JVC MX-KC45E - Page 51

3-13
Power trans board
(MX-KC45E,MX-KC45EN)
Block No. [0][4]
Main board (MX-KC45A)
Block No. [0][5]
JK601 BI2301571X TERMINAL SPK 4P
 RF601 BIRF3300025N00 FUSE RESISTOR 33 Ω 1/2W
RY601 BI8RL00191V RELAY
DC12V ME-7C-
012-3H

Symbol
No.
Part No. Part Name Description Local
Q901 DTC114YS DIGI TRANSISTOR BI2DTC114YKA011
D901 1SS133 FR DIODE
BI31SS133M000V
7
D902 1SS133 FR DIODE
BI31SS133M000V
7
D903 1SS133 FR DIODE
BI31SS133M000V
7
D904 1SS133 FR DIODE
BI31SS133M000V
7
D905 1SS133 FR DIODE
BI31SS133M000V
7
D906 1SS133 FR DIODE
BI31SS133M000V
7
C901 BICH223250ZM01 C CAPACITOR 0.022uF 25V
C902 BICH223250ZM01 C CAPACITOR 0.022uF 25V
C903 BICH223250ZM01 C CAPACITOR 0.022uF 25V
C904 BICH223250ZM01 C CAPACITOR 0.022uF 25V
C905 BICE477250MP01 E CAPACITOR 470uF 25V
C907 BICE335500MP01 E CAPACITOR 3.3uF 50V
 C951 BICT224275MX TA CAPACITOR 0.22uF 275V
R901 BIRC1000085M00 C RESISTOR 10 Ω 1/8W
R902 BIRC4720085M00 C RESISTOR 4.7K Ω 1/8W
 L901 BI2601102V LINE FILTER WIRE
CW902 BI12P60176X CONNECTOR WIRE 6P to AMP CN902
CW903 BI12P80121X CONNECTOR WIRE 8P to AMP CN903
 PT902 BI211011142001 POWER TRANS TG1204000
 RY901 BI8RL00171V RELAY
DC9V 250mW
KTC3199GR

Symbol
No.
Part No. Part Name Description Local
IC301 BI120971X IC S3C825C63
IC302 BI116691X IC BU4051B
IC401 BI112721X IC BD3881FV
IC403 BI101851X IC NJM78L05
IC701 BI116431X IC SIL9226X0
IC702 BI118221X IC B5927FM
IC801 BI118171X IC BH18FB1WG
IC802 BI110891X IC KI7808P
IC803 BI117401X IC K4S161622H
IC804 BI120281X IC S5L8310
Q50 2SC3052 TRNSISTOR BI2SC3052F013H
Q302 2SC3052 TRNSISTOR BI2SC3052F013H
Q303 DTC114YK DIGI TRNSISTOR BI2DTC114YK018
Q304 2SC1815 TRNSISTOR
BI2SC1815GRP00
0
Q401 2SJ460 TRNSISTOR BI2SJ460P0001
Q402 2SJ460 TRNSISTOR BI2SJ460P0001

Symbol
No.
Part No. Part Name Description Local
Q403 2SK2541 TRNSISTOR BI2SK2541P0001
Q404 2SK2541 TRNSISTOR BI2SK2541P0001
Q405 2SJ460 TRNSISTOR BI2SJ460P0001
Q406 2SJ460 TRNSISTOR BI2SJ460P0001
Q407 2SK2541 TRNSISTOR BI2SK2541P0001
Q408 2SK2541 TRNSISTOR BI2SK2541P0001
Q409 2SK2541 TRNSISTOR BI2SK2541P0001
Q410 SR2202S TRNSISTOR BI2SR2202S00
Q411 KT1267GR TRNSISTOR BI2KT1BI267GP
Q412 DTC114YK DIGI TRNSISTOR BI2DTC114YK018
Q413 DTC114YK DIGI TRNSISTOR BI2DTC114YK018
Q414 2SC3052 TRNSISTOR BI2SC3052F013H
Q415 KT1273 TRNSISTOR BI2KT1273P0008
Q416 2SC3052 TRNSISTOR BI2SC3052F013H
Q417 KT1273 TRNSISTOR BI2KT1273P0008
Q418 DTC114TK DIGI TRNSISTOR BI2DTC114TK011
Q419 KT1273 TRNSISTOR BI2KT1273P0008
Q420 2SC3052 TRNSISTOR BI2SC3052F013H
Q421 2SC3052 TRNSISTOR BI2SC3052F013H
Q422 2SC3052 TRNSISTOR BI2SC3052F013H
Q423 KT1267GR TRNSISTOR BI2KT1267GP00
Q424 KTC3199G TRNSISTOR BI2KTC3199GP00
Q425 KTC3199G TRNSISTOR BI2KTC3199GP00
Q433 2SC3052 TRNSISTOR BI2SC3052F013H
Q434 2SC5343 TRNSISTOR
BI2SC5343GP000
0
Q435 2SC5343 TRNSISTOR
BI2SC5343GP000
0
Q436 2SC5343 TRNSISTOR
BI2SC5343GP000
0
Q437 2SC3052 TRNSISTOR BI2SC3052F013H
Q438 DTC114TK DIGI TRNSISTOR BI2DTC114TK011
Q504 KT1267GR TRNSISTOR BI2KT1267GP00
Q505 DTC114TK DIGI TRNSISTOR BI2DTC114TK011
Q506 KT1267GR TRNSISTOR BI2KT1267GP00
Q507 DTC114TK DIGI TRNSISTOR BI2DTC114TK011
Q508 2SC1815 TRNSISTOR
BI2SC1815GRP00
0
Q509 DTC114TK DIGI TRNSISTOR BI2DTC114TK011
Q701 KT1266GR TRNSISTOR BI2KT1266GP00
Q703 KTC3205 TRNSISTOR BI2KTC3205P0008
Q704 2SC1815 TRNSISTOR
BI2SC1815GRP00
0
D301 1SS133 FR DIODE
BI31SS133M000V
7
D302 1SS133 FR DIODE
BI31SS133M000V
7
D303 1SS133 FR DIODE
BI31SS133M000V
7
D304 1SS133 FR DIODE
BI31SS133M000V
7
D305 1SS133 FR DIODE
BI31SS133M000V
7
D306 UZ4.7BS Z DIODE BI3UZ4.7BSM000
D307 1SS133 FR DIODE
BI31SS133M000V
7
D308 1SS133 FR DIODE
BI31SS133M000V
7
D309 1SS133 FR DIODE
BI31SS133M000V
7
D401 MC2836 DIODE BI3MC2836002H
D402 UZ4.7BS Z DIODE BI3UZ4.7BSM000
D403 1SS133 FR DIODE
BI31SS133M000V
7
D404 1SS133 FR DIODE
BI31SS133M000V
7
D405 UZ4.7BS Z DIODE BI3UZ4.7BSM000
D406 1SS133 FR DIODE
BI31SS133M000V
7
D407 1SS133 FR DIODE
BI31SS133M000V
7
D501 1SS133 FR DIODE
BI31SS133M000V
7
D502 1SS133 FR DIODE
BI31SS133M000V
7
D503 1SS133 FR DIODE
BI31SS133M000V
7
D504 1SS133 FR DIODE
BI31SS133M000V
7

Symbol
No.
Part No. Part Name Description Local
