3-10
Front board (MX-KC45E,MX-KC45EN)
Block No. [0][2]
CN303 BI12S90024V FFC CONNECTOR 9P
CN306 BI12S100047X CONNECTOR 10P
CN601 BI12S240004V FFC CONNECTOR 24P
CN701 BI12S160031V FFC CONNECTOR 16P
CN702 BI12P60142V CONNECTOR WIRE 6P to CD MECHA
CN703 BI12P100051X CONNECTOR WIRE
10P to CD PICK
UP
JR301 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR302 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR401 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR402 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR403 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR404 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR408 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR701 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR702 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR703 BIRC0000085A00 C RESISTOR 0
Ω
1/8W
JR801 BIRC0000085A00 C RESISTOR 0
Ω
1/8W
X801 BI2102361 CRYSTAL 16.9344MHz
XT301 BI2101012 CRYSTAL 32.768KHz
XT302 BI29ZTA8.00P015 C RESONATOR 8MHz
Symbol
No.
Part No. Part Name Description Local
IC201 BI115291X IC RPM7138-V4
IC202 BI116661X IC S5G5128A
D201 1SS133 FR DIODE
BI31SS133M000V
7
D202 1SS133 FR DIODE
BI31SS133M000V
7
D206 1SS133 FR DIODE
BI31SS133M000V
7
D207 1SS133 FR DIODE
BI31SS133M000V
7
D208 1SS133 FR DIODE
BI31SS133M000V
7
C201 BICC103500KA02 C CAPACITOR 0.01uF 50V
C202 BICC103500KA02 C CAPACITOR 0.01uF 50V
C203 BICE106500MP01 E CAPACTIOR 10uF 50V
C204 BICC102500KA04 C CAPACITOR 1000pF 50V
C205 BICE226500MP01 E CAPACITOR 22uF 50V
C207 BICE226500MP01 E CAPACITOR 22uF 50V
C209 BICC104500KA04 C CAPACITOR 0.1uF 50V
C211 BICE107500MP01 E CAPACITOR 100uF 50V
C212 BICC104500KA04 C CAPACITOR 0.1uF 50V
C213 BICC104500KA04 C CAPACITOR 0.1uF 50V
C221 BICC102500KA04 C CAPACITOR 1000pF 50V
C222 BICC102500KA04 C CAPACITOR 1000pF 50V
C225 BICC104500KA04 C CAPACITOR 0.1uF 50V
C226 BICC104500KA04 C CAPACITOR 0.1uF 50V
C227 BICC101500JA04 C CAPACITOR 100pF 50V
C228 BICC101500JA04 C CAPACITOR 100pF 50V
C229 BICC101500JA04 C CAPACITOR 100pF 50V
C230 BICC102500KA04 C CAPACITOR 1000pF 50V
C231 BICC102500KA04 C CAPACITOR 1000pF 50V
C233 BICE108063MP01 E CAPACITOR 1000uF 6.3V
R203 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R204 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R205 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R206 BIRC2210105A00 C RESISTOR 220
Ω
1/10W
R207 BIRC0100105A00 C RESISTOR 1
Ω
1/10W
R208 BIRC0100105A00 C RESISTOR 1
Ω
1/10W
R209 BIRC1000085M00 C RESISTOR 10
Ω
1/8W
R210 BIRC2730105A00 C RESISTOR 27K
Ω
1/10W
R212 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R213 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R214 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
Symbol
No.
Part No. Part Name Description Local
R215 BIRC9110105A00 C RESISTOR 910
Ω
1/10W
R216 BIRC1120105A00 C RESISTOR 1.1K
Ω
1/10W
R217 BIRC1320105A00 C RESISTOR 1.3K
Ω
1/10W
R218 BIRC1820105A00 C RESISTOR 1.8K
Ω
1/10W
R219 BIRC2020105A00 C RESISTOR 2K
Ω
1/10W
R220 BIRC3020105A00 C RESISTOR 3K
Ω
1/10W
R221 BIRC3920105A00 C RESISTOR 3.9K
Ω
1/10W
R222 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R223 BIRC9110105A00 C RESISTOR 910
Ω
1/10W
R224 BIRC1120105A00 C RESISTOR 1.1K
Ω
1/10W
R225 BIRC1320105A00 C RESISTOR 1.3K
Ω
1/10W
R226 BIRC1820105A00 C RESISTOR 1.8K
Ω
1/10W
R227 BIRC2020105A00 C RESISTOR 2K
Ω
1/10W
R228 BIRC3020105A00 C RESISTOR 3K
Ω
1/10W
R229 BIRC3920105A00 C RESISTOR 3.9K
Ω
1/10W
R230 BIRC6220105A00 C RESISTOR 6.2K
Ω
1/10W
R231 BIRC9110105A00 C RESISTOR 910
Ω
1/10W
R232 BIRC1120105A00 C RESISTOR 1.1K
Ω
1/10W
R233 BIRC1320105A00 C RESISTOR 1.3K
Ω
1/10W
R234 BIRC1820105A00 C RESISTOR 1.8K
Ω
1/10W
R235 BIRC2020105A00 C RESISTOR 2K
Ω
1/10W
R236 BIRC3020105A00 C RESISTOR 3K
Ω
1/10W
R237 BIRC3920105A00 C RESISTOR 3.9K
Ω
1/10W
R238 BIRC6220105A00 C RESISTOR 6.2K
Ω
1/10W
R241 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R247 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R248 BIRC1020085M00 C RESISTOR 1K
Ω
1/8W J
R249 BIRC1020085M00 C RESISTOR 1K
Ω
1/8W J
R250 BIRC1020085M00 C RESISTOR 1K
Ω
1/8W J
R251 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R252 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R253 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R254 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R255 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R256 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R257 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R258 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R259 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R260 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R261 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R262 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R263 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R264 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R265 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R266 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R267 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R268 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R269 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R270 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R271 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R272 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R273 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R274 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R275 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R276 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R277 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R278 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R279 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R280 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R281 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R282 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R283 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R284 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R285 BIRC1810045M00 C RESISTOR 180
Ω
1/4W
R286 BIRC1810045M00 C RESISTOR 180
Ω
1/4W
VR201 BI804401V ROTARY SW RE012307PVB30
L201 BI26100000KM00 FIXED INDUCTOR 10uH
L202 BI26100000KM00 FIXED INDUCTOR 10uH
L203 BI18A843556N00 FILTER BEAD 843556
CN201 BI12S30081X CONNCTOR 3P
CN203 BI12P30272X CONNECTOR WIRE
3P to FRONT
CN201
CW201 BI12S1800071 FFC CONNECTOR 18P
CW202 BI12P402341V CONNECTOR WIRE 4P to AMP CN202
CW205 BI12P30270X CONNECTOR WIRE 3P MAIN CN205
Symbol
No.
Part No. Part Name Description Local
