JVC MX-KC45E - Page 52

3-14
D505 1SS133 FR DIODE
BI31SS133M000V
7
D508 1SS133 FR DIODE
BI31SS133M000V
7
D509 1SS133 FR DIODE
BI31SS133M000V
7
D510 1N4002 DIODE BI31N4002M000V3
D511 1SS133 FR DIODE
BI31SS133M000V
7
D516 UZ11BSC Z DIODE
BI3UZ11BSCM000
0
D517 UZ9.1BSC Z DIODE
BI3UZ91BSCM000
V
D710 UZ3.6BSB Z DIODE BI3UZ3.6BSBM000
D711 UZ3.6BSB Z DIODE BI3UZ3.6BSBM000
D712 1SS133 FR DIODE
BI31SS133M000V
7
D713 1SS133 FR DIODE
BI31SS133M000V
7
D801 1SS133 FR DIODE
BI31SS133M000V
7
C301 BICC104500K04 C CPCITOR 0.1uF 50V
C302 BICC104500K04 C CPCITOR 0.1uF 50V
C303 BICC223500K04 C CPCITOR 0.022uF 50V
C304 BICE107100MP01 E CPCITOR 100uF 10V
C305 BICE108100MP01 E CPCITOR 1000uF 10V
C306 BICE476250MP01 E CPCITOR 47uF 25V
C307 BICC104500K04 C CPCITOR 0.1uF 50V
C308 BICC104500K04 C CPCITOR 0.1uF 50V
C311 BICC270500J04 C CPCITOR 27pF 50V
C312 BICC240500J04 C CPCITOR 24pF
C313 BICC330500J04 C CPCITOR 33pF 50V
C314 BICC102500K04 C CPCITOR 1000pF 50V
C315 BICC220500J04 C CPCITOR 22pF 50V
C316 BICC220500J04 C CPCITOR 22pF 50V
C317 BICC104500K02 C CPCITOR 0.1uF 50V
C318 BICE105500MP01 E CPCITOR 1uF 50V
C319 BICC104500K02 C CPCITOR 0.1uF 50V
C322 BICC101500J04 C CPCITOR 100pF 50V
C323 BICC101500J04 C CPCITOR 100pF 50V
C324 BICC101500J04 C CPCITOR 100pF 50V
C325 BICC101500J04 C CPCITOR 100pF 50V
C326 BICC101500J04 C CPCITOR 100pF 50V
C401 BICC122500K04 C CPCITOR 1200pF 50V
C402 BICC122500K04 C CPCITOR 1200pF 50V
C403 BICC470500J04 C CPCITOR 47pF 50V
C404 BICC470500J04 C CPCITOR 47pF 50V
C405 BICE226100MP01 E CPCITOR 22uF 10V
C406 BICE226100MP01 E CPCITOR 22uF 10V
C407 BICE225500MP01 E CPCITOR 2.2uF 50V
C408 BICC471500K04 C CPCITOR 470pF 50V
C409 BICC103500K04 C CPCITOR 0.01uF 50V
C410 BICC103500K04 C CPCITOR 0.01uF 50V
C411 BICC181500J04 C CPCITOR 180pF 50V
C412 BICC181500J04 C CPCITOR 180pF 50V
C413 BICE107100MP01 E CPCITOR 100uF 10V
C414 BICC561500K04 C CPCITOR 560pF 50V
C415 BICC561500K04 C CPCITOR 560pF 50V
C416 BICC332500K04 C CPCITOR 3300pF 50V
C417 BICE227160MP01 E CPCITOR 220uF 16V
C418 BICE225500MP01 E CPCITOR 2.2uF 50V
C419 BICC332500K04 C CPCITOR 3300pF 50V
C420 BICE104500MP01 E CPCITOR 0.1uF 50V
C421 BICC101500J04 C CPCITOR 100pF 50V
C422 BICE474500MP01 E CPCITOR 0.47uF 50V
C423 BICC104500K04 C CPCITOR 0.1uF 50V
C424 BICC104500K04 C CPCITOR 0.1uF 50V
C425 BICE104500MP01 E CPCITOR 0.1uF 50V
C426 BICC122500K04 C CPCITOR 1200pF 50V
C427 BICC181500J04 C CPCITOR 180pF 50V
C428 BICE227160MP01 E CPCITOR 220uF 16V
C429 BICC122500K04 C CPCITOR 1200pF 50V
C430 BICC102500K04 C CPCITOR 1000pF 50V
C431 BICE107100MP01 E CPCITOR 100uF 10V
C432 BICC103500K04 C CPCITOR 0.01uF 50V
C433 BICC222500K04 C CPCITOR 2200pF 50V
C434 BICC181500J04 C CPCITOR 180pF 50V

Symbol
No.
Part No. Part Name Description Local
C435 BICC103500K04 C CPCITOR 0.01uF 50V
C436 BICC103500K04 C CPCITOR 0.01uF 50V
C437 BICC682500K04 C CPCITOR 6800pF 50V
C438 BICC104500K04 C CPCITOR 0.1uF 50V
C439 BICC103500K04 C CPCITOR 0.01uF 50V
C440 BICE227160MP01 E CPCITOR 220uF 16V
C441 BICC272500K04 C CPCITOR 2700pF
C444 BICC222500K04 C CPCITOR 2200pF 50V
C445 BICE474500MP01 E CPCITOR 0.47uF 50V
C446 BICC103500K04 C CPCITOR 0.01uF 50V
C447 BICE107160MP01 E CPCITOR 100uF 16V
C448 BICC682500K04 C CPCITOR 6800pF 50V
C449 BICC103500K04 C CPCITOR 0.01uF 50V
C450 BICE475500MP01 E CPCITOR 4.7uF 50V
C451 BICE107160MP01 E CPCITOR 100uF 16V
C453 BICC102500K04 C CPCITOR 1000pF 50V
C454 BICC102500K04 C CPCITOR 1000pF 50V
C458 BICE476160MP01 E CPCITOR 47uF 16V
C459 BICE224500MP01 E CPCITOR 0.22uF 50V
C460 BICE224500MP01 E CPCITOR 0.22uF 50V
C496 BICC683160K04 C CPCITOR 0.068uF 16V
C497 BICC683160K04 C CPCITOR 0.068uF 16V
C501 BICE226250MP01 E CPCITOR 22uF 25V
C502 BICE107100MP01 E CPCITOR 100uF10V
C503 BICM682101KP01 M CPCITOR 6800pF 100V
C518 BICC272500K04 C CPCITOR 2700pF
C520 BICC272500K04 C CPCITOR 2700pF
C521 BICC561500K04 C CPCITOR 560pF 50V
C524 BICE105500MP01 E CPCITOR 1uF 50V
C525 BICE475500MP01 E CPCITOR 4.7uF 50V
C526 BICE105500MP01 E CPCITOR 1uF 50V
C527 BICE226250MP01 E CPCITOR 22uF 25V
C528 BICE476160MP01 E CPCITOR 47uF 16V
C535 BICE476160MP01 E CPCITOR 47uF 16V
C536 BICC102500K04 C CPCITOR 1000pF 50V
C539 BICC102500K04 C CPCITOR 1000pF 50V
C540 BICC101500J04 C CPCITOR 100pF 50V
C541 BICC101500J04 C CPCITOR 100pF 50V
C542 BICE105500MP01 E CPCITOR 1uF 50V
C543 BICE105500MP01 E CPCITOR 1uF 50V
C544 BICE475500MP01 E CPCITOR 4.7uF 50V
C545 BICE475500MP01 E CPCITOR 4.7uF 50V
C546 BICE104500MP01 E CPCITOR 0.1uF 50V
C547 BICE104500MP01 E CPCITOR 0.1uF 50V
C557 BICE107100MP01 E CPCITOR 100uF 10V
C558 BICC103500K04 C CPCITOR 0.01uF 50V
C701 BICC104500K04 C CPCITOR 0.1uF 50V
C702 BICC104500K04 C CPCITOR 0.1uF 50V
C703 BICC102500K04 C CPCITOR 1000pF 50V
C704 BICE476160MP01 E CPCITOR 47uF 16V
C705 BICC102500K04 C CPCITOR 1000pF 50V
C706 BICC102500K04 C CPCITOR 1000pF 50V
C707 BICC103500K04 C CPCITOR 0.01uF 50V
C708 BICC473500K04 C CPCITOR 0.047uF 50V
C709 BICE107100MP01 E CPCITOR 100uF 10V
C710 BICE107100MP01 E CPCITOR 100uF 10V
C711 BICC040500C04 C CPCITOR 4pF 50V
C712 BICC100500D04 C CPCITOR 10pF 50V
C713 BICC682500K04 C CPCITOR 6800pF 50V
C714 BICC103500K04 C CPCITOR 0.01uF 50V
C715 BICE475500MP01 E CPCITOR 4.7uF 50V
C716 BICC104500K04 C CPCITOR 0.1uF 50V
C717 BICC104500K04 C CPCITOR 0.1uF 50V
C718 BICC102500K04 C CPCITOR 1000pF 50V
C719 BICC104500K04 C CPCITOR 0.1uF 50V
C720 BICC333250K04 C CPCITOR 0.033uF 25V
C721 BICC474100K04 C CPCITOR 0.47uF 10V
C722 BICC332500K04 C CPCITOR 3300pF 50V
C723 BICC474100K04 C CPCITOR 0.47uF 10V
C724 BICC103500K04 C CPCITOR 0.01uF 50V
C725 BICC683160K04 C CPCITOR 0.068uF 16V
C726 BICE106160MP01 E CPCITOR 10uF 16V
C727 BICC683160K04 C CPCITOR 0.068uF 16V
C728 BICC331500K04 C CPCITOR 330pF 50V
C729 BICC102500K04 C CPCITOR 1000pF 50V
C730 BICC222500K04 C CPCITOR 2200pF 50V
C731 BICC333250K04 C CPCITOR 0.033uF 25V

