3-9
R472 BIRC5630105A00 C RESISTOR 56K
Ω
1/10W
R479 BIRC1200045M00 C RESISTOR 12
Ω
1/4W
R480 BIRC2720105A00 C RESISTOR 2.7K
Ω
1/10W
R481 BIRC2720105A00 C RESISTOR 2.7K
Ω
1/10W
R482 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R483 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R484 BIRC4710105A00 C RESISTOR 470
Ω
1/10W
R501 BIRC1530085M00 C RESISTOR 15K
Ω
1/8W
R502 BIRC1530085M00 C RESISTOR 15K
Ω
1/8W
R503 BIRC2230085M00 C RESISTOR 22K
Ω
1/8W
R504 BIRC2230085M00 C RESISTOR 22K
Ω
1/8W
R505 BIRC3930105A00 C RESISTOR 39K
Ω
1/10W
R506 BIRC3930105A00 C RESISTOR 39K
Ω
1/10W
R507 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R508 BIRC4720085M00 C RESISTOR 4.7K
Ω
1/8W
R509 BIRC6830105A00 C RESISTOR 68K
Ω
1/10W
R510 BIRC5630105A00 C RESISTOR 56K
Ω
1/10W
R511 BIRC4720085M00 C RESISTOR 4.7K
Ω
1/8W
R512 BIRC2220085M00 C RESISTOR 2.2K
Ω
1/8W
R513 BIRC5620105A00 C RESISTOR 5.6K
Ω
1/10W
R514 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R515 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R516 BIRC1050105A00 C RESISTOR 1M
Ω
1/10W
R517 BIRC1000105A00 C RESISTOR 10
Ω
1/10W
R518 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R519 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R520 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R521 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
R523 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R525 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R526 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R528 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R537 BIRC3920105A00 C RESISTOR 3.9K
Ω
1/10W
R538 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R539 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R540 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R541 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R542 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R543 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R550 BIRC3920105A00 C RESISTOR 3.9K
Ω
1/10W
R557 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R558 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R559 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R560 BIRC2230105A00 C RESISTOR 22K
Ω
1/10W
R561 BIRC2230105A00 C RESISTOR 22K
Ω
1/10W
R562 BIRC2230105A00 C RESISTOR 22K
Ω
1/10W
R563 BIRC4710105A00 C RESISTOR 470
Ω
1/10W
R566 BIRC6820105A00 C RESISTOR 6.8K
Ω
1/10W
R567 BIRC3320105A00 C RESISTOR 3.3K
Ω
1/10W
R570 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R571 BIRC4710045M00 C RESISTOR 470
Ω
1/4W
R572 BIRC4720085M00 C RESISTOR 4.7K
Ω
1/8W
R573 BIRC2210085M00 C RESISTOR 220
Ω
1/8W
R574 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R575 BIRC1010085M00 C RESISTOR 100
Ω
1/8W J
R576 BIRC2220085M00 C RESISTOR 2.2K
Ω
1/8W
R577 BIRC2220085M00 C RESISTOR 2.2K
Ω
1/8W
R578 BIRC4710045M00 C RESISTOR 470
Ω
1/4W
R579 BIRC4700085M00 C RESISTOR 47
Ω
1/8W
R580 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R581 BIRC3320105A00 C RESISTOR 3.3K
Ω
1/10W
R582 BIRC5610085M00 RESISTOR 560
Ω
1/8W
R585 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
R586 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
R597 BIRC4710045M00 C RESISTOR 470
Ω
1/4W
R598 BIRC2210085M00 C RESISTOR 220
Ω
1/8W
R701 BIRC0820105A00 C RESISTOR 8.2
Ω
1/10W
R702 BIRC8230105A00 C RESISTOR 82K
Ω
1/10W
R703 BIRC3930105A00 C RESISTOR 39K
Ω
1/10W
R704 BIRC3930105A00 C RESISTOR 39K
Ω
1/10W
R705 BIRC3930105A00 C RESISTOR 39K
Ω
1/10W
R706 BIRC3930105A00 C RESISTOR 39K
Ω
1/10W
R707 BIRC8230105A00 C RESISTOR 82K
Ω
1/10W
R708 BIRC3940105A00 C RESISTOR 390K
Ω
1/10W
R709 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R710 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R711 BIRC8220105A00 C RESISTOR 8.2K
Ω
1/10W
Symbol
No.
Part No. Part Name Description Local
R714 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R715 BIRC1830105A00 C RESISTOR 18K
Ω
1/10W
R716 BIRC2230105A00 C RESISTOR 22K
Ω
1/10W
R717 BIRC1050105A00 C RESISTOR 1M
Ω
1/10W
R718 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R719 BIRC5620105A00 C RESISTOR 5.6K
Ω
1/10W
R720 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R721 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R722 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R723 BIRC6830105A00 C RESISTOR 68K
Ω
1/10W
R724 BIRC5630105A00 C RESISTOR 56K
Ω
1/10W
R725 BIRC1530105A00 C RESISTOR 15K
Ω
1/10W
R726 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R727 BIRC8230105A00 C RESISTOR 82K
Ω
1/10W
R728 BIRC3930105A00 C RESISTOR 39K
Ω
1/10W
R729 BIRC3940105A00 C RESISTOR 390K
Ω
1/10W
R730 BIRC1240105A00 C RESISTOR 120K
Ω
1/10W
R731 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R732 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R750 BIRC8200105A00 C RESISTOR 82
Ω
1/10W
R751 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R752 BIRC1330105A00 C RESISTOR 13K
Ω
1/10W
R753 BIRC1330105A00 C RESISTOR 13K
Ω
1/10W
R754 BIRC1330105A00 C RESISTOR 13K
Ω
1/10W
R755 BIRC1330105A00 C RESISTOR 13K
Ω
1/10W
R756 BIRC1020085N00 C RESISTOR 1K
Ω
1/8W
R757 BIRC1020085N00 C RESISTOR 1K
Ω
1/8W
R758 BIRC1810105A00 C RESISTOR 180
Ω
1/10W
R759 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R760 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R761 BIRC6820105A00 C RESISTOR 6.8K
Ω
1/10W
R762 BIRC1020085M00 C RESISTOR 1K
Ω
1/8W J
R763 BIRC2020105A00 C RESISTOR 2K
Ω
1/10W
R764 BIRC0100025N00 C RESISTOR 1
Ω
1/2W
R780 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R781 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R782 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R801 BIRC1210105A00 C RESISTOR 120
Ω
1/10W
R802 BIRC1010085M00 C RESISTOR 100
Ω
1/8W J
R803 BIRC1010085M00 C RESISTOR 100
Ω
1/8W J
R804 BIRC1050105A00 C RESISTOR 1M
Ω
1/10W
R805 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R806 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R807 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R808 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R809 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R810 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R811 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R814 BIRC1210085M00 C RESISTOR 120
Ω
1/8W
R815 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R816 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R817 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R821 BIRC1020085M00 C RESISTOR 1K
Ω
1/8W J
R850 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
L301 BI26100000KN00 FIXED INDUCTOR 10uH
L302 BI18A843556N00 FILTER BEAD 843556
L304 BI18A916121A00 FERRITE BEAD 120
Ω
L501 BI18A843556N00 FILTER BEAD 843556
L503 BI18A843556N00 FILTER BEAD 843556
L505 BICH103500KM01 C CAPACITOR 0.01uF 50V
L509 BI18A843556N00 FILTER BEAD 843556
L702 BI26100000KN00 FIXED INDUCTOR 10uH
L801 BI26100000KN00 FIXED INDUCTOR 10uH
L802 BI26100000KN00 FIXED INDUCTOR 10uH
L803 BI26100000KN00 FIXED INDUCTOR 10uH
L804 BI26100000KN00 FIXED INDUCTOR 10uH
L805 BI26100000KN00 FIXED INDUCTOR 10uH
L806 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
L807 BI18A843556N00 FILTER BEAD 843556
L808 BI18A843556N00 FILTER BEAD 843556
T401 BI603141V COIL OSC
CN201 BI12S1800061V CONNECTOR 18P
CN205 BI12S30039 CONNECTOR 3P
CN301 BI12S30039 CONNECTOR 3P
CN302 BI12S80024 CONNECTOR 8P
Symbol
No.
Part No. Part Name Description Local
