JVC MX-JD5 User Manual

3-21
Block No. [0][5]
 Symbol No. Part No. Part Name Description Local
IC201 LA6502-X IC
IC301 MN2DS0004AA-H IC
IC302 LM1117MP-ADJ-X IC
IC305 MM1563DF-X IC 3.3V Regulator
IC453 S-80830CNNB-G-W IC
IC505 K4S643232F-TC60 IC
IC505 or K4S643232H-TC60 IC
IC509 AT49BV322AT70TI IC(FLASH)
IC509 or MBD32TF70TN IC(MICRO C ROM)
IC512 SN74LVC373APW-X IC(DIGITAL)
IC513 SN74LVC373APW-X IC(DIGITAL)
IC701 AK4384VT-X IC
IC702 AK4384VT-X IC
IC703 AK4384VT-X IC
IC704 CS5342-CZZ-X IC(DIGITAL)
IC705 MM1615AN-X IC
Q101 KTA1001/Y/-X TRANSISTOR
Q101 or 2SB1424/R/-W TRANSISTOR
Q102 2SC4617/R/-X TRANSISTOR
Q103 KTA1001/Y/-X TRANSISTOR
Q103 or 2SB1424/R/-W TRANSISTOR
Q104 2SC4617/R/-X TRANSISTOR
Q105 UN2119-X TRANSISTOR
C101 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C102 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C103 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C104 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C105 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C106 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C107 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C108 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C204 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C205 NCB31HK-271X C CAPACITOR 270pF 50V K
C206 NDC31HJ-151X C CAPACITOR 150pF 50V J
C211 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C217 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C251 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C256 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C257 NCB31HK-822X C CAPACITOR 8200pF 50V K
C258 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C259 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C260 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C261 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C262 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C300 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C301 NEA70GM-227X E CAPACITOR 220uF 4V M
C302 NEA70GM-476X E CAPACITOR 47uF 4V M
C303 NEA70GM-476X E CAPACITOR 47uF 4V M
C304 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C305 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C306 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C307 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C308 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C309 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C310 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C311 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C312 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C313 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C314 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C315 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C316 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C317 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C318 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C319 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C320 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C321 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C322 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C323 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C324 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C325 NDC31HJ-180X C CAPACITOR 18pF 50V J
C326 NDC31HJ-150X C CAPACITOR 15pF 50V J
C328 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C329 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C330 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C331 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C332 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C333 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C334 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C335 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C337 NCB31CK-183X C CAPACITOR 0.018uF 16V K
C338 NCB31HK-562X C CAPACITOR 5600pF 50V K
C339 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C340 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C341 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C347 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C348 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C349 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C350 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C351 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C352 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C353 NCB31HK-561X C CAPACITOR 560pF 50V K
C354 NCB31HK-561X C CAPACITOR 560pF 50V K
C356 NCB21CK-105X C CAPACITOR 1uF 16V K
C371 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C380 NCB21CK-105X C CAPACITOR 1uF 16V K
C381 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C382 NCB31HK-471X C CAPACITOR 470pF 50V K
C391 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C455 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C551 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C552 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C553 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C554 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C555 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C556 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C557 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C558 NEA70GM-476X E CAPACITOR 47uF 4V M
C701 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C702 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C703 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C704 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C706 NEA71AM-106X E CAPACITOR 10uF 10V M
C707 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C708 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C709 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C711 NCB21CK-105X C CAPACITOR 1uF 16V K
C712 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C713 NCB21CK-105X C CAPACITOR 1uF 16V K
C741 NCF21CZ-225X C CAPACITOR 2.2uF 16V Z
C742 NCF21CZ-225X C CAPACITOR 2.2uF 16V Z
C743 NCF21CZ-225X C CAPACITOR 2.2uF 16V Z
C748 NCF21CZ-225X C CAPACITOR 2.2uF 16V Z
C749 NCF21CZ-225X C CAPACITOR 2.2uF 16V Z
C761 NCB31CK-104X C CAPACITOR 0.1uF 16V K
R101 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R102 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R103 NRSA63J-243X MG RESISTOR 24k Ω 1/16W J
R104 NRSA63J-303X MG RESISTOR 30k
Ω 1/16W J
R105 NRS125J-270X MG RESISTOR 27
Ω 1/2W J
R106 NRSA63J-2R2X MG RESISTOR 2.2 Ω 1/16W J
R107 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R108 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R109 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R110 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R111 NRSA63J-243X MG RESISTOR 24k Ω 1/16W J
R112 NRSA63J-303X MG RESISTOR 30k
Ω 1/16W J
R113 NRS125J-270X MG RESISTOR 27
Ω 1/2W J
R114 NRSA63J-2R2X MG RESISTOR 2.2 Ω 1/16W J
R115 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R116 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R117 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R118 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R119 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R120 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R122 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R123 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R125 NRS125J-1R0X MG RESISTOR 1
Ω 1/2W J
R126 NRSA63J-181X MG RESISTOR 180
Ω 1/16W J
R127 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R128 NRSA63J-163X MG RESISTOR 16k
Ω 1/16W J
R204 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
