JVC MX-KC45E - Page 49

3-11
Amp board (MX-KC45E,MX-KC45EN)
Block No. [0][3]
FL201 BI2702381X FL DISPLAY HNAC 17LM3 41P
JK201 BI2301211 MINI JACK CKX-3.5- 25
JK202 BI2301211 MINI JACK CKX-3.5- 25
LD201 BI28B4541EP01 LED
RED BL-B4541-AV-
TBS2
S201 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S202 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S203 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S204 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S205 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S206 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S207 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S208 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S209 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S210 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S211 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S212 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S213 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S214 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S215 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S216 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S217 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S218 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S219 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S220 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S221 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S222 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S223 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S224 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S225 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S226 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S227 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S228 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
XXXXX BI1206721X FLAT CABLE
8P CW215 to
CW203

Symbol
No.
Part No. Part Name Description Local
IC601 BI118201X IC STK412-430-E
Q101 2SC3052 TRANSISTOR
BI2SC3052FA013
H
Q111 KTA1273Y TRANSISTOR BI2KTA1273YP000
Q112 2SC3052 TRANSISTOR
BI2SC3052FA013
H
Q113 2SC3052 TRANSISTOR
BI2SC3052FA013
H
Q114 KTA1273Y TRANSISTOR BI2KTA1273YP000
Q201 2SC3052 TRANSISTOR
BI2SC3052FA013
H
Q601 2SC3052 TRANSISTOR
BI2SC3052FA013
H
Q604 2SB1370 TRANSISTOR BI22SB1370E7
Q605 2SC3052 TRANSISTOR
BI2SC3052FA013
H
Q607 KTA1273Y TRANSISTOR BI2KTA1273YP000
Q608 2SB1370 TRANSISTOR BI22SB1370E7
Q609 2SC3052 TRANSISTOR
BI2SC3052FA013
H
Q610 2SC3052 TRANSISTOR
BI2SC3052FA013
H
Q611 DTC323TK DIGI TRANSISTOR
BI2DTC323TKA01
1
Q612 DTC323TK DIGI TRANSISTOR
BI2DTC323TKA01
1
Q613 KTA1267GR TRANSISTOR
BI2KTA1267GP00
0
Q614 KTA1267GR TRANSISTOR
BI2KTA1267GP00
0
Q615 2SC3052 TRANSISTOR
BI2SC3052FA013
H

Symbol
No.
Part No. Part Name Description Local
Q616 2SC3052 TRANSISTOR
BI2SC3052FA013
H
Q617 2SC3052 TRANSISTOR
BI2SC3052FA013
H
Q618 2SC3052 TRANSISTOR
BI2SC3052FA013
H
Q619 DTA114YK DIGI TRANSISTOR
BI2DTA114YKA01
8
Q620 DTA114YK DIGI TRANSISTOR
BI2DTA114YKA01
8
Q621 DTA114YK DIGI TRANSISTOR
BI2DTA114YKA01
8
Q622 DTC323TK DIGI TRANSISTOR
BI2DTC323TKA01
1
Q623 DTC323TK DIGI TRANSISTOR
BI2DTC323TKA01
1
Q624 DTA114YK DIGI TRANSISTOR
BI2DTA114YKA01
8
D101 1N4003 DIODE BI31N4003LEM000
D102 1N4003 DIODE BI31N4003LEM000
D103 1N4003 DIODE BI31N4003LEM000
D105 1SS133 FR DIODE
BI31SS133M000V
7
D106 1SS133 FR DIODE
BI31SS133M000V
7
D107 1SS133 FR DIODE
BI31SS133M000V
7
D108 1SS133 FR DIODE
BI31SS133M000V
7
D109 MC2838 DIODE BI3MC2838A002
D601 1N4003 DIODE BI31N4003LEM000
D602 1N4003 DIODE BI31N4003LEM000
D603 1N4003 DIODE BI31N4003LEM000
D605 1N4003 DIODE BI31N4003LEM000
D606 1N4003 DIODE BI31N4003LEM000
D607 UZ12BSC Z DIODE
BI3UZ12BSCM000
V
D609 UZ30BSD Z DIODE
BI3UZ30BSDM000
0
D610 UZ6.2BSB Z DIODE BI3UZ6.2BSBM000
D611 UZ5.6BSB Z DIODE BI3UZ5.6BSBM000
D613 1N4003 DIODE BI31N4003LEM000
D614 RS402M SELEN RECTIFIER BI3RS402M1
D615 GBU6J DIODE BI3GBU6J1V
D616 UZ12BSC Z DIODE
BI3UZ12BSCM000
V
D617 UZ12BSC Z DIODE
BI3UZ12BSCM000
V
D618 1SS133 FR DIODE
BI31SS133M000V
7
D619 1SS133 FR DIODE
BI31SS133M000V
7
D620 1SS133 FR DIODE
BI31SS133M000V
7
D621 1SS133 FR DIODE
BI31SS133M000V
7
D622 1SS133 FR DIODE
BI31SS133M000V
7
D623 1SS133 FR DIODE
BI31SS133M000V
7
D624 1SS133 FR DIODE
BI31SS133M000V
7
D625 1SS133 FR DIODE
BI31SS133M000V
7
D626 1SS133 FR DIODE
BI31SS133M000V
7
D631 1SS133 FR DIODE
BI31SS133M000V
7
C101 BICE108250MP01 E CAPACITOR 1000uF 25V
C102 BICE107100MP01 E CAPACITOR 100uF 10V
C113 BICE107100MP01 E CAPACITOR 100uF 10V
C114 BICE105500MP01 E CAPACITOR 1uF 50V
C115 BICE476160MP01 E CAPACITOR 47uF 16V
C116 BICE107160MP01 E CAPACITOR 100uF 16V
C117 BICE107160MP01 E CAPACITOR 100uF 16V
C118 BICE107160MP01 E CAPACITOR 100uF 16V
C601 BICC104250ZA04 C CAPACITOR 0.1uF 25V
C602 BICC104250ZA04 C CAPACITOR 0.1uF 25V

Symbol
No.
Part No. Part Name Description Local
