3-12
C603 BICC104250ZA04 C CAPACITOR 0.1uF 25V
C604 BICC104250ZA04 C CAPACITOR 0.1uF 25V
C605 BICE47825M0 E CAPACITOR 4700uF 25V
C606 BICE105500MP01 E CAPACITOR 1uF 50V
C607 BICE107250MP01 E CAPACITOR 100uF 25V
C608 BICC104250ZA04 C CAPACITOR 0.1uF 25V
C609 BICE107160MP01 E CAPACITOR 100uF 16V
C610 BICE476630MP01 E CAPACITOR 47uF 63V
C611 BICE226500MP01 E CAPACITOR 22uF 50V
C612 BICC103500KA04 C CAPACITOR 0.01uF 50V
C613 BICE226500MP01 E CAPACITOR 22uF 50V
C614 BICE106250MP01 E CAPACITOR 10uF 25V
C615 BICC103500KA04 C CAPACITOR 0.01uF 50V
C616 BICE477100MP01 E CAPACITOR 470uF 10V
C617 BICM682101KP01 M CAPACITOR 6800pF 100V
C618 BICM682101KP01 M CAPACITOR 6800pF 100V
C619 BICM682101KP01 M CAPACITOR 6800pF 100V
C620 BICM682101KP01 M CAPACITOR 6800pF 100V
C621 BICM682101KP01 M CAPACITOR 6800pF 100V
C622 BICM682101KP01 M CAPACITOR 6800pF 100V
C623 BICE47850MSNY3 E CAPACITOR 4700uF 50V
C624 BICE47850MSNY3 E CAPACITOR 4700uF 50V
C625 BICE33871M2Y E CAPACITOR 3300uF 71V
C626 BICE33871M2Y E CAPACITOR 3300uF 71V
C627 BICM682101KP01 M CAPACITOR 6800pF 100V
C628 BICM682101KP01 M CAPACITOR 6800pF 100V
C631 BICE107101MP01 E CAPACITOR 100uF 100V
C632 BICE107101MP01 E CAPACITOR 100uF 100V
C633 BICC101500JA04 C CAPACITOR 100pF 50V
C634 BICC101500JA04 C CAPACITOR 100pF 50V
C635 BICE107100MP01 E CAPACITOR 100uF 10V
C636 BICE107100MP01 E CAPACITOR 100uF 10V
C637 BICC030500CA04 C CAPACITOR 3pF 50V
C638 BICC030500CA04 C CAPACITOR 3pF 50V
C639 BICC102500JA04 C CAPACITOR 1000pF 50V
C640 BICC102500JA04 C CAPACITOR 1000pF 50V
C641 BICE475500MP01 E CAPACITOR 4.7uF 50V
C642 BICE475500MP01 E CAPACITOR 4.7uF 50V
C643 BICE475500MP01 E CAPACITOR 4.7uF 50V
C644 BICE105500MP01 E CAPACITOR 1uF 50V
C645 BICM104101KP01 M CAPACITOR 0.1uF 100V
C646 BICM104101KP01 M CAPACITOR 0.1uF 100V
C647 BICM104101KP01 M CAPACITOR 0.1uF 100V
C648 BICM104101KP01 M CAPACITOR 0.1uF 100V
C649 BICC121500JA04 C CAPACITOR 120pF 50V
C650 BICE476160MP01 E CAPACITOR 47uF 16V
C651 BICC223500KA04 C CAPACITOR 0.022uF 50V
C652 BICE226500MP01 E CAPACITOR 22uF 50V
C653 BICE227100MP01 E CAPACITOR 220uF 10V
C654 BICE106250MP01 E CAPACITOR 10uF 25V
C655 BICC153500KA04 C CAPACITOR 0.015uF 50V
C656 BICC153500KA04 C CAPACITOR 0.015uF 50V
C699 BICC104250ZA04 C CAPACITOR 0.1uF 25V
R101 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R102 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R103 BIRC2230105A00 C RESISTOR 22K
Ω
1/10W
R104 BIRC2230105A00 C RESISTOR 22K
Ω
1/10W
R110 BIRC0220105A00 C RESISTOR 2.2
Ω
1/10W
R112 BIRC4710105A00 C RESISTOR 470
Ω
1/10W
R113 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R114 BIRC5600105A00 C RESISTOR 56
Ω
1/10W
R115 BIRC2240105A00 C RESISTOR 220K
Ω
1/10W
R116 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R117 BIRC4710105A00 C RESISTOR 470
Ω
1/10W
R118 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R119 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R120 BIRC3330105A00 C RESISTOR 33K
Ω
1/10W
R121 BIRC3330105A00 C RESISTOR 33K
Ω
1/10W
R123 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R124 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R600 BIRC8210105A00 C RESISTOR 820
Ω
1/10W
R601 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R602 BIRC5600105A00 C RESISTOR 56
Ω
1/10W
R605 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R606 BIRC3320105A00 C RESISTOR 3.3K
Ω
1/10W
R607 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
Symbol
No.
Part No. Part Name Description Local
R608 BIRC1010085N00 C RESISTOR 100
Ω
1/8W
R609 BIRC1010085N00 C RESISTOR 100
Ω
1/8W
R610 BIRC1540105A00 C RESISTOR 150K
Ω
1/10W
R611 BIRC5630105A00 C RESISTOR 56K
Ω
1/10W
R612 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R613 BIRF1010025N00 FUSE RESISTOR 100
Ω
1/2W
R614 BIRF1010025N00 FUSE RESISTOR 100
Ω
1/2W
R615 BIRC1520025N00 C RESISTOR 1.5K
Ω
1/2W
R616 BIRC1520025N00 C RESISTOR 1.5K
Ω
1/2W
R617 BIRC5610105A00 C RESISTOR 560
Ω
1/10W
R618 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
R619 BIRC3330105A00 C RESISTOR 33K
Ω
1/10W
R620 BIRC3330105A00 C RESISTOR 33K
Ω
1/10W
R621 BIRC5610105A00 C RESISTOR 560
Ω
1/10W
R622 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
R623 BIRC3330105A00 C RESISTOR 33K
Ω
1/10W
R624 BIRC5630105A00 C RESISTOR 56K
Ω
1/10W
R625 BIRC5630105A00 C RESISTOR 56K
Ω
1/10W
R626 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R627 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R628 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R629 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R630 BIRC3920105A00 C RESISTOR 3.9K
Ω
1/10W
R631 BIRC3920105A00 C RESISTOR 3.9K
Ω
1/10W
R632 BIRM001530V M RESISTOR 0.15
Ω
3W
R633 BIRM001530V M RESISTOR 0.15
Ω
3W
R634 BIRM001530V M RESISTOR 0.15
Ω
3W
R635 BIRM001530V M RESISTOR 0.15
Ω
3W
R636 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R637 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R638 BIRC1530105A00 C RESISTOR 15K
Ω
1/10W
R639 BIRC1530105A00 C RESISTOR 15K
Ω
1/10W
R640 BIRC0470045N00 C RESISTOR 4.7
Ω
1/4W
R641 BIRC0470045N00 C RESISTOR 4.7
Ω
1/4W
R642 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R643 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R644 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R645 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R646 BIRC4710105A00 C RESISTOR 470
Ω
1/10W
R647 BIRC4740105A00 C RESISTOR 470K
Ω
1/10W
R648 BIRC0470045N00 C RESISTOR 4.7
Ω
1/4W
R649 BIRC0470045N00 C RESISTOR 4.7
Ω
1/4W
R650 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R651 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R652 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R653 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
R654 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R655 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R656 BIRC1500085M00 C RESISTOR 15
Ω
1/8W
R657 BIRC6840105A00 C RESISTOR 680K
Ω
1/10W
R658 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R659 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R660 BIRC3920105A00 C RESISTOR 3.9K
Ω
1/10W
R661 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R662 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R663 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R664 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R665 BIRM1020N25N00 M RESISTOR 1K
Ω
2W
R666 BIRM1020N25N00 M RESISTOR 1K
Ω
2W
R669 BIRC1220105A00 C RESISTOR 1.2K
Ω
1/10W
R671 BIRC1030085M00 C RESISTOR 10K
Ω
1/8W J
R672 BIRC3300045M00 C RESISTOR 33
Ω
1/4W
R679 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
R681 BIRC3330085M00 C RESISTOR 33K
Ω
1/8W
R682 BIRC3330085M00 C RESISTOR 33K
Ω
1/8W
R683 BIRC4730085M00 C RESISTOR 47K
Ω
1/8W
R684 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
L601 BI2601141 COIL 3.0uH
L602 BI2601141 COIL 3.0uH
CN202 BI12S40047 CONNECTOR 4P
CN602 BI12S20016 CONNECTOR 2P
CN603 BI12S300471V CONNECTOR 3P
CN902 BI12S60127X CONNECTOR 6P
CN903 BI12S80060V CONNECTOR 8P
CW601 BI12S240004V FFC CONNECTOR 24P
Symbol
No.
Part No. Part Name Description Local
