISTOR 1.5k Ω 1/4W J
JD5U
N,JD5
US,JD
5UX
 R2010 QRJ146J-4R7X UNF C RESISTOR 4.7 Ω 1/4W J
R2011 FQRK123J-153X C RESISTOR
R2012 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
 R2014 ERX12SJR33E UNF C RESISTOR
VR970 QVQ0299-B54 V RESISTOR
JD5U
N,JD5
US,JD
5UX
L996 QQL231K-470Y COIL 47uH K
L997 QQL231K-470Y COIL 47uH K
L998 QQR1183-001Z FERRITE BEADS
CN101 QGD2504C1-03Z CONNECTOR (1-3)
CN119 QGA3901F1-08 CONNECTOR W-B (1-8)
CN250 QGA7901C1-02 CONNECTOR W-B (1-2)
CN810 QGB2024K1-04S CONNECTOR B-B (1-4)
CN820 QGB2024J1-04S CONNECTOR B-B (1-4)
CN870 QGF1205C1-17 CONNECTOR FFC/FPC (1-17)
CN890 QGF1205F1-12 CONNECTOR FFC/FPC (1-12)
 Symbol No. Part No. Part Name Description Local
FT111 QNG0003-001Z FUSE CLIP
FT112 QNG0003-001Z FUSE CLIP
FT131 QNG0003-001Z FUSE CLIP
FT132 QNG0003-001Z FUSE CLIP
FT151 QNG0003-001Z FUSE CLIP
FT152 QNG0003-001Z FUSE CLIP
FT511 QNG0003-001Z FUSE CLIP
FT512 QNG0003-001Z FUSE CLIP
FT521 QNG0003-001Z FUSE CLIP
FT522 QNG0003-001Z FUSE CLIP
FT531 QNG0003-001Z FUSE CLIP
FT532 QNG0003-001Z FUSE CLIP
FW116 QUM153-29DGZ4 FLAT WIRE
FW241 QUM153-18DGZ4 FLAT WIRE
FW444 QJP001-033600 SINGLE WIRE
JD5U
E,JD5
UW
J970 QNS0236-001 PHONE JACK
JD5U
N,JD5
US,JD
5UX
J971 QNS0235-001 PHONE JACK
JD5U
E,JD5
UW
J971 QNS0236-001 PHONE JACK
JD5U
N,JD5
US,JD
5UX
J995 QNS0237-001 PHONE JACK
JS920 QSW0857-001 ROTARY SW
 S500 QSW0812-001 VOLTAGE SWITCH
S920 QSW0825-001Z TACT SW
S939 QSW0825-001Z TACT SW
S940 QSW0825-001Z TACT SW
S941 QSW0825-001Z TACT SW
S942 QSW0825-001Z TACT SW
S943 QSW0825-001Z TACT SW
S944 QSW0825-001Z TACT SW
S945 QSW0825-001Z TACT SW
S946 QSW0825-001Z TACT SW
S947 QSW0825-001Z TACT SW
S948 QSW0825-001Z TACT SW
S949 QSW0825-001Z TACT SW
S950 QSW0825-001Z TACT SW
S951 QSW0825-001Z TACT SW
S952 QSW0825-001Z TACT SW
S953 QSW0825-001Z TACT SW
S954 QSW0825-001Z TACT SW
S955 QSW0825-001Z TACT SW
S960 QSW0825-001Z TACT SW
S961 QSW0825-001Z TACT SW
S962 QSW0825-001Z TACT SW
S963 QSW0825-001Z TACT SW
S964 QSW0825-001Z TACT SW
S965 QSW0825-001Z TACT SW
S966 QSW0825-001Z TACT SW
S967 QSW0825-001Z TACT SW
SP920 GV40205-004A IC HOLDER
TW920 QUB220-32HPDM WIRE
TW991 QUB220-18HPDM S.WIRE
 Symbol No. Part No. Part Name Description Local
CN1 QGF1016F3-05 CONNECTOR FFC/FPC (1-5)
S1 QSW1007-001 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
